Seite 1/167

<變數 1> Contents

Contents

Safety Information ........................................................................................... 2

Specifications ...................................................................................................3

Package contents ............................................................................................5

Rear I/O Panel .................................................................................................6

LAN Port LED Status Table .................................................................................6

Overview of Components ................................................................................7

CPU Socket .........................................................................................................8

DIMM Slots ..........................................................................................................9

PCI_E1~3: PCIe Expansion Slots ......................................................................10

JFP1, JFP2: Front Panel Connectors ...............................................................11

SATA1~4: SATA 6Gb/s Connectors....................................................................11

M2_1: M.2 Slot (Key M) .....................................................................................12

ATX_PWR1, CPU_PWR1: Power Connectors....................................................12

JUSB1~2: USB 2.0 Connectors .........................................................................13

JUSB3: USB 3.1 Gen1 Connector .....................................................................13

CPU_FAN1, SYS_FAN1~2: Fan Connectors ......................................................14

JTPM1: TPM Module Connector .......................................................................15

JCI1: Chassis Intrusion Connector ...................................................................15

JAUD1: Front Audio Connector ......................................................................... 16

JCOM1: Serial Port Connector .........................................................................16

JLPT1: Parallel Port Connector........................................................................16

JBAT1: Clear CMOS (Reset BIOS) Jumper .......................................................17

EZ Debug LED: Debug LED indicators ..............................................................17

JRGB1: RGB LED strip connector .....................................................................17

BIOS Setup ..................................................................................................... 18

Entering BIOS Setup .........................................................................................18

Resetting BIOS ..................................................................................................19

Updating BIOS ...................................................................................................19

Software Description .....................................................................................20

Installing Windows

10 .....................................................................................20

Installing Drivers ..............................................................................................20

Installing Utilities ..............................................................................................20

Thank you for purchasing the MSI

B450M PRO-VDH V2

motherboard. This User Guide gives information about

board layout, component overview, BIOS setup and software

installation.

Safety Information

y The components included in this package are prone to damage from electrostatic

discharge (ESD). Please adhere to the following instructions to ensure successful

computer assembly.

y Ensure that all components are securely connected. Loose connections may cause

the computer to not recognize a component or fail to start.

y Hold the motherboard by the edges to avoid touching sensitive components.

y It is recommended to wear an electrostatic discharge (ESD) wrist strap when

handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is

not available, discharge yourself of static electricity by touching another metal object

before handling the motherboard.

y Store the motherboard in an electrostatic shielding container or on an anti-static

pad whenever the motherboard is not installed.

y Before turning on the computer, ensure that there are no loose screws or metal

components on the motherboard or anywhere within the computer case.

y Do not boot the computer before installation is completed. This could cause

permanent damage to the components as well as injury to the user.

y If you need help during any installation step, please consult a certified computer

technician.

y Always turn off the power supply and unplug the power cord from the power outlet

before installing or removing any computer component.

y Keep this user guide for future reference.

y Keep this motherboard away from humidity.

y Make sure that your electrical outlet provides the same voltage as is indicated on

the PSU, before connecting the PSU to the electrical outlet.

y Place the power cord such a way that people can not step on it. Do not place

anything over the power cord.

y All cautions and warnings on the motherboard should be noted.

y If any of the following situations arises, get the motherboard checked by service

personnel:

 Liquid has penetrated into the computer.

 The motherboard has been exposed to moisture.

 The motherboard does not work well or you can not get it work according to

user guide.

 The motherboard has been dropped and damaged.

 The motherboard has obvious sign of breakage.

y Do not leave this motherboard in an environment above 60°C (140°F), it may

damage the motherboard.

Produktspezifikationen

Marke:	MSI
Kategorie:	Wandsteckdose
Modell:	B450M PRO-VDH V2
Prozessorhersteller:	AMD
Breite:	244 mm
Tiefe:	244 mm
Mitgelieferte Kabel:	SATA
Energiequelle:	ATX
Kopfhörerausgänge:	3
Anzahl USB 2.0 Anschlüsse:	2
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Betriebsanleitung:	Ja
Anzahl HDMI-Anschlüsse:	1
Audio Kanäle:	7.1 Kanäle
Unterstützt Windows-Betriebssysteme:	Windows 10, Windows 10 x64, Windows 7, Windows 7 x64
Mikrofon-Eingang:	Ja
Unterstützte Speicherlaufwerke:	HDD & SSD
RAID Level:	0, 1,10
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	4
Schnellinstallationsanleitung:	Ja
Prozessorsockel:	Sockel AM4
Anzahl VGA (D-Sub) Anschlüsse:	1
Kompatible Prozessoren:	AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Motherboardformfaktor:	ATX
Motherboard Chipsatz Familie:	AMD
Motherboard Chipsatz:	AMD B450
Audio-Chip:	Realtek ALC892
Komponente für:	PC
Anzahl der Befestigungsbohrungen:	8
Unterstützte Arbeitsspeicher:	DDR4-SDRAM
Anzahl der Speichersteckplätze:	4
Arbeitsspeicher Typ:	DIMM
Speicherkanäle:	Zweikanalig
Unterstützte Arbeitsspeichergeschwindigkeit:	1866,2133,2400,2667,2800,2933,3000,3066,3200,3466 MHz
RAM-Speicher maximal:	64 GB
Anzahl der M.2 (M)-Steckplätze:	1
PCI-Express x16 (Gen 3.x)-Anschlüsse:	1
PCI-Express x1 (Gen 2.x)-Anschlüsse:	2
DirectX-Version:	12.0
Maximale Auflösung:	4096 x 2160 Pixel
Treiber enthalten:	Ja
Anzahl PS/2 Anschlüsse:	1
Anzahl DVI-D-Anschlüsse:	1
ATX Stromstecker (24-pol.):	Ja
SATA III Anschlüsse:	4
Anzahl USB 2.0 Schnittstellen:	4
CPU Ventilatorstecker:	Ja
Zahl der Chassisventilatorstecker:	2
Front Panel Audiostecker:	Ja
Frontpanel-Stecker:	Ja
Chassis Intrusion Stecker:	Ja
Serielle Port-Headers:	1
RGB-LED-Stiftleiste:	Ja
USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse:	2
Clear CMOS-Jumper:	Ja
Ethernet Schnittstellen Typ:	Fast Ethernet, Gigabit Ethernet
LAN-Controller:	Realtek 8111H
Grafikkarte-Familie:	AMD, Intel, NVIDIA
Diskreter Grafik support:	Ja
Parallel Verbinder:	Ja
Power Fan Connector:	Ja
Maximale unterstützte Anzahl der HDD:	4
EPS Stromstecker (8-pin):	Ja
Ethernet/LAN:	Ja
TPM-Anschluss:	Ja
