Thank you for purchasing this Panasonic product.

■

The Operating Instructions correspond to rmware main versions below 2.00 and rmware

main versions 3.00 and higher.

■

The functions and applications supported may di󰀨er depending on the main version of the

rmware. Before reading the instructions, please check the main version of the projector's

rmware in [MAIN/SUB VERSION] on the [STATUS] screen.

■

This manual is common to all the models regardless of su󰀩xes of the Model No.

for Taiwan

BT: Black model

for India

BD: Black model

for other countries or regions

B: Black model W: White model

■

Before operating this product, please read the instructions carefully and save this manual

for future use.

■

Before using this product, be sure to read “Read this rst!” (

pages 5 to 15).

DPQP1399ZC/X1

DLP™ Projector

Commercial Use

Operating Instructions

Functional Manual

ENGLISH

Model No.

PT-FRQ60

PT-FRQ50

* Resolution is 3 840 x 2 160 dots

(with QUAD PIXEL DRIVE)

2 - ENGLISH

Contents

Read this rst! 5

Chapter 1 Preparation

Precautions for use 19

Intended use of the product 19

Lens protection material 19

Cautions when transporting 19

Cautions when installing 19

Cautions when setting up the projector 20

Security 21

Notes regarding the wireless LAN 22

QUAD PIXEL DRIVE 23

DIGITAL LINK 23

Art-Net 23

Application software supported by the projector 23

Storage 24

Disposal 24

Cautions on use 24

Accessories 25

Optional accessories 26

About your projector 27

Remote control 27

Projector body 28

Preparing the remote control 31

Inserting and removing the batteries 31

When using the multiple projectors 31

Chapter 2 Getting Started

Setting up 33

Installation mode 33

Parts for installation (optional) 34

Projected image and throw distance 34

Connecting 37

Before connecting 37

Connecting example: AV equipment 37

Connecting example: Computers 38

Connecting example using DIGITAL LINK 39

Chapter 3 Basic Operations

Switching on/o󰀨 the projector 42

Connecting the power cord 42

Power indicator 42

Switching on the projector 43

When the initial setting screen is displayed 44

When the administrator account setting screen

is displayed 49

Making adjustments and selections 50

Switching o󰀨 the projector 51

Projecting 52

Selecting the input signal 52

Adjusting the image 53

Adjusting adjustable feet 54

Lens shift range 54

Using the USB memory 55

Notes on use 55

USB memory that can be used with the projector 55

Attaching the USB memory 55

Removing the USB memory 55

Operating with the remote control 56

Using the shutter function 56

Using the mute function 56

Adjusting the volume 57

Using the freeze function 57

Using the on-screen display function 57

Using the automatic setup function 57

Using the geometric adjustment function 58

Switching the image aspect ratio 59

Using the function button 59

Displaying internal test pattern 59

Using the status function 59

Using the ECO management function 60

Using the HDMI-CEC function 60

Setting ID number of the remote control 60

Chapter 4 Settings

Menu navigation 63

Navigating through the menu 63

Main menu 65

Sub-menu 65

[PICTURE] menu 68

[PICTURE MODE] 68

[CONTRAST] 68

[BRIGHTNESS] 68

[COLOR] 69

[TINT] 69

[COLOR TEMPERATURE] 69

[WHITE GAIN] 71

[GAMMA] 71

[DAYLIGHT VIEW] 72

[SHARPNESS] 73

[NOISE REDUCTION] 73

[DYNAMIC CONTRAST] 73

[COLOR SPACE] 74

[SYSTEM SELECTOR] 74

sRGB-compliant video 75

[POSITION] menu 76

[SHIFT] 76

Produktspezifikationen

Marke:	Panasonic
Kategorie:	videopprojektor
Modell:	PT-FRQ50
Marktpositionierung:	Business
Eingebaute Lautsprecher:	Nein
WLAN:	Nein
Breite:	498 mm
Tiefe:	492 mm
Gewicht:	16100 g
Produkttyp:	Großraumprojektor
Produktfarbe:	Weiß
Höhe:	168 mm
Energiequelle:	AC
AC Eingangsspannung:	100 - 240 V
AC Eingangsfrequenz:	50 - 60 Hz
Eingebautes Display:	Nein
Anzahl USB 2.0 Anschlüsse:	1
Betriebstemperatur:	0 - 45 °C
Relative Luftfeuchtigkeit in Betrieb:	10 - 80 %
Stromverbrauch (Standardbetrieb):	480 W
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Natives Seitenverhältnis:	16:9
Kontrastverhältnis:	20000:1
Anzahl HDMI-Anschlüsse:	2
Stromverbrauch (Standby):	- W
Ethernet LAN Datentransferraten:	10, 100 Mbit/s
Geräuschpegel:	35 dB
Audioeingang (L, R):	1
Audio (L,R) Out:	1
3D:	Nein
DVI Anschluss:	Nein
Full-HD:	Ja
Zoom-Fähigkeit:	Ja
Integrierter Kartenleser:	Nein
Projektorhelligkeit:	5200 ANSI Lumen
Projektionstechnologie:	DLP
native Auflösung des Projektors:	2160p (3840x2160)
Trapezkorrektur, vertikal:	-40 - 40 °
Projektionsflächenkapazität:	30 - 300 "
Fokus:	Manuell
Anzahl VGA (D-Sub) Anschlüsse:	2
Serielle Schnittstelle:	RS-232C
Lebensdauer der Lichtquelle:	20000 h
Typ der Lichtquelle:	Laser
Brennweitenbereich:	21.5 - 43 mm
Trapezkorrektur, horizontal:	-20 - 20 °
Zoomverhältnis:	2.0:1
Blendenbereich (F-F):	2 - 3.4
Projektionsverhältnis:	1.46 - 2.93:1
Vertical Linsenschwankung Range:	-48 - 71 %
Smart Projektor:	Nein
Interaktiv:	Nein
Zoomtyp:	Manuell
Horizontale Linsenschwankung Range:	-27 - 34 %
Geräuschpegel (Standby):	28 dB
Ethernet/LAN:	Ja
