Seite 1/6
MIDEA.COM | 4008899315
OWNER’S MANUAL
TOWER FAN
MODEL:FZ10-10JRH
Please read the instruction manual carefully before use and safekeeping.
TOWER FAN
GD Midea Environment Appliances Manufacturing CO.,LTD.
Midea Industrial Park, Dongfu Road, Dongfeng Town, Zhongshan, Guangdong, China
145x210mm 颜色 K FZ10-10JRH(CB) 说明书 369 20150918
1
Read Rules for Safe Operation and Instructions Carefully.
CAUTION
1. If the supply cord is damaged, it must be replaced by manufacturer
or its service agent or a similarly qualified person in order to avoid
a hazard.
2. To protect against the risk of electrical shock, do not immerse the
unit, cord or plug in water or other liquid.
3. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
4. When the appliance is not in use and before cleaning, unplug the
appliance from the outlet.
5. Keep electrical appliances out of reach from Children or infirm
persons. Do not let them use the appliances without supervision.
6. When the fan was assembled, the rotor blade guard shall not be
taken off anymore
- Prior cleaning unplug the fan
- The rotor guard shall not be dissembled/opened to clean the
rotor blades.
- Wipe the fan enclosure and rotor blade guard with a slightly
damp cloth.
WARNING
1. Never insert fingers, pencils, or any other object through the grille when fan is
running.
2. Disconnect fan when moving from one location to another.
3. Be sure fan is on a stable surface when operating to avoid overturning.
4. DO NOT use fan in window, rain may create electrical hazard.
5. Household use only.
RULES FOR SAFE OPERATION
2
PART FIGURE
Note: All the pictures in this manual are for explanation purpose only. Any discrepancy between
the real object and the illustration in the drawing shall be subject to the real subject.
1. Body
2. Pedestal
3. Base
4. Wing Screws
5. Power cord
A. Pedestal Assembly
• Line up the front and rear pedestal assembly pieces and firmly snap together.
Fig. 1. The rear piece has a screw hole opening near the top.
B. Base Assembly
• Connect the two pieces of the base together by inserting the four pins of the rear
half B into the four channeled holes for them in the front half A . Fig. 2.
C. Securing the Pedestal to the Base
• Align the 3 screw holes on the bottom of the pedestal with the 3 holes on the base
and insert pedestal into base. Fig. 3.
• Secure the base assembly to the pedestal by inserting and tightening the 3 wing
screws into the 3 holes located on the bottom of the base (Fig. 4).
D. Securing the Tower Fan to the Pedestal
• Carefully turn the fan on its side and place on a table. Feed power cord through the
center of the pedestal and base assembly.
• Insert the pedestal over the base of the fan body so that the tabs in the fan body
base fit into the slots for them in the pedestal. Rotate the pedestal slightly to secure
the tabs into the slots. When correctly secured the screw hole in the fan body base
will be aligned with the screw hole in the pedestal. Fig. 5.
• Secure the pedestal to the fan body base by inserting and tightening a wing screw
into the attachment hole. Fig. 6
ASSEMBLY INSTRUCTIONS
