TX401-B TX402-B
QUAD SPLIT
User Manual
V010000
2022-9-14
OSEE TECHNOLOGY LTD.
Address:
No. Building, No.68 zone Beiqing Road, Haidian District, 22 ,
Beijing, China
Post Code:
100094
Tel:
(+86) -62434168 010
Fax:
(+86) -62434169 010
Web:
http://www.osee-dig.com/
E-mail:
sales@osee-dig.com
TX TX401-B/ 402-B
1
Chapter 1 Product Overview
TX401-B/TX402-B is professional quad split instrument. It supports high quality a
quad split displays for multiple environment with high quality display and swift switch
for various display modes.
TX401-B/TX402-B has compact and beautiful structure design offering local control ,
buttons and embedded web conguration functionality, and supports Ethernet loop out
functionality, which is convenient for multiple TX401-B/TX402-B integration controlled
by only one control computer.
TX401-B/TX402-B is suitable in office work environment and cabinet mounting
environment, it is widely used in the following fields: command and dispatch center,
video conference center, broadcast master control, studio, broadcasting vehicle and
so on.
Model
Inputs
Outputs
TX401-B
4C HDMI Video Input H
4C GPI Input H
1CH SDI Video Output
1 HDMI Video Output CH
TX402-B
4C / -SDI Video Input H SD HD/3G
4C GPI Input H
1 SDI Video Output CH
1 HDMI Video Output CH
Features
pports 4 channels of signal inputs with LED indicators and one power input Su
indicator
Supports four kinds of output formats: 1080P50, 1080P59.94, 1080I50,
1080I59.94
Supports four kinds of screen display modes: four uniform size screens one ,
big left with three right small, one big right with three left small, one big top
with three bottom small
Supports TSL3.1/4.0, TSL5.0 protocol
4ch GPI interfaces, one -422 interface, one ETHERNET interface RS
Embedded Web Server, supports web interview
Chapter 2 TX401-B/TX402-B atures Fe
2.1 Control Buttons and Interfaces
There are a series of control buttons, interfaces and indicators at the left side of the
device, besides, a series of interfaces at the right side of the device.
TX TX401-B/ 402-B
2
Name
Position
Quantity
Description
TX401-B
TX402-B
Interfaces
HDMI Input
Right Side
4
--
Input formats HDMI, DVI-: D, Label as HDMI ed
IN1, HDMI IN2, HDMI IN3, HDMI IN4
HDMI Output
Right Side
1
1
Output formats 1080P50/P59.94, 1080I50/I59.94, :
Label as HDMI ed OUT
SDI Input
Right Side
--
4
Input formats: HD/SD/3G-SDI
，
Label ed as SDI
IN1, SDI 2, SDI 3 SDI 4 IN IN , IN
SDI Output
Right Side
1
1
Output formats 1080P50/P59.94, 1080I50/I59.94, :
Label SDI ed as OUT
Power Input
Right Side
1
1
DC6~16V External Power(12V/1A)
Conguration
Ethernet
Left Side
1
1
RJ45
GPI/Serial
Communication
Left Side
1
1
RJ45, RS422 Standard, only received; TTL level
Operating Buttons
Reset
Left Side
1
1
Restore the factory settings
Controls
Left Side
3
3
Mute, Single, Quad
Indicators
Power
Left Side
1
1
Label PWR ed as
Input Signal
Left Side
4
4
Label as IN1, 2, 3, 4 ed IN IN IN
Operating Buttons
MUTE:
Mute button, click this button to enable or disable the audio play.
SINGLE：
Single mode button, click this button to switch to display only one
picture for one signal source on whole screen in SINGLE mode.
QUAD：
Quad mode button, click this button to switch to display quad split
windows, including four uniform size screens display, one big with three small
screens display. The latter including one big left with three right small, one big
