EASY REEL
TM
SPOOLER
I N S TA L L AT I O N I N S T R U C T I O N S
574.293.1581 • MORryde.com
Using the wood screws provided, install your Easy
Reel™ Spooler in the desired location by screwing
into your wood sub-floor through the 4 mounting
hole locations (8 mounting hole locations for the
REEL56-009H) on your Easy Reel™ Spooler.
NOTE: If your floor is not wood, please contact
MORryde for installation recommendations.
REEL56-004H
Stores up to 50' of amp
REEL56-001H
Stores up to 50' of amp
REEL56-009H
Stores up to 30' of amp cord
Screw Mounting Holes
Screw Mounting Holes
Screw Mounting Holes
I N S TA L L AT I O N I N S T R U C T I O N S
574.293.1581 • MORryde.com
Step 1
Loosen the resistance brake
on the handle of your Easy
Reel™ Spooler by turning
the knob counter-clockwise
enough to allow your reel
to freely rotate without any
resistance.
S TO R AG E
Step 2
For Detachable AMP Cord: Insert
the plug end of the cord into one of
the holes in the center of your Easy
Reel™ Spooler and slide the cord
to either the right or left side of the
inner spool.
For Hard-Wired AMP Cord: Insert
the socket end of the cord into one
of the holes in the center of your
Easy Reel™ Spooler and slide the
cord to either the right or left side
of the inner spool.
Step 3
While holding the cord in one hand, begin winding the
cord using the Easy Reel™ Handle. Guide the cord from
side-to-side as you coil the cord.
NOTE: Holding a rag in the hand that guides the cord will help
clean to cord as you store it in your spooler.
Step 4
Once the cord is fully stored, tighten the resistance
brake on the handle of your Easy Reel™ Spooler by
turning clockwise to keep the cord from unwinding
during transit. This will also provide resistance, allowing
for smooth removal (see below for removal).
Step 1
Keeping the resistance brake on the handle of your
Easy Reel™ Spooler tight, pull the cord completely out.
NOTE: Failure to keep the resistance brake tight when
removing the cord may result in a “backlash” of your cord
causing it to get temporarily stuck in your Easy Reel™ Spooler.
If this happens, simply turn the handle of your spooler to
re-spool the cord while holding the cord with your opposite
hand. This will help tighten the cord around the spool.
Once the cord is tight, engage the resistance brake on the
handle. This will allow you to then easily remove the cord.
R E M OVA L
Step 2
Use your cord as directed by the manufacturer.
INSTRUCTIONS FOR DETACHABLE/HARD WIRED 30/50' AMP CORD:
Resistance Brake
Center Feed
If you have any questions regarding the installation procedure or
have diculty with any of the steps, please give us a call at
574-293-1581 parts@morryde.comor email .
