<變數 1> Contents

Contents

Safety Information ........................................................................................... 2

Specifications ...................................................................................................3

Rear I/O Panel ..................................................................................................6

LAN Port LED Status Table .................................................................................6

Overview of Components ................................................................................7

DIMM Slots ..........................................................................................................8

CPU Socket .........................................................................................................9

PCI_E1~3: PCIe Expansion Slots ......................................................................10

JRGB1: RGB LED connector .............................................................................10

JFP1, JFP2: Front Panel Connectors ...............................................................11

SATA1~6: SATA 6Gb/s Connectors....................................................................11

M2_1: M.2 Slot (Key M) .....................................................................................12

ATX_PWR1, CPU_PWR1: Power Connectors....................................................12

JUSB1, JUSB2: USB 2.0 Connectors ................................................................13

JUSB3, JUSB4: USB 3.1 Gen1 Connectors .......................................................13

JAUD1: Front Audio Connector ......................................................................... 14

JCOM1: Serial Port Connector .........................................................................14

JLPT1: Parallel Port Connector........................................................................14

CPU_FAN1, SYS_FAN1~2: Fan Connectors ......................................................15

JTPM1: TPM Module Connector .......................................................................16

EZ Debug LED ...................................................................................................16

JCI1: Chassis Intrusion Connector ...................................................................17

JBAT1: Clear CMOS (Reset BIOS) Jumper .......................................................17

BIOS Setup ..................................................................................................... 18

Entering BIOS Setup .........................................................................................18

Resetting BIOS ..................................................................................................19

Updating BIOS ...................................................................................................19

Installing OS, Drivers & Utilities ...................................................................20

Installing Windows

10 .....................................................................................20

Installing Drivers ..............................................................................................20

Installing Utilities ..............................................................................................20

Thank you for purchasing the MSI

B365M PRO-VDH

motherboard. This User Guide gives information about

board layout, component overview, BIOS setup and software

installation.

Safety Information

y The components included in this package are prone to damage from electrostatic

discharge (ESD). Please adhere to the following instructions to ensure successful

computer assembly.

y Ensure that all components are securely connected. Loose connections may cause

the computer to not recognize a component or fail to start.

y Hold the motherboard by the edges to avoid touching sensitive components.

y It is recommended to wear an electrostatic discharge (ESD) wrist strap when

handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is

not available, discharge yourself of static electricity by touching another metal object

before handling the motherboard.

y Store the motherboard in an electrostatic shielding container or on an anti-static

pad whenever the motherboard is not installed.

y Before turning on the computer, ensure that there are no loose screws or metal

components on the motherboard or anywhere within the computer case.

y Do not boot the computer before installation is completed. This could cause

permanent damage to the components as well as injury to the user.

y If you need help during any installation step, please consult a certified computer

technician.

y Always turn off the power supply and unplug the power cord from the power outlet

before installing or removing any computer component.

y Keep this user guide for future reference.

y Keep this motherboard away from humidity.

y Make sure that your electrical outlet provides the same voltage as is indicated on

the PSU, before connecting the PSU to the electrical outlet.

y Place the power cord such a way that people can not step on it. Do not place

anything over the power cord.

y All cautions and warnings on the motherboard should be noted.

y If any of the following situations arises, get the motherboard checked by service

personnel:

 Liquid has penetrated into the computer.

 The motherboard has been exposed to moisture.

 The motherboard does not work well or you can not get it work according to

user guide.

 The motherboard has been dropped and damaged.

 The motherboard has obvious sign of breakage.

y Do not leave this motherboard in an environment above 60°C (140°F), it may

damage the motherboard.

Produktspezifikationen

Marke:	MSI
Kategorie:	Objektiv
Modell:	B365M PRO-VDH
Prozessorhersteller:	Intel
WLAN:	Nein
Breite:	226 mm
Tiefe:	185 mm
Mitgelieferte Kabel:	SATA
Anzahl USB 2.0 Anschlüsse:	2
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Warentarifnummer (HS):	84733020
Anzahl HDMI-Anschlüsse:	1
Audio Kanäle:	7.1 Kanäle
RAID Level:	0, 1,5, 10
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	3
Schnellinstallationsanleitung:	Ja
Prozessorsockel:	LGA 1151 (Socket H4)
Anzahl VGA (D-Sub) Anschlüsse:	1
Kompatible Prozessoren:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximale Anzahl an SMP-Prozessoren:	1
Motherboardformfaktor:	micro ATX
Motherboard Chipsatz Familie:	Intel
Motherboard Chipsatz:	Intel B365
Audio-Chip:	Realtek ALC887
Komponente für:	PC
Anzahl der Befestigungsbohrungen:	6
Unterstützte Arbeitsspeicher:	DDR4-SDRAM
Anzahl der Speichersteckplätze:	4
Arbeitsspeicher Typ:	DIMM
Speicherkanäle:	Zweikanalig
Unterstützte Arbeitsspeichergeschwindigkeit:	2666 MHz
RAM-Speicher maximal:	64 GB
Unterstützte Speicherlaufwerk-Schnittstellen:	SATA III
Anzahl der M.2 (M)-Steckplätze:	1
PCI-Express x16 (Gen 3.x)-Anschlüsse:	1
Treiber enthalten:	Ja
Anzahl PS/2 Anschlüsse:	1
Anzahl DVI-D-Anschlüsse:	1
HDMI-Version:	1.4
ATX Stromstecker (24-pol.):	Ja
12-V-Stromanschluss:	Ja
SATA III Anschlüsse:	6
Anzahl USB 2.0 Schnittstellen:	2
CPU Ventilatorstecker:	Ja
Zahl der Chassisventilatorstecker:	1
Front Panel Audiostecker:	Ja
Frontpanel-Stecker:	Ja
Chassis Intrusion Stecker:	Ja
Serielle Port-Headers:	1
USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse:	2
Ethernet Schnittstellen Typ:	Gigabit Ethernet
LAN-Controller:	Realtek RTL8111H
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ C:	1
Unbuffered Speicher:	Ja
PCI-Express x1 (Gen 3.x)-Anschlüsse:	2
Clear-CMOS-Taste:	Ja
Ethernet/LAN:	Ja
