Seite 1/48

Operating Instructions

Functional Manual

FULL HD LCD Display For business use

Model No. TH-49LFV8U

49-inch model

TH-49LFV8W

49-inch model

TH-55LFV8U

55-inch model

TH-55LFV8W

55-inch model

English

* The instructions in this manual apply to all models irrespective of the

suffixes to the model number.

U: for US, Canada and Mexico

W: for EU, CIS, South East Asia and Middle East Asia

Please read these instructions before operating your

Display and retain them for future reference.

English

DPQP1189ZA

Dear Panasonic Customer

Welcome to the Panasonic customer family. We

hope that you will have many years of service and

enjoyment from your new LCD Display.

To obtain maximum benefit from your Display,

please read these Instructions before making

any adjustments, and hold on to them for future

reference.

Keep your purchase receipt as well, and record the

model and serial numbers of your set in the space

provided on the rear cover.

Visit our Panasonic Web Site http://panasonic.

com

Table of Contents

Before use

Pictures and images of screens in this manual are for

illustration only and may be different from the actual

physical device.

Important Safety Instructions ..........................3

FCC STATEMENT .............................................. 4

Important Safety Notice ...................................5

Safety Precautions ...........................................6

Precautions for use .......................................... 8

Accessories ....................................................10

Accessories Supply ·········································· 10

Remote Control Batteries ·································· 11

VESA Mounting ............................................... 11

Cautions when moving ..................................12

Kensington security lock ...............................12

Identifying Controls ........................................13

Main unit ························································ 13

Interface ························································ 14

Remote Control ··············································· 15

Connections ....................................................17

AC cord connection ········································· 17

Cable fixing ···················································· 17

Before connecting ············································ 18

PC Input Terminals connection ··························· 18

VIDEO IN connection ········································ 19

COMPONENT connection ································· 19

AUDIO OUT connection ···································· 20

Speaker connection ·········································· 20

HDMI1, HDMI2 connection ································ 20

DVI-D input / DVI-I output connection ··················· 21

DisplayPort input/output connection ····················· 22

SERIAL terminal connection ······························· 23

IR terminal connection ······································ 24

USB terminal connection ··································· 24

Connecting Multiple Displays in a Daisy-chain

configuration ··················································· 25

Basic controls .................................................26

Watch the Connected Video Source ···················· 26

Change Picture Format ····································· 26

Choose your Preferred Picture Settings ················ 26

Choose your Preferred Sound Settings················· 26

Play multimedia files from a USB device ··············· 26

Function controls ...........................................29

Picture ··························································· 29

Sound ··························································· 30

Tiling ····························································· 30

General Settings ·············································· 31

Network settings ·············································· 34

Using the Network Function ..........................35

The environment necessary for a computer connection

Example of network connection ·························· 35

For instructions on connection, consult r ·············· 35

Computer operation ·········································· 36

PJLink protocol ················································ 36

Early Warning Software ····································· 38

Multi Monitoring & Control Software ····················· 38

USB device compatibility...............................39

Input Mode ......................................................42

Troubleshooting ............................................. 44

Technical Specifications ................................ 46

Produktspezifikationen

Marke:	Panasonic
Kategorie:	Monitor
Modell:	TH-49LFV8U
Touchscreen:	Nein
Bildschirmdiagonale:	48.5 "
Bildschirmtechnologie:	LED
Anzahl der Farben des Displays:	1,073 Milliarden Farben
Eingebaute Lautsprecher:	Ja
USB Anschluss:	Ja
Breite:	1077.7 mm
Tiefe:	103.9 mm
Gewicht:	22000 g
Mitgelieferte Kabel:	AC, DisplayPort
Produktfarbe:	Schwarz
Impedanz:	8 Ohm
Höhe:	607.9 mm
Zweck:	Universal
RMS-Leistung:	20 W
Anzahl eingebauter Lautsprecher:	2
AC Eingangsspannung:	110 - 127 V
AC Eingangsfrequenz:	50 - 60 Hz
Betriebstemperatur:	0 - 40 °C
Relative Luftfeuchtigkeit in Betrieb:	20 - 80 %
Verpackungsbreite:	1374 mm
Verpackungstiefe:	373 mm
Verpackungshöhe:	901 mm
Paketgewicht:	35000 g
Fernbedienung enthalten:	Ja
Stromverbrauch (Standardbetrieb):	220 W
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Betriebsanleitung:	Ja
HD-Typ:	Full HD
Helligkeit:	450 cd/m²
Reaktionszeit:	8 ms
Kontrastverhältnis:	1300:1
Bildwinkel, horizontal:	178 °
Bildwinkel, vertikal:	178 °
Anzahl HDMI-Anschlüsse:	2
Stromverbrauch (Standby):	0.5 W
Ethernet LAN Datentransferraten:	10, 100 Mbit/s
Temperaturbereich bei Lagerung:	-20 - 60 °C
Luftfeuchtigkeit bei Lagerung:	5 - 95 %
Kontrastverhältnis (dynamisch):	50000:1
Audioeingang (L, R):	1
PC Audio-Eingang:	Ja
HDCP:	Ja
VESA-Halterung:	Ja
LED-Hintergrundbeleuchtungstyp:	Direct-LED
DVI Anschluss:	Ja
Panel-Montage-Schnittstelle:	400 x 400 mm
Produktdesign:	Videowand
Anzahl der USB-Anschlüsse:	1
USB-Version:	2.0
Akkus/Batterien enthalten:	Ja
Anzahl DVI-D-Anschlüsse:	1
Stromverbrauch (aus):	0 W
Panel-Typ:	IPS
Höhe bei Betrieb:	0 - 2800 m
Anzahl DisplayPort Anschlüsse:	1
Pixel Abstand:	- mm
Fernbedienung (IR) output:	1
TV Tuner integriert:	Nein
Ausrichtung:	Horizontal/Vertikal
Betriebszeiten (Stunden/Tage):	24/7
Höhe bei Lagerung:	2800 - 9000 m
Lebensdauer des Panels:	50000 h
Computersystem:	Nein
Fernbedienung (IR) input:	1
Anzahl DVI-I-Anschlüsse:	1
Display-Auflösung:	1920 x 1080 Pixel
Ethernet/LAN:	Ja
Unterstützte Positionierung:	Drinnen
