Seite 1/27
75
V
L
R
P
r
/
C
r
P
b
/
C
b
Y
O
U
T
I
N
V
I
D
E
O
A
UD
I
O
S
-
V
I
D
E
O
I
N
Pr/Cr
Pb/Cb
Y
Rear of System
FL CFR
FL CFR SLSR
+
+
(4 )
SPEAKERS
SPEAKERS
Rear Speaker
(Surround Right)
FM Antenna
AM Antenna
Front Speaker
(Right)
Center Speaker
Front Speaker
(Left)
Rear Speaker
(Surround Left)
Subwoofer
AUDIO
INPUT
AM/FM
ANTENNA
DIGITAL OUT
WOOFER
LINE OUT
OPTICAL COAXIAL AUX TV
AUDIO IN
AUDIO
OUT
L
R
.047"
(12mm)
PUSH IN
PUSH
DOWN
abc
MX3660D
Rear of TV
(example only)
VIDEO
AUDIO
OUT IN
Pr/Cr Pb/Cb Y
S-VIDEO
IN
COMPONENT
VIDEO IN
Use this simple and quick way to
watch your favorite DVD movie
and enjoy your Home Cinema
experience!
(Not all the cables supplied are required to complete the
basic hook-up.)
Connecting Speaker Cable
Recommended Speaker Setup
Helpful Hints
You only need to make one video connection to your TV in order to view the DVD playback.
If your TV has only a single Antenna In jack, you will need an accessory RF modulator.
The RF modulator converts the video from the DVD system so it can play through the TV’s
Antenna connector. Refer to your owner’s manual for proper connection.
Additional Video Input Connections can provide better picture quality and image for DVD
movie playback (If your TV is compatible) :
Component Video (Pr/Cr Pb/Cb Y) provides the best picture quality.
OR
S-Video provides excellent picture quality.
Connect the DVD system VIDEO OUT(put) directly to the TV. Do not connect to a VCR first and
then to a TV. This type of connection may distort the picture and sound playback.
When listening to TV programs, press TV/AV button on the remote to set the DVD system to
TV/AV mode in order for the sound to be heard.
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
ANTENNA IN
Printed in China
Detailed playback features and additional functions are described in the
accompanying owner’s manual.
continue...
VOLUMESOURCE
STANDBY
-
ON
OPEN•CLOSE
PLAY•PAUSE
PREV NEXT SURROUND
STOP BASS
TREBLE
PROGRAM
DVD VIDEO DIGITAL SURROUND SYSTEM
AV IN
SUPER VIDEO
Make sure your DVD system and
TV are connected and turned on!
Playing a disc
1 Press DISC on the remote control.
You can also adjust the SOURCE button on the front panel until “DISC” appears on the display panel.
2 Turn on the TV and select the correct Video In mode.
You should see the blue Philips DVD background screen on the TV (if no disc in the DVD system).
Usually this channel is between the lowest and highest channels and may be called FRONT, A/V IN, or
VIDEO.
Or, you may go to channel 1 on your TV, then press the Channel down button repeatedly until you see the
Video In channel.
Or, your TV remote control may have a button or switch that chooses different video modes.
Do not use channel 3 or 4 on the TV unless you are using an RF modulator.
See your TV manual for more details.
3 Press OPEN•CLOSE 0 on the front of the DVD system and load a disc, then
press the OPEN•CLOSE 0 again to close the disc tray.
Make sure the disc label facing up. For double-sided discs, load the side you want to play facing up.
4 Playback will start automatically. If not, press ÉÅ button.
If a disc menu appears, use 3 4 1 2 buttons on the remote to make the necessary selection, then press
OK to confirm. Or, use the numeric keypad on the remote to select features. Follow the instructions
given in the disc menu.
5 To stop playback, press STOPÇ.
Region Codes
DVDs must be labeled for ALL regions or for
Region 1 in order to play on this DVD system.
ALL 1
1) Press SYSTEM MENU button.
The icon will be highlighted in the menu bar on the TV
screen.
2) Press 4 button to select the Picture Setup Menu item
.
3) Press 2 button to enter the Menu.
4) Press 4 button to select ‘VIDEO OUT’ and 2 button to enter
the Menu.
5) Press 34 to select and highlight :
S-VIDEO - if you use the S-Video connection.
PR PB Y/SCART - if you use the Component Video
Pr/Cr Pb/Cb Y
6) Press OK button to confirm.
DVD system Video Output Selection for Proper Playback
CVBS & S-VIDEO
PR PB Y / SCART
Note: SCART control not
available for use with your DVD
system.
