Bluetooth® Modules That Simply Work

with iPhone®, iPad®, and iPod® Devices

Summary

Microchip’s Bluetooth APL modules natively support iAP

(iPod Accessory Protocol) data connections and directly

manage authentication, reducing engineering effort and

cost, and simplifying accessory product design.

Apple® iOS devices such as the iPhone freely connect via

the Bluetooth hands-free and headset profiles. However,

establishing Bluetooth data connections with an iPhone,

iPad or iPod requires a specific discovery class and

authentication. Every Bluetooth accessory must have an

Apple authentication co-processor.

APL modules are based on the standard RN41-I/RM

and RN42-I/RM, making them footprint compatible.

Power, ground and UART connections are identical, and

connection of the Apple authentication IC is direct to the

module via a 2-wire interface. The Apple authentication

IC is not part of the module. Customer must join and

purchase authentication ICs through the MFi program.

Features

■Discoverable/Connectable with iPhone, iPod or iPad

■Dual proﬁle allows Bluetooth connections to other

smartphone or computing platforms

■Automatically stores Bluetooth address of the last

paired device, for quick reconnection

■Secure Simple Pairing (SSP) enables ‘no PIN code

required’ operation

■Supports complete Microchip Bluetooth feature set

■Direct hardware connection to the

authentication co-processor

■Authentication without iAP ﬁrmware development

Development Tools

RN-4x-APL-EVAL Evaluation Kits Include:

■RN-4x-APLX development board which contains:

• RN4xAPL-I/RM module

• Apple authentication co-processor

• Status LEDs

• Power regulation

• RS232 and TTL signals

■Four RN4xAPL-I/RM modules

■Complete design documents including schematics

■Source code for the Microchip Diagnostic Application

Product Selector

Module Class Typ. Range Development Kit

RN41APL-I/RM Class 1 ~100m RN-41-APL-EVAL*

RN42APL-I/RM Class 2 ~30m RN-42-APL-EVAL*

*MFi membership is required to purchase the development kit of modules. Please check with your

Microchip Sales representative for availability: www.microchip.com/sales .

RN-41-APL-EVAL RN-42-APL-EVAL

Information subject to change. The Microchip name and logo and the Microchip logo are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. All other trademarks
