© MuxLab Inc. 2020 -000940-A -09-A94SE0040

2321 Rue Cohen, Montreal, Quebec, Canada. H4R 2N7

Tel: (514) 9-0588 Fax: (514) 905-0589 05

Toll Free (North America): (877) 689-5228

E-mail: URL: www.muxlab.com [email protected]

Specications

Environment

HDMI 1.3

Devices

Computers, Game ConsolesTV Set Top Box, es and other HDMI

sources

Transmission

Transparent to the user

Bandwidth

148 MHz

Signals

HDMI 1.3 protocol and HDCP 1.4

Connectors

Cables not included.

Two (2) HDMI receptacles.

One (1) USB Type A Connector.

Two (2) 3.5mm jacks for Microphone and Headphone.

Supported HDMI

Resolution

720x480p(60), 720x576p(50), 1280x720p(50), 1280x(60), 720p

1920x1080i(50),1920x1080i(60), 1920x1080p(24),

1920x1080p(25),1920x(30), 1920x1080p(50), 1920x1080p1080p(60)

Recording Resolution

720x480p(60), 720x576p(50), 1280x720p(50), 1280x(60), 720p

1920x1080i(50), 1920x1080i(60), 1920x1080p(24), 1920x1080p(25),

1920x1080p(30)

Audio Signal

Up to16bit 48KHz dual channel (via HDMI input interface) and 3.5mm

analog audio input

Recording Format

Video: MP4, Audio: AAC Stereo

Coding Format

H.264 (Video) and AAC (Audio)

Recording Quality

Highest: 16Mbps@/30 1080p

Maximum Storage

Capacity

USB Flash Drive (≤64G), Mobile Hard Disk (≤2TB)

Power Supply

One (1) 110-240V/VDC power supplies 12

Temperature

Operating: 0° to 40°C Storage: -20° to 85°C

Humidity: Up to 95% non-condensing

Enclosure

Metal

Dimensions

4.8” x ” x 2.90.6” (12.20 x 7. 1.5 cm) 37x

Weight

0.6 lbs (0. kg) 27

Compliance

Regulatory: FCC, CE, RoHS Flammability: 94V0

Warranty

1 year

Order Information

15 Video Capture & Recorder 0012

Video Capture and Recorder (1005) 12

Quick Installation Guide

Overview

The Video Capture and Recorder (100512) allows the user to record from HDMI video

sources to a USB Flash Drive or Removable Hard Drive. High denition video

recording does not require a computer and can be recorded from a variety of HDMI

source equipment like Computers, Game ConsolesTV S Top Band other , etoxes,

sources.

The maximum input resolution supported is 1080p/60 and the maximum recording

resolution is 1080p/30. The unit supports microphone mixing, recording and a

headphone output.

Operation is as easy as placing the device between an HDMI source and an optional

display and simply pressing a button to start recording.

Applications

Applications include home video recording, video game capture, security and trac

recordingeducation/classroom systems, and medical systems. ,

Installation

1.Identify the connectors on the product as indicated on the product labels.

2.Connect the source to the HDMI Input of the Recorder.

3.Connect the Display to the HDMI Output of the Recorder

4.Connect a microphone to the 3.5mm Microphone input of the recorder. The

microphone audio will be mixed with the HDMI Audio.

5.Connect an Audio Headphone to the 3.5mm Headset output of the recorder.

6.Insert a USB Flash Drive or removable hard drive to the USB Connector of the

Recorder. e recorder supports FAT32 and NTFS FormatsIf the drive is Th.
