SMSC EVK-2074/84SOFTWARE OPERATION MANUALRevision 1.1 (03-31-06)

CircLink

TM

EVB Software Operation Manual

1 Overview

This manual explains how to install and operate the CircLink

TM

EVB Software. This software is used

to control a TMC2084 IO Node from a TMC2074 Host Node. This software was written using Visual

Studio VC++ 6.0 and is intended to run on a PC with a Windows 2000 or Windows XP operating

system. This software does not use interrupt handling. Editing this software requires a Visual Studio

VC++ 6.0 development environment. Correct operation of this software requires a CircLink evaluation

environment consisting of the following:

Exactly one host node, consisting of a PCM-2074 evaluation board with TMC2074 Dual Mode

CircLink Controller installed.

At least one IO node, consisting of an EVB-2084 evaluation board with TMC2084 IO Node CircLink

Controller installed. The CircLink

TM

EVB Software comes configured for two IO nodes.

This application does not access the PCM-2074 directly, but indirectly through a device driver. For

instructions on installation of this device driver, refer to Chapter 4.

1.1 Software File Listings

The CircLink

TM

EVB Software is shipped on one disk, consisting of the files outlined in Table 1.1 below:

Table 1.2 below lists all of the source and header files associated with the CircLink

TM

EVB Software.

Table1.1 CircLink

TM

EVB Software Installation Disks

ITEMFILE/FOLDER NAMECONTENTSNOTES

1<EcTest2000>Source filesVC++ 6.0

2EcTest.EXEExecutable file

3EcNetPcm.infINF File for PCM-2074 Device Driver (Win2000/XP)

4CLIoDRV.sysPCM-2074 Device Driver (Win2000/XP)

Table1.2 CircLink

TM

EVB Software Source Files

ITEMFILE NAMECONTENTSNOTES

1EcDriverIF.cppDevice driver I/F function

2Ecnet.cppCircLink related functions

3EcTest.cppVisual Studio auto-generation file

4EcTestDlg.cppMain dialogs of sample program
