www.newgy.com

CONTACT US

Newgy Industries, Inc. • Tennessee, USA

800-556-3949 • 615-452-6470

newgy@newgy.com • www.newgy.com

© Newgy Industries, Inc., 2018 All rights reserved.

LIMITED 1 YEAR WARRANTY

*

Manufacturer warrants to the original retail purchaser this product to be

free from defects in material and workmanship for a period of 1 year

from date of purchase.

Should this product become defective due to material or workmanship

during the warranty period, contact our Customer Service Department

describing the defect. Always provide your serial number. We will

provide you with return authorization and shipping instructions. If you

are asked to return the product, pack it securely and ship it PREPAID.

If defective as provided by the terms of this warranty, we will, at our

option, repair or replace the product and return it prepaid to a

Contiguous U.S. address (other areas carry a shipping charge).

This warranty is not transferable and does not cover normal wear and

tear, or damage caused by improper handling, installation, or use. This

warranty is void if the product is in any way abused, damaged, or

modified from its original state.

This warranty gives you specific legal rights, and you may have other

rights that may vary from state to state.

*

Warranty and service valid only in territory of original sale.

For questions or troubleshooting, refer to this robot’s Owner’s Manual at www.newgy.com.

V2 6.25.18

12

INTRODUCTORY

INTERMEDIATE

BEGINNER

ADVANCED

BONUS

MY DRILL LIBRARY

SET-UP ROBOT

OWNER’S MANUAL

HELP

0.0.0/000

Drill Mode

STANDARD

PRECISION

RIGHT HANDED

Control Mode

Set-Up Robot

Your robot’s

head should be

in an upright

position.

If it isn’t, rotate

the robot head

by touching the

red arrows.

DONE

6”

6”

Ball

Dam

Set-Up Robot

THROW TEST BALL

Ball should

land centered

on table.

Place your Ball

Dam on the table

vertically from the

edge of the table.

It is about 9 inches

tall. Your ball should

land at the tip of the

Ball Dam and in the

center of the table.

If it doesn’t, adjust

its location using the

red arrows.

DONE

3

1

2

3A

IMPORTANT - Calibrate Your Robot

The calibration step is

required

to make sure your

robot functions properly. This step will ensure all

drills perform correctly.

1.

To start the calibration process, press the gray SET-UP ROBOT

button on the bottom left of your screen (see image 1).

2. Adjust your robots head angle. The LED lights on your

robot should be as close to verticle as possible (see image 2).

Once you are finished with this step, press done.

3. This step is important to make sure all robot functions

including drills run correctly. Place your robot’s ball

dam at the center edge of player’s side of the table

(see image 3). Use the arrows on the App to adjust

placement of the ball. Adjust the throw until the ball

lands in a roughly 6” area in front of the ball dam

(see image 3A below). Once you have the head

angle and oscillation angle set it is helpful to throw a

couple more balls to make sure of placement. Once

this step is complete press done on your App to return

to the home screen.

You are now ready to begin using your

Newgy Robo-Pong 3050XL robot!

IMPORTANT

You must calibrate your

new robot before using

the first time to function

properly. See back of

this guide for

instructions.
