Seite 1/2
1 HDMI IN: Connect to HDMI Source
2 ACTIVE: Signal LED Indicator
Ocean Matrix
www.oceanmatrix.com
1 HDBaseT OUT: HDBaseT Output Port
2 DC-24V: Plug in AC Power Supply
3 RS-232: Transmit RS-232 Commands
4 IR IN/OUT: Connect IR Input or Output
5 5V OUT: For External IR RX
4 5
1
2
3
1 2
OMX-01HMBT0003-T HDBaseT 4K HDMI
1-Gang Wall Plate Transmitter
INSTALLATION & SPECIFICATIONS
Front Rear
Typical Application
Source Computer
RS232 HDMI Matrix
Display
Control Equipment
Power Supply
RX
IR
Extender
IR
Blaster
NOTE: Does not support KVM/USB Functions of OMX-01HMBT0003-R Receiver
SAFETY PRECAUTIONS
To prevent fire or shock hazard, do not expose this equipment to dust or high humidity. Do not use in an
unprotected outdoor installation or in areas classified as overly damp or wet.
The installation temperature should be kept between 32°F to 140°F (0°C to 60°C). Avoid direct sunlight exposure or extreme
changes of temperature over a short period of time.
Do not place the unit on an unstable base and avoid heavy impact.
Proper ventilation is required for permanent installation. Do not block or cover enclosure openings as they protect the unit from
overheating.
Prior to cleaning, turn the power off and unplug the unit from all connections. Use a damp cloth. Do not use liquid or aerosol
cleaners.
Do not overload outlets and extension cords as this may result in a risk of fire or electric shock.
Enclosure entry is dangerous. Never push objects of any kind, including liquids, through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or electric shock.
Do not open or service this unit yourself as opening or removing covers may expose you to dangerous voltage and other hazards.
There are no user-serviceable parts inside the unit. If the unit authorized dealer, or authorized requires service contact your repair
service company.
Ocean Matrix
812 Kings Highway • Saugerties, NY 12477
FCC Caution
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Class A Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to the user will be required to correct the cause harmful interference in which case
interference at his own expense.
Federal Communications Commission (FCC) Compliance Notices
FEATURES
Extends Two-Way IR & RS232 Pass Through
Transmission Distance: 1080P Up to 230 Feet,
4K up to 131 Feet
Up to 7.1 Channels HD Audio
Two-Way 24V PoC
Black Metal Enclosure with White Front Panel
Includes (2) 3Pin RS232 & (2) 2Pin RS232
Connectors
CE, FCC Certified
SPECIFICATIONS
Compliance HMDI 2.0b, HDCP2.2, HDCP 1.4
Video Bandwidth 18Gbps
HDMI Video Resolutions
up to 4K2K@50/60Hz(YUV4:4:4), 4K2K@30Hz,
1080P@120Hz,1080P 3D@60Hz
Color Space/Color Depth RGB, YCbCr 4:4:4, YCbCr 4:2:2 / 10-bit, 12-bit
HDMI Audio Formats
LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby
Digital+, Dolby TrueHD, DTS-HD Master Audio,
Dolby Atmos, DTS:X
Optical Audio Formats
LPCM 2CH, LPCM 5.1, Dolby Digital 2/5.1CH, DTS
2/5.1CH
Power Consumption 9W
Dimensions 4.1 x 1.8 x 1.2 in
Weight 5 oz
