A  LEARNING

Your One For All remote control can learn any function from any other working remote

control. This is a quick and easy one-time setup that will allow you to control one or more

of your home entertainment devices, and even combine multiple devices in one easy to

use remote control – for example you could teach the volume keys to control your Sound

Bar, the TV Power and AV keys to control your TV, and the rest of the keys to control your

Set Top Box (Satellite, Cable or Freeview Receiver).

To do this, rstly make sure you have all your original remote controls to hand, and

that they have working batteries in. To learn functions, the original remote should be

approximately 3cm from the OFA remote, pointing towards it as shown below:

1. Hold down AV and Exit until the red LED blinks twice.

2. Press and release the key you want to learn a function onto (for

example the TV Power key) – The red LED will blink continuously.

3. Press and release* the corresponding key on the original remote,

for example Power.

4. The red LED will blink twice to indicate the key has been learned

correctly.

5. Repeat steps 2 and 3 for each key you want to learn – remember

you can learn from multiple remotes, but only one function per key.

6. When you learned all the functions you require, press and hold the

OK key until the red LED blinks twice.

Hints

• If the red LED shows one long blink at step 4, the function was not learned correctly,

please try again from step 2.

• If you nd one or more keys don’t work properly after set up, you can re-enter the

learning mode at any time by repeating the procedure from step 1.

• To delete a learned function, hold down Guide and Menu until the red LED blinks

twice, and press the key to delete twice.

• If one or more of your original remotes aren’t working, you can still set up the One For

All remote by SimpleSet (B) or Code Set Up (C).

* Some remotes send commands dierently. If you nd a function cannot be learned, try holding down the key on

the original remote instead of pressing and releasing.

B  SIMPLESET

To set up your device:

1. Turn on your device (not on standby) and point the OFA remote towards it.

2.To set up:

TV

hold down TV Power and STB Power

until the red LED blinks twice.

STB

(CABLE, SATELLITE, FREEVIEW, DVB-T) -

hold down Volume + and Channel +

until the red LED blinks twice.

AUDIO

(RECEIVER, SOUND BAR) -

hold down Volume – and Channel –

until the red LED blinks twice.

3.Hold down the digit for your brand and device as listed left (e.g. 6 for Samsung TV).

4.The remote will send Power every 3 seconds until your device switches o.

5.As soon as your device switches o, release the digit.

6.The red LED will blink twice and the remote should now operate your device.

• If you nd one or more keys do not work as you expect, start again at step 2 – the

remote will start with the next code in the memory.

• If you set up a Set Top Box and then an Audio device, to turn the Audio device back on

hold the STB Power key for 3 seconds – the key will send STB Power and then Audio

Power.

C  SET UP BY CODE

If your brand is not listed in section B, you can set up your device by trying codes

individually. To do this:

1. Turn on your device (not on standby).

2. Locate the brand of your device in the code list (pages 77 - 93). Codes are listed by

Device Type and Brand.

3.To set up:

TV

hold down TV Power and STB Power

until the red LED blinks twice.

STB

(CABLE, SATELLITE, FREEVIEW, DVB-T) -

hold down Volume + and Channel +

until the red LED blinks twice.

AUDIO

(RECEIVER, SOUND BAR) -

hold down Volume – and Channel –

until the red LED blinks twice.

4.Enter the rst 4 digit code listed for your brand (e.g. 0556 for Bennett).

5.The red LED will blink twice.

6.Now aim the remote towards your device and press the Power (or Mute*) key.

7. If the device turns o (or mutes*), your remote is ready to use. If not, repeat steps 3-6

with the next code in the list.

* If you have already set up a Set Top Box and you are setting up Audio as well, please try the Mute key during step 6.

If the brand of your device is not listed and you cannot learn from the original remote,

please proceed to section C – Set Up By Code

Thank you for purchasing the One For All Zapper+.

The remote features the most commonly used keys for control of your home entertain-

ment devices, which can be customised using the handy learning feature to perform

exactly the way you need them to.

You could for example just learn the volume, power and channels of your TV in the

kitchen, or combine the control of your TV, Set Top Box and even Sound Bar in the living

room. There are also 2 Power keys for combining more than one device together on a

single remote.

B  SIMPLESET

If the brand of your device is listed below, you can also set up your device using the One

For All SimpleSet system:

TV

1 Bush

2 Grundig

3 LG

4 Panasonic

5 Philips

6 Samsung

7 Sharp

8 Sony

9 Thomson, TCL

0 Toshiba

Set Top Box (Satellite, Cable, Freeview/DVB-T)

1 BSkyB / Sky Ireland / Orange

2 Canal+ / CanalSat / Digital+

3 Dream Multimedia / TechniSat

4 DStv / Multichoice / Foxtel / Sky New Zealand

5 freebox / Tricolor TV / Vu+

6 Humax

7 Samsung

8 Sky Italia / SFR / Neuf TV

9 Sky Deutschland / Sky Österreich / T-Home / Deutsche Telekom

0 UPC / Cablecom / UPC Direct / Virgin Media

Audio Sound Bars, AV Receivers etc

1 Bose

2 Denon

3 LG

4 Marantz / Philips

5 Onkyo

6 Panasonic / Technics

7 Pioneer

8 Samsung

9 Sony

0 Yamaha

Your One For All Zapper+ can operate up to three devices. If you only set up one device, all

keys will operate that device.

If you set a TV and Set Top Box, most keys will operate the Set Top Box, with the exception

of the TV Power Key, the Volume Up, Down and Mute, and the AV key.

If you set up a TV, Set Top Box and an Audio device such as a sound bar, the Volume Up,

Down and Mute keys will control your Audio device. Also if you hold down the Set Top Box

Power key for three seconds it will rst send Power for the Set Top Box, and then for the

Audio Device.

As the AV key is intended to select the input on your TV and most TVs use a menu to select

from a list of inputs, when the AV key is pressed and a TV and STB are set up, the Menu Up,

Down, Left, Right and OK keys temporarily control the TV. If the OK key is pressed, or no

key is pressed for ten seconds, these keys will revert to controlling your Set Top Box.

HOW TO SET UP YOUR REMOTEHOW TO SET UP YOUR REMOTEHOW TO SET UP YOUR REMOTEHOW TO SET UP YOUR REMOTE

www.ofa.com/urc6820

URC 6820

ENGLISHSIMPLE SET UP GUIDE

DEUTSCHESCHNELLANLEITUNG

BITTE UMDREHEN

facebook.com/ @oneforall.worldwide linkedin.com/ youtube.com/

oneforallworldwide company/one-for-all-worldwide/ user/oneforallproducts

Connect with us

WELCOME, PREPARE YOUR

REMOTE FOR INSTALLATION

Open the battery door.

Insert 2 AAA batteries.

CAUTION:

Risk of explosion if battery

is replaced by an incorrect

type. Use quality Alkaline

batteries.

PRODUCT DISPOSAL EUROPEAN DIRECTIVE 2012/19/EU

The crossed out wheeled bin symbol on this product ensures

that this product is manufactured using high quality compo-

nents that can be recycled and reused according European

Directive 2012/19/EU. Please do not dispose of this product

with your normal household waste, refer to local regulations

for the proper collection or disposal of electrical and electronic

products. This will help this will help in preventing negative

eects on the environment and/or human health.

BATTERY DISPOSAL EUROPEAN DIRECTIVE 2006/66/EC

Please do not dispose of your batteries with your normal household waste,

refer to local regulations for the proper collection or disposal. This will help

preventing potential negative eects on the environment and/or human

health.

GUARANTEE TERMS AND CONDITIONSUNIVERSAL ELECTRONICS warrants

to the original purchaser that this product will be free from defects in materials

and workmanship under normal and correct use for a period of 3 years from the

date of original purchase. This product will be repaired or if necessary, replaced

free of charge if it has been proven to be defective within the 3 year warranty

period. The forwarding costs are on the account of the owner; the costs of

returning the product are on the account of UNIVERSAL ELECTRONICS.

This warranty does not cover damage or failures caused by products or services

not supplied by UNIVERSAL ELECTRONICS, or which result from not mounting

the product according to manual instructions. This also applies when the

product has been modied / repaired by others than UNIVERSAL ELECTRONICS

or if a fault is the result of accident, misuse, abuse, neglect, mishandling, misap-

plication, faulty installation, improper maintenance, alteration, modications,

re, water, lightning, natural disasters, wrong use or carelessness.

To obtain warranty service during the warranty period contact […], and please

note that we need your original purchase receipt so that we may establish your

eligibility for service. If you have bought this product for purposes which are not

related to your trade, business or profession, you may have legal rights under

your national legislation governing the sale of consumer goods. This guarantee

does not aect those rights. www.oneforall.com

Universal Electronics BV –

Europe & International

P.O. Box 3332, 7500 DH Enschede

The Netherlands

RDN-1150323 - 710335

GUIDE

2 - 5 CM

GUIDE

KEY TABLE

TV Power

Set Top Box Power

TV Guide / EPG

Menu selection

Up, Down,

Left, Right, OK–

Navigate the TV Guide

Volume Up,

Volume Down

Mute

Digits 0 -9

Channel Up,

Channel Down

Select the Input

on your TV

Menu Exit

AFTER SIMPLESET OR CODE SETUP
