Optical Bubble Sensor
For small diameter tubes
BE
-
A
SERIES
Conforming to
EMC Directive
2016.03
panasonic.net/id/pidsx/global
Detects liquid and air bubbles
without fail!
Fits perfectly with applicable tube sizes!
Tube outer diameter
ø
2
mm
ø0.078
in
Tube outer diameter
ø
3
mm
ø0.125
in
Tube outer diameter
ø
4
mm
ø0.156
in
Optical bubble sensor is handy, simple, and precise!
Hassle-free one-touch attachment without using tools!
Simply attach the sensor with your hand!
Perfect fit into applicable tubes without obstructing flow rate.
Compatible with tubes in inch size
For ø2 mm, ø3 mm, ø4 mm tubes
No requirement of
sensitivity adjustment
0.8 mm
0.032 in
*Refer to the specifications for detection conditions,
BE-A201□ has a response time of 30 μs.
High speed detection Fingertip size 5 to 24 V DC compliant
In the case of BE 1-A40 □
BE 1-A30 □
BE 1-A20
(NPN output type)
BE-A201P
(PNP output type)
Transparent resin tube
(PFA equivalent)
Outer diameter ø2 mm × ø0.078 in
inner diameter ø1 mm ø0.039 in
Liquid-absent-ON / Liquid-present-ON
(equipped with two outputs)
Model No. :
Applicable tube :
Output operation:
●Push down the tube into the sensor. ●
Stretch the tube and insert it into the sensor.
*ø4 tube: Equivalent to flexible PVC
ø4 tube
Insert
Pull
Pull
One-touch attachment
New proposals
for ease of use
High speed response time
New proposals
for ease of use
Ultra compact
New proposals
for ease of use
For a wide-range of
power supply voltages
New proposals
for ease of use
For small diameter tubes
New proposals
for ease of use
Built-in Amplifier
New proposals
for ease of use
ø
2
mm
ø
0.078
in
tube type
Allows for direct power supply from
PC board.
Can be used immediately after installation
by built-in amplifier.
Equipped with two outputs,
Liquid-absent-ON and Liquid-present-ON.
0.8 mm 0.032 in air gaps are reliably
detected by optical technology at a
response time of 20 μs*.
Ideal for traceability of the analysis process.
Allows for installation in a narrow space.
Experience its ease of use!
In the case of BE 1 / BE 1-A20 □ -A30 □
Push down
Tube
ø
2 mm tube type
BE 1-A20 □
ø
4 mm tube type
ø
3 mm tube type
BE 1-A40 □
2
Applications
Allows for
close proximity
attachment
Model No. :
Applicable tube :
Output operation:
BE 1-A30
(NPN output type)
BE-A301P
(PNP output type)
Transparent resin tube
(PFA equivalent)
Outer diameter ø3 mm × ø1/8 in
inner diameter ø2 mm ø1/16 in
Liquid-absent-ON / Liquid-present-ON
(equipped with two outputs)
Model No. :
Applicable tube :
Output operation:
BE-A401
(NPN output type)
BE-A401P
(PNP output type)
Transparent resin tube
(equivalent to flexible PVC)
Outer diameter ø4 mm × ø5/32 in
inner diameter ø2.4 mm ø3/32 in
Liquid-absent-ON / Liquid-present-ON
(equipped with two outputs)
Air bubble detection
before liquid dispensing
Precise liquid
dispensing
To
dispensing
nozzle
Reagent/
cleaning
fluid tank
Air bubble
detection
after pumping
Staggered pattern
(10 mm 0.394 in pitch)
Parallel pattern
(15.5 mm 0.610 in pitch)
Liquid dispensing
instrument
Clinical laboratory
instrument
ø
4
mm
ø
0.156
in
tube type
ø
3
mm
ø
0.125
in
tube type
BE-A series
BE-A seriesBE-A series
Empty detection
inside the tank
3
