N 90, INductIoN cooktop, 80 cm, Flex desIgN
V68YYx4c0
1 x Slider for unducted recirculation, 1 x Clean Air Plus odor filter
Z1365WX0 Wireless food thermometer, Z811DU0 Acoustics Filter,
Z821PD1 Plinth Diffusor, Z821VR1 Clean Air Plus odor filter
(replacement), Z861KE1 Exhaust kit, Z861KR0 Recirculation kit 2
L-bow (70cm), Z861KR1 Recirculation kit S and L-bow (60cm),
Z861KR2 Recirculation kit 1x L-bow, Z861SB1 90° flat duct bend
horizontal, Z861SB2 90° flat duct L vertical, Z861SB3 90° flat duct
M vertical, Z861SB4 90° flat duct S vertical, Z861SI0 Adapter
round-flat, Z861SI1 90° Adapter round-flat, Z861SM1 Straight tube
500mm, Z861SM2 Straight tube 1000mm, Z861SS1 Connector
sleeve (female), Z861SS2 Flex sleeve (female), Z9301CO10
Connecting strip, Z9401FF0 Flex Pan, large, Z9401TY0 Teppan
Yaki, Z9403FF0 Flex Pan set, 3 pcs., Z9404FF0 Flex Pan set, 4 pcs.,
Z9404SE0 4 pieces Set, Z9406SE0 6 pieces Set, Z9410ES0
Espresso maker 4 cups, Z9410X1 Stainless Steel roaster with glas
lid, Z9415X1 Steaming Rack for Stainless Steel roaste, Z9416X2
Griddle Plate, Z9417X2 Teppan Yaki (large), Z9424CF0 Fry pan,
coated 24cm Ø, Z9428CF0 Fry pan, coated 28cm Ø, Z9428FE0
Iron pan Ø 18 / 28 cm, Z943SE0 Set of 2 pots and 1 pan,
Z9801TWAY0 Twist Pad Flex, Anthracite Grey, Z9801TWBY0 Twist
Pad Flex, Brushed Bronze, Z9801TWDY0 Twist Pad Flex, Deep
Black, Z9801TWMY0 Twist Pad Flex, Metallic Silver, Z9802PFAY0
Flex Design trims hob Anthracite Grey, Z9802PFBY0 Flex Design
trims hob, Brushed Bronze, Z9802PFDY0 Flex Design trims hob
Deep Black, Z9802PFMY0 Flex Design trims hob Metallic Silver
Z9301CO10 Connecting strip
Z9301CPAY0 Flex Design conn. trim hob+hob A.Grey
Z9301CPBY0 Flex Design conn. trim hob+hob B.Bronze
Z9301CPDY0 Flex Design conn. trim hob+hob D.Black
Z9301CPMY0 Flex Design conn. trim hob+hob M.Silver
Z9302GLAY0 Flex Design seaml. glassdr+hob A.Grey
Z9302GLMY0 Flex Design seaml. glassdr+hob M.Silver
Z9802PFAY0 Flex Design trims hob Anthracite Grey
Z9802PFBY0 Flex Design trims hob, Brushed Bronze
Z9802PFDY0 Flex Design trims hob Deep Black
This induction cooktop with integrated ventilation combines two
appliances in one for a clear view while cooking.
√ Twist Pad Flex® - An easy to spin dial for effortless control of
your cooktop.
√ Flex Design - Personalise your cooktop with separately
selectable Twist Pad Flex® and frame elements.
√ Flex Induction - Your cooktop detects and heats your individual
cookware.
√ Intuitive Flex Zones - Place your cookware! Size, shape and
position are recognised instantly.
√ Automatic Air Sensor: Constantly adjusts the extraction rate to
match the situation in the kitchen.
Product name/family: .................................. Cooking zone ceramic
Built-in / Free-standing: ...................................................... Built-in
Energy input: ......................................................................Electric
Min. required niche size for installation (HxWxD): 223 x 750-750 x
490-500 mm
Width of the appliance: .....................................................834 mm
Dimensions (HxWxD): ....................................... 223x834x527 mm
Dimensions of the packed product (HxWxD): . 430 x 940 x 660 mm
Net weight: ........................................................................ 25.4 kg
Gross weight: .....................................................................31.8 kg
Residual heat indicator: .................................................... separate
Location of control panel: ......................................................Front
Basic surface material: ...................................................... Ceramic
Color of surface: .................................................................... Black
Color of frame: ............................... Choose from Brushed Bronze,
Anthracite Grey, Deep Black or Metallic Silver
Length electrical supply cord: .......................................... 110.0 cm
Sealed Burners: ......................................................................... No
Heating with booster: ................................................................ All
Power of 2nd heating element (kW): ...................................3.3 kW
Maximum output air extraction: .......................................500 m³/h
Boost position output recirculating: ..............................595.0 m³/h
Maximum output recirculating air: ................................... 499 m³/h
Boost position air extraction: ...........................................622 m³/h
Noise level: .......................................................... 69 dB(A) re 1pW
Odour filter: .............................................................................. No
Voltage: .......................................................... 220-240/380-415 V
Frequency: .......................................................................50-60 Hz
Main colour of product: ..........................................................Black
Included accessories: ................................. 1 x Slider for unducted
recirculation, 1 x Clean Air Plus odor filter
1 /
Z9802PFMY0 Flex Design trims hob Metallic Silver
2 /
Produktspezifikationen
| Marke: | Neff |
| Kategorie: | Herd |
| Modell: | V68YYX4C1-AG |
