Double DIN Kit contents
(1) Facia Plate
(2) Mounting Bracket Right
(3) Mounting Bracket Left
(4) Flat Headed Screw
(5) speed nut
Installation Manual Double DIN Kit
Compatible with these double DIN devices
• Ford B-MAX (JK8) 06/2012->
All installation work must be performed by a qualied professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Installation Manual
Double DIN Kit
nestor silver CA-HM-FOR.006LG
piano black: CA-HM-FOR.006BP
10. cut away a pin on the rear side of
the trim frame (see arrow)
( Note: Does not apply for SONY
OEM head units! )
Attach air vents and air vents trim
frame to new facia plate
9. Remove air vents carefully
(double clipped /see arrows)
and air vent trim frames from
OEM panel.
12. A new hazard light switch by Ford
is required: part-no.: 1519127
Attach hazard light switch to new
facia plate
Connect all required circuit points
Reinstall everything in reverse
order to nish installation
11. Attach mounting brackets to
Double DIN head unit and x it
on dash board
A new hazard light switch by Ford
is required: part-no.: 1519127
