GE Monogram

Installation

Instructions

Under Cabinet Installation

and

JX827WN Built-In Kit

Microwave Oven

Model

ZEM200WV

Before you begin—Read these instructions completely and carefully.

IMPORTANT: Save these instructions for local inspector’s use.

IMPORTANT: OBSERVE ALL GOVERNING CODES AND ORDINANCES.

NOTE TO INSTALLER: Be sure to leave these instructions with the Consumer.

NOTE TO CONSUMER: Keep these instructions with your Use and Care Book for future

reference.

This appliance must be properly grounded. See “Electrical Supply”, page 6.

CAUTION

WARNING

If you have questions concerning the installation of

this product, call the GE Answer Center® Consumer

Information Service at 800.626.2000, 24 hours a day, 7

days a week.

If you received a damaged microwave oven, you

should contact your dealer.

Proper installation is the responsibility of the installer.

Product failure due to improper installation is not

covered under the GE Appliance Warranty. See the

Use & Care Guide for warranty information.

Contents

Design Information

Model Available............................................................................................................................................................... 3

Dimensions and Clearances ........................................................................................................................................... 3

Installation Options ........................................................................................................................................................ 3

Advance Planning ........................................................................................................................................................... 3

Cabinetry

ZEM200WV In-Wall Installation .................................................................................................................................... 4

ZEM200WV with Single Oven........................................................................................................................................ 5

ZEM200WV Under-Cabinet Mounting ......................................................................................................................... 5

Installation Preparation

Electrical Supply ............................................................................................................................................................. 6

ZEM200WV In-Wall Installation ................................................................................................................................ 6, 7

ZEM200WV Under-Cabinet Mounting .......................................................................................................................... 7

Installation

JX827WN Installation............................................................................................................................................ 8, 9, 10

Assemble Trim Kit Frame ............................................................................................................................................. 11

Install Trim Kit Frame................................................................................................................................................... 11

ZEM200WV Under-Cabinet Mounting ........................................................................................................................ 12

To Drill from Inside ................................................................................................................................................ 12, 13

To Drill from Bottom .................................................................................................................................................... 13

If Cabinet Has a Partition ............................................................................................................................................. 13

Finalize Under-Cabinet Installation ............................................................................................................................. 14

Questions & Answers

Inside Back Cover
