Seite 1/8
Subwoofer Manual
Features
Models: MX12D2, MX12D4
MX10D2, MX10D4
• 11mm of Linear Excursion
• Dual 2 Ohm or 4 Ohm Voice Coil models
• 12” or 10” versions
• High Excursion CAE/CAD Motor Design
• KlaraForm Vented Kapton Former technology
reduces distortion by reducing heat and resistance
• Glass Fiber Reinforced Cone for Increased Low End
© 2020 Phoenix Gold • www.phoenixgold.com
• Phoeniroll Surround Technology promotes
linear motion
• Torriform Voice Coil Technology:
Effectively dissipates heat and minimizes distortion
• Nickel Plated 12 Gauge Speaker Terminal
• Optimized for Sealed Enclosures
• Powder Coated Anti-Resonant Steel Basket
Subwoofer Owner’s Manual
© 2020 Phoenix Gold • www.phoenixgold.com
Enclosure Recommendations
SEALED MX10D2 MX10D4
MX12D2
MX12D4
Rock / Punchy Bass (cu. Ft.) 0.5 0.5 0.5 0.5
Neutral / Good All Around 0.75 0.75 0.75 0.75
Hip Hop / Low Bass / (cu. Ft.) 1.0 1.0 1.0 1.0
Enclosure recommendations already include driver and / or port displacement.
Specications
T/S Parameter MX10D2 MX10D4 MX12D2 MX12D4
Impedance (Ohm) Dual 2 Ohm Dual 4 Ohm Dual 2 Ohm Dual 4 Ohm
Znom (Ohm) 2.0 x 2 3.6 x 2 2.0 x 2 3.6 x 2
Revc (Ohm) 1 1.8 1 1.8
FS (Hz) 50.9 51.6 38 40.7
Sd (SqM) 0.034 0.034 0.051 0.051
BL (TM) 6.02 7.9 5.96 8.24
Qms 4.105 3.27 3.514 3.3
Qes 1.085 1.09 1.049 1.217
Qts 0.858 0.819 0.808 0.889
Vas (L) 13.54 15.23 41.68 35.097
Cms (uM/N) 79.45 81.37 112.5 94.76
Mms (gms) 123.228 116.8 155.88 161.46
SPL (dB) 84 85 85 85
Voice Coil Diameter 2in - 50mm 2in - 50mm 2in - 50mm 2in - 50mm
RMS Power Handling 300 watts 300 watts 300 watts 300 watts
PEAK Power Handling 600 watts 600 watts 600 watts 600 watts
Xmax (Linear) 11mm 11mm 11mm 11mm
Driver Displacement (cf) 0.037 0.037 0.040 0.040
Overall Diameter 12.5in - 318mm 12.5in - 318mm10.35in - 263mm 10.35in - 263mm
Mounting Diameter 9.25in - 234mm 9.25in - 234mm 11.10in - 282mm 11.10in - 282mm
Mounting Depth 3.63in - 92mm
3.63 in - 92mm
4.10in - 104mm 4.10in / 104mm
© 2020 Phoenix Gold • www.phoenixgold.com
Subwoofer Owner’s Manual
Enclosure Examples
Sealed Enclosure / 0.5cu.ft
Sealed Enclosure / 0.75cu.ft
Sealed Enclosure / 1.0cu.ft
External Dimensions
A = 13 in
B = 21.35 in
C = 5.5 in
External Dimensions
A = 13 in
B = 31.55 in
C = 5.5 in
External Dimensions
A = 13 in
B = 40.14 in
C = 5.5 in
A
B
C
A
B
C
A
B
C
MX10
Qtc = 0.825
F3 = 59.9 Hz
MX10
Qtc = 0.779
F3 = 57.79 Hz
MX10
Qtc = 0.753
F3 = 56.85 Hz
MX12
Qtc = 0.991
F3 = 55.77 Hz
MX12
Qtc = 0.905
F3 = 51.06 Hz
MX12
Qtc = 0.852
F3 = 48.65 Hz
Detail Size Quantity
Top/Bottom 5.5” x 21.35”2
Front/Rear 11.5” x 19.85”2
Left/Right 5.5” x 11.5”2
Detail Size Quantity
Top/Bottom 5.5” x 31.55”2
Front/Rear 11.5” x 30.05”2
Left/Right 5.5” x 11.5”2
Detail Size Quantity
Top/Bottom 5.5” x 40.14”2
Front/Rear 11.5” x 38.64”2
Left/Right 5.5” x 11.5”2
Vb = 0.5 cu.ft
V(total) = 0.53 cu.ft
Vb = 0.75 cu.ft
V(total) = 0.80 cu.ft
Vb = 1.0 cu.ft
V(total) = 1.035 cu.ft
CUBIC FEET
CUBIC FEET
CUBIC FEET
0.5
0.75
1.0
Material Thickness: 0.75 in
Material Thickness: 0.75 in
Material Thickness: 0.75 in
