2321 Rue Cohen, Montreal, QC, H4R 2N7
Tel:(514) 905-0588 Fax: (514) 905-0589
Toll Free (North America): (877)689-5228
Specifications
Environment
HDMI 1.3aand DVI-D
Devices
DVD, plasma, projectors, monitors, TV, PC, laptops, servers
supporting HDMI.
Transmission
Unidirectional. Transparent to the user
Bandwidth
340 MHz
Signals
HDMI 1.3a protocol
Copy Protection
Do NOT Support HDCP protected content.
Connectors
TX Side: One (1) HDMI receptacle.
One (1) LC Fiber connector (output only).
One (1) 2.1mm power connector.
T
X Side: One (1) HDMI receptacle.
One (1) LC Fiber connector (input only).
One (1) 2.1mm power connector.
Note: HDMI and Fiber cables not included.
Maximum Distance
Based on a maximum
length of 6.6 ft (2 m) of
HDMI cable per end.
480i/p: 984ft (300m)
720p, 1080i: 984ft (300m)
1080p 8-bit: 984ft (300m)
1080p 12-bit deep-color: 984ft (300m)
4K @ 24,25, 30Hz 984ft (300m)
Cable
One (1) Multimode fiber 50/125 μm OM3 cable required
Power Supply
Two (2) 110-240V/5VDC power supply with interchangeable blades
Power Consumption
Transmitter: 1.35 Watt Receiver: 1.15Watt
Temperature
Operating: 0° to 55°C Storage: -20° to 85°C
Humidity: Up to 95% non-condensing
Enclosure
Aluminium
Dimensions
3.27” x 1.97” x 0.75” (83x 50x 19 mm)
Weight
1.0 lb (0.45kg)
Compliance
Regulatory: FCCClass A, CE, RoHS
Warranty
2 years
Order Information
500462 HDMI Optical Isolator Kit
HDM
I Optical Isolator Kit
500462
Quick Installation Guide
Overview
The HDMI Optical Isolator (500462) allows HDMI equipment to be completely isolated
and connected up to 984ft (300m), while allowing a unidirectional communication (with
no return signaling) via one (1) LC 50/125 μm
OM3 multimode fiber cable in a point-to-
point configurationat 1080p resolution.
TheHDMI Optical Isolator
establishes ahigh separation between the source computer
and the displaydevices preventing any potential leakage between the source and the
peripheral equipment; removing the vulnerability of shared display equipment to cyber-
attacks.
The kit comes with one (1) Transmitter,one (1) Receiver and two (2) power supply.
Applications
Commercial and residential AV systems, classroom projector systems, digital signage,
boardroom systems, collaborative PC systems, and medical information systems, high
security applications.
Key Features
•Complete optical isolation between source and display.
•Unidirectional HDMI communication.
•No return signaling.
•Fixed EDID configuration.
•Up to 984ft (300m) @ 1080p via one (1) LC multimode fiber.
© MuxLab Inc.94-000776-A SE-000776-A
Produktspezifikationen
| Marke: | MuxLab |
| Kategorie: | Audio/Video-Konverter |
| Modell: | 500462 |
