HFC

utilized

R410A

INDOOR UNIT

SERVICE MANUAL

No. OBH733

REVISED EDITION-J

Indoor unit service manual

MSZ-GL•NA, MSY-GL•NA Series (OBH732)

MUZ-GL18/24NA

MUZ-GL18/24NAH

MUY-GL18/24NA

PARTS CATALOG (OBB733)

OBH733 REVISED EDITION-H is void.

Revision J:

• A warning when opening or closing the valve has

been added.

CONTENTS

1. TECHNICAL CHANGES ······························3

2. PART NAMES AND FUNCTIONS ··················3

3. SPECIFICATION ········································4

4. OUTLINES AND DIMENSIONS ·····················7

5. WIRING DIAGRAM ·····································9

6. REFRIGERANT SYSTEM DIAGRAM ···········21

7. DATA······················································24

8. ACTUATOR CONTROL ·····························39

9. SERVICE FUNCTIONS ······························40

10. TROUBLESHOOTING ·······························41

11. DISASSEMBLY INSTRUCTIONS ·················65

OUTDOOR UNIT

Models

MUZ-GL09NA

-

U1

,

U2

,

U8

MUZ-GL09NAH

-

U1

,

U2

,

U8

MUY-GL09NA

-

U1

,

U2

MUZ-GL12NA

-

U1

,

U2

MUZ-GL12NAH

-

U1

,

U2

MUY-GL12NA

-

U1

,

U2

MUZ-GL15NA

-

U1

,

U2

MUZ-GL15NAH

-

U1

,

U2

MUY-GL15NA

-

U1

,

U2

MUZ-GL18NA

-

U1

MUZ-GL18NAH

-

U1

MUY-GL18NA

-

U1

MUZ-GL24NA

-

U1

,

U2

MUZ-GL24NAH

-

U1

MUY-GL24NA

-

U1
