8300 W. Good Hope Rd. • Milwaukee, WI 53223 • (800) 558-5592 • Fax: (414) 353-7069 • perlick.com
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without warning.
24” signature series
beer dispenser
HP24TS-3 24” INDOOR MODEL
HP24TO-3 24” OUTDOOR MODEL
Form No.HP24T-3
Rev. 09.06.2017
• Availablewithsolidstainlesssteeldoororsolidwood
overlaydoor
• Stores(1)1/4barrelor(2)1/6barrels
• Complete,self-containedbeersystem
• Portabledrainer;noplumbingrequired
• 1-or2-faucettappingkit
• Lowprolecouplerfor“D”systemkegvalvesincluded
• BeerDispensertemperature33°-42°F
• Zero-clearancehingingallowsforabutmentwith
surroundingcabinetry
• Perlick’sexclusivecommercial-grade995Btuvariable
speedcompressor
• Front-vented,RAPIDcoolforced-airrefrigerationsystem
• Commercial-gradestainlesssteelinteriorandexterior
• IndustryExclusiveadjustable,full-extensionpull-out
shelves(drawermodelsandbeerdispenserexcluded)
• State-of-the-artdigitalcontrolmodule
• Optionaldoorlocks(factoryinstalled)
• Indoorandoutdoormodelsavailable
• Alsoavailable-24”Freezer,Refrigerator,BeverageCenter
andWineReserve
• 5.2cubicfeetofcapacity
• IndustryBestThreeYearWarrantyplusadditionalthree
yearsonsealedsystem
general signature series
features
HP24TS-3/TO-3 features
Solid Door Model
C
US
Available with 1 or 2 faucets (2 faucet shown)
(1) 1/4 barrel (2) 1/6 barrel
8300 W. Good Hope Rd. • Milwaukee, WI 53223 • (800) 558-5592 • Fax: (414) 353-7069 • perlick.com
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without warning.
Form No.HP24T-3
Rev. 09.06.2017
Overall Width 23-7/8” (60.64 cm.)
Overall Height 34-1/4” (86.96 cm.)
Overall Depth 24” (60.96 cm.)
Opening Width 24” (60.96 cm.)
Opening Height 34-3/8” (87.31 cm.)
Opening Depth 24” (60.96 cm.)
Refrigerated Volume 5.2 cu. ft.
Door Swing Clearance 25” (63.5 cm.) minimum
Electrical 115V, 60Hz., 1 Phase, 2.3 amps
Plumbing None Required
Annual Energy Usage 290 kWh/yr
Shipping Weight 222 lbs (100.7 kg.)
product specifications indoor models
HP24TS-3-1L* Solid stainless steel door, hinge left
HP24TS-3-2L* Solid wood overlay door, hinge left
outdoor models
HP24TO-3-1L* Solid stainless steel door, hinge left
HP24TO-3-2L* Solid wood overlay door, hinge left
* Also available hinge right
# Number of faucets (24” models are available with 1 or 2 taps)
20" 508
15
8" 42
2138" 543
31
2" 89
269
16" 674
115
16" 49
1618" 410
Typical
quarter barrel.
14" 356
31
2" 89
2138" 543
915
16 " 252
1178" 302 6 14" 159
183
16" 461
247
8" 632
12
3
4" 323
50" Area in which1270
electrical outlet must be located
79
16
"192
1 3/8" 32
Min. clearance from
a corner to
acheive 90
door swing.
2415
16
" 634
Min. clearance
for door swing.
345"* 16
606
"
8
872
7
23
*315
16" 100
Tapping
- Leg levelers can add
*
Signature Series HP24 Models
when fully extended.
3/4" [19] to these dimensions
Also fits two sixth
barrels when shelf
is removed.
SCALE: 1:10
MILWAUKEE, WI 53223
PERLICK CORPORATION
NOT TO BE COPIED O R USED DETRIMENTAL TO OUR INT ERESTS
DR.:
PRINTED
DATE:
9/5/2017
95005
9/30/09DAS
PROPERTY OF THE PERLICK CORP.
SHEET 3 OF 4
Shelf included with
dispensing cabinets.
35
Value may
"
change due to a
8
custom pull. with a wood overlay door.
Value may change
61124"
(with 1/16" tolerance)
13
1512" 394
Power cord 6-5/8" [168] off floor. *
16
"
7214
8
111516"303
