Neff B6ACM7AG7A Bedienungsanleitung
Lies die bedienungsanleitung für Neff B6ACM7AG7A (3 Seiten) kostenlos online; sie gehört zur Kategorie Backöfen. Dieses Handbuch wurde von 4 Personen als hilfreich bewertet und erhielt im Schnitt 4.6 Sterne aus 2.5 Bewertungen. Hast du eine Frage zu Neff B6ACM7AG7A oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage
Seite 1/3
1/3
N 50, Built-in
ov
en, 60 x 60 cm, G
r
ap
h
it
e-Grey
B6ACM7AG7A
Included accessories
1 x enamel baking tray, 1 x combination grid, 1 x universal pan
Optional accessories
Z11AB15A0 : , Z11AU15A0 : , Z11CR10X0 : , Z11GU20X0 : ,
Z11TI15X0 : , Z12CB10A0 : Baking tray, anthracite enamelled ,
Z12CL10A0 : , Z12CM10A0 : Moussaka pan, anthracite enamelled ,
Z12CN10A0 : , Z12CP10A0 : , Z12CU10A0 : Multipurpose pan,
anthracite enamelled , Z1365WX0 : Wireless food thermometer ,
Z1608BX0 : Full ext rails, level independent , Z1650BE0 : Half tray ,
Z1655CA0 : Air Fry & Grill tray , Z1913X0 : Baking Stone
Joyful interaction: unrestricted access thanks to the retracting
Hide® door, Meatprobe and Pyrolytic Self-Cleaning.
√ Hide® – The unique fully disappearing oven door.
√ Home Connect - Control your oven via the App.
√ Singlepoint Meatprobe - keeps one eye constantly on the oven
temperature
√ Pyrolytic Self-Cleaning with Easy Clean: The best duo for optimal
cleaning.
√ LCD-Display – simple, straightforward with large characters for
clear reading
Features
Technical Data
Gross weight : 42.3 kg
Built-in / Free-standing : Built-in
Cleaning : Pyrolytic+Hydrolytic
Required niche size for installation (HxWxD) : 585-595 x 560-568 x
550 mm
Dimensions (HxWxD) : 595x594x548 mm
Dimensions of the packed product (HxWxD) : 675 x 660 x 690 mm
Control Panel Material : Glass
Door Material : Glass
Net weight : 39.6 kg
Usable volume of cavity : 71 l
Heating functions : Bottom heat, Bread Baking Setting, Conventional
heat, Full width grill, Hot Air, Hot air gentle, Hot Air grilling, Pizza
setting
Number of interior lights : 1
Length electrical supply cord : 120.0 cm
Interior Lights - cavity 1 : 1
Telescopic Racking System : Accessory
Included accessories : 1 x enamel baking tray, 1 x combination grid, 1
x universal pan
Broil Element Wattages cavity 1 : 2800 W
Convection Element Wattages cavity 1 : 2200 W
Energy efficiency rating : A+
Energy consumption per cycle conventional (2010/30/EC) : 0.94
kWh/cycle
Energy consumption per cycle forced air convection (2010/30/EC) :
0.69 kWh/cycle
Energy efficiency index (2010/30/EC) : 81.2 %
Connection Rating : 3600 W
Fuse protection : 16 A
Voltage : 220-240 V
Frequency : 50; 60 Hz
Plug type : no plug
Energy input : Electric
Required cutout/niche size for installation (in) : x
Dimensions of the packed product : 26.57 x 25.98 x 27.16
Net weight : 87.000 lbs
Gross weight : 93.000 lbs
Length electrical supply cord : 120.0 cm
Net weight : 39.6 kg
'!2E20AE-cibedg!
2/3
N 50, Built-in
ov
en, 60 x 60 cm, G
r
ap
h
it
e-Grey
B6ACM7AG7A
Features
Heating Functions
●
Oven with 8heating methods:
Bread Baking, Full surface grill, CircoTherm® gentle, CircoTherm®,
Top/bottom heating, Pizza Setting, Bottom heating, Circo-roasting
●
Heating methods only via Home Connect App: air fry, let rest,
preheating
●
Temperature range 30 °C - 275 °C
●
Cavity volume: 71 net usable litres
Racks and Rails
●
Number of shelf levels: 4
●
Large capacity oven with shelf supports, Telescopic shelf rails
available as optional accessory
Design
●
Graphite-Grey Edition
●
Rotary Control, Retractable control knobs
●
Cavity inner surface: enamel
Cleaning
●
Pyrolytic self cleaning
●
EasyClean® program
●
Full glass inner door - safer touch door
Convenience
●
White LCD display
●
Electronic clock with start / stop function
●
Automatic temperature proposal, automatic start, Actual
temperature display, Optical temperature control, Meat probe
function
●
Hide®, the fully retracting oven door
●
Bar handle
●
Single-point meat probe
●
Rapid heat-up
●
Halogen lighting
●
Cooling fan
●
Stainless-steel fan
●
Info button
●
HomeConnect
Accessories
●
1 x combination grid, 1 x universal pan, 1 x enamel baking tray
Safety Features
●
Maximum door temperature 30° C
●
Quadruple glazed CoolTouch door
●
Automatic door lock during pyrolysis, Individual adjustable child
lock, Safety switch off, Residual heat indicator, Door contact
switch
Technical Information
●
Length of mains cable: 120 cm
●
Nominal voltage: 220 - 240 V
●
Total connected load electric: 3.6 KW
Dimensions
●
Appliance dimensions (HxWxD): 595 mm x 594 mm x 548 mm
●
Installation dimensions (HxWxD): 585 mm - 595 mm x 560 mm -
568 mm x 550 mm
●
Please reference the built-in dimensions provided in the
installation drawing
●
We recommend you to choose complementary products within
N50, in order to assure an optimal design combination of your
Built-In appliances.
