Frequency Response, 1 Meter

On-Axis, Swept-Sine in Anechoic

Environment:

 90Hzto14kHz(±3dB)

Usable Low Frequency Limit

(-10 dB point):

 67Hz

Power Handling:

 500wattscontinuous

 1,000wattsprogram

 2,000wattspeak

Sound Pressure Level, 1 watt, 1 meter

in Anechoic Environment:

 99.0dB(2.83Vinput)

Maximum Sound Pressure Level

(1 meter):

 126.0dBSPLcontinuous

 132.0dBSPLpeak

Radiation Angle Measured at -6 dB

Point of Polar Response:

 40°horizontalby90°vertical

Transducer Complement:

Lowfrequencysection:

One15"woofer

1508-8HESFBWX

Highfrequencysection:

One.875"exit/51mmvoicecoil

Rx™22compressiondriverona

CDhorn

Box Tuning Frequency:

Lowfrequencysection: 94Hz

Crossover Frequency (internal

passive):

Lowfrequency-highfrequency:

1,600Hz

Impedance (Z):

Fullrange:

Nominal: 8.0Ω

Minimum: 6.3Ω

Input Connections:

Fullrange:Two1/4"phonejacks

andafour-pin twist lock connector

Enclosure Materials & Finish:

Hardwoodpanelcoatedwith

Peavey'sHammerHead™polyurea

finish.

Mounting Provisions:

Thisunitisnotdesignedfor

overheadsuspension.

Metalstandmountadapter

incorporatedandeightrubberfeet

ontwosidesfordual-angleuse.

Dimensions (H x W x D):

45°baffleorientation:

17.13"x26.13"x19.88"

435mmx664mmx505mm

30°baffleorientation:

16.88"x26.13"x18.88"

429mmx664mmx480mm

Net Weight:

56lbs.(25.4kg)

Features

•Two-way,full-rangefloormonitor

•1,000wattsprogram2,000watts

peak

•15"BWXBlackWidow®Woofer,

4"VC,field-replaceablebasket

•Rx™22compressiondriverwith

ferrofluidcooling

•SoundGuard™IIItweeter

protection

•Hardwoodpanelcoatedwith

Peavey'sHammerHead™

polyureafinish

•Dualbaffleanglesof45°or30°

•Two1/4"full-rangephone-jack

inputsinparallelwithafour-pin

twist lock connector

•Perforatedmetalgrille

•Stand-mountadapter

Description

ThenewSP™15Misatwo-way

floormonitorspeakersystem

comprisedofa15"Black

Widow®SFwooferwitha

Kevlar®impregnatedcone

andanenclosure,madefroma

hardwoodpanelandcoatedwith

Peavey'sheavy-dutypolyurea

finishforincreaseddurability

andruggedness.Afulllength

wrap-aroundperforatedsteel

grilleprotectsthefrontofthe

enclosure.Anmetalstandmount

adaptorisbuiltinforside-fillor

PAuse.

Thelowfrequenciesare

providedbythe15"BlackWidow

BWXwooferwithaKevlar®

impregnatedconeanddust

cap.Capableofover500Watts

ofcontinuouspowerhandling

(AESStd2-1984),thewoofer

canhandlealotofpower,

SPECIFICATIONS SP

™

15M

whichresultsinverylowpower

compression.Thehighfrequencies

arehandledbya2"Rx™22

titaniumdiaphragmcompression

driverutilizingferrofluidcooling.

Thissuperbdriveriscoupledto

aconstantdirectivityhornwith

smooth,evenresponseandgood

highfrequencydispersion.TheRx

22driverfeaturestheRadialinear

PlanarPhaseCorrectionSystem

(U.S.Patent6,064,745),which

providessmootherandextended

highfrequencyresponse.

Inputconnectiontothesystemis

madeviatwo1/4"phonejacksand

afour-pintwistlockconnector

inparallel.Theinternalpassive

crossoverfeaturestheSound

Guard™IIItweeterprotection

circuitandanadvancedtopology

crossoverwithhighperformance

componentstoprovidehighpower

handlingandreliability.Sound

Guard,Peavey’sproprietaryhigh

frequencydriverprotectioncircuitry,

provideslong-andmedium-term

driveroverloadprotectionwhenthe

systemisusedfullrangewithout

impairingmusicaltransientsor

dynamics.Thecrossoverprovides

driverrolloffandprotectionas

wellasdriverEQforthewoofer

andhornforclean,clear,smooth

response.Highquality,reliable

crossovercomponentsinclude

polypropylenecapacitorsandhigh

currentinductors.Theoptimal

integrationofthecrossoverwiththe

selecteddriversresultsinasmooth

frequencyresponsefrom90Hzto

14kHz,makingithighlyappropriate

formonitorapplications.

Despiteitscompactdimensions

fora15"floormonitorenclosure,

thissystemcanputoutsomevery

highsoundlevelsandhandle1000

wattsofundistortedamplifier

powerprogram,resultinginclean

monitoringwithhigharticulation

andreliability.



Frequency Response

Thismeasurementisusefulin

determininghowaccuratelyagiven

unitreproducesaninputsignal.The

frequencyresponseoftheSP15M

ismeasuredatadistanceof1meter

usinga1watt(intothenominal

impedance)swept-sineinputsignal.

Asshowninfigure1,theselected

driversintheSP15Mcombineto

giveasmoothfrequencyresponse

from90Hzto14kHz.

Power Handling

Therearemanydifferent

approachestopowerhandling

ratings.Peaveyratesthis

loudspeakersystem'spower

handlingusingafull-rangeform

oftheAESStandard2-1984.Using

audioband20Hzto20kHzpink

noisewithpeaksoffourtimes

theRMSlevel,thisstrenuoustest

signalassurestheuserthatevery

portionofthissystemcanwithstand

today'shightechnologymusic.This

ratingiscontingentuponhavinga

minimumof3dBavailableamplifier

headroom.

Harmonic Distortion

Secondandthirdharmonic

distortionsvs.frequencyareplotted

infigures3&4fortwopower

levels,tenpercent(10%)ofrated

inputpowerandeitheronepercent

(1%)ofratedinputpoweror1watt,

whicheverisgreater.Distortion

isreadfromthegraphasthe

differencebetweenthefundamental

signal(frequencyresponse)andthe

desiredharmonic.Asanexample,a

distortioncurvethatisdown40dB

fromthefundamentalisequivalent

to1%distortion.

Mounting

Thisunitisnotdesignedfor

overheadsuspension.Includes

metalstand-mountadapterand

eightrubberfeetontwosidesfor

dual-angleuse.

Architectural & Engineering

Specifications

Theloudspeakersystemshallhave

anoperatingbandwidthof90Hz

to14kHz.Thenominaloutputlevel

shallbe99dBwhenmeasuredata

distanceofonemeterwithaninput

ofonewatt.Thenominalimpedance

shallbe8.0ohms.Themaximum

continuouspowerhandlingshallbe

500wattswithmaximumprogram

powerof1000watts,apeakpower

inputofatleast2,000wattsanda

minimumamplifierheadroomof3

dB.Thenominalradiationgeometry

shallbe40degreesinthehorizontal

plane,and90degreesinthevertical

plane.Theoutsidedimensions

shallbe17.13incheshighby26.13

incheswideby19.88inchesdeep

withtheunitinthe45degreebaffle

orientation.Theweightshallbe56

lbs.Theloudspeakersystemshall

beaPeaveymodelSP15M.

3 + 2 Year Limited Warranty

NOTE:Fordetails,refertothe

warrantystatement.Copiesof

thisstatementmaybeobtained

bycontactingPeaveyElectronics

Corporation,P.O.Box2898,Meridian,

Mississippi39301-2898.

SPECIFICATIONS SP

™

15M

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100

110

dB SPL (re 20 Pa)

Amplitude Response (1W 1m On-Axis)

Figure 1

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100

Impedance

( )

Figure 2

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100

110

dB SPL (re 20 Pa)

Harmonic Distortion : 1% Rated Power

Figure 3

3rd Harmonic

2nd Harmonic

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100

110

120

dB SPL (re 20 Pa)

Harmonic Distortion : 10% Rated Power

Figure 4

3rd Harmonic

2nd Harmonic
