Seite 1/3
To charge the speaker microphone using the wall charger:
1. Ensure the microphoe is turned off using the Power/Volume Knob.
The microphone cannot be operated while plugged into the wall charger.
2. Plug the charge cable into any powered USB outlet, such as an
AC wall charger, and then into the charge jack on the bottom of
the speaker microphone.
3. Once the charging process has begun, the LED indicator
on the speaker microphone will show a constant red light.
4. Typical charge time is approximately five hours. Actual charge
time will vary depending on several factors including the battery’s
charge state, condition, and age.
5. When the battery is fully charged the LED
indicator on the speaker microphone will turn off.
6. Disconnect the charger from the adapter when
charging is completed.
To charge the speaker microphone using the optional drop-in charging cradle:
1. Plug the power cable for the charge cradle into any powered USB outlet,
such as an AC wall adapter and then into the jack on the back of the charge
cradle. The LED on the charge cradle will light a solid green.
2. Drop the microphone into the charge cradle. NOTE that you may
continue to operate the microphone while it is in the charge cradle.
3. Once the charging process has begun, the LED indicator on the
charge cradle will show a constant red light.
4. Typical charge time is approximately five hours. Actual charge
time will vary depending on several factors including whether you
are operating the microphone duringh charging as well as the
battery’s charge state, condition, and age.
5. When the battery is fully charged the LED
indicator on the charge cradle will turn green.
Charging Cautions:
- Do not use a charger or charge cable that appears to be damaged. (Example: frayed wires,
melted plastic, etc.) Contact PRYME to get a new manufacturer-approved replacement charger.
- Do not tamper with or modify the speaker microphone or charger.
- Always turn the speaker microphone off when charging.
3 4
Charging the Speaker Microphone
2
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
To maintain compliance with FCC RF exposure compliance requirements, please avoid direct contact to
the transmitting antenna during transmitting.
RF Exposure Warning!
This device contains transmitters and receivers which emit Radio Frequency (RF) energy. The device
is designed to comply with the limits for exposure to RF energy set by the Federal Communications
Commission (FCC) of the United States, Industry Canada (IC) of Canada, and the regulating entities
of other countries.
If you are still concerned about exposure to RF energy,
you can further limit your exposure by limiting the
amount of time you use the equipment or by placing
more distance between your body and the device,
since exposure level drops off dramatically
with distance.
1.00 JANUARY 2022
911 Mariner St., Brea, CA 92821
PH: 714.257.0300 FAX: 714.257.0500
TOLL FREE: 800.666.2654
WWW.PRYME.COM
The BTH-550-MAX speaker microphone has an internal Lithium Ion rechargeable battery pack which must be
charged prior to operation, and must be recharged regularly. A fully charged battery will provide up to 40
hours of continuous operation before needing to be recharged. However, operating time can vary
depending on usage and the condition of the battery pack. Recharge the battery regularly.
The microphone can be charged either using the wall charger (not included)
or optional drop-in charging cradle. (not included. part number P-CHA-550)
PRYMEMAX™ BTH-550-MAX
Wireless Speaker Microphone
For use with PRYMEBLU Wireless adapters; BK, Icom, and Kenwood
two-way radios with built-in BT connectivity; and for PTT Over-Cellular
apps such as ES Chat, Wave Communicator, and Zello on IOS
and Android smart phones,
© 2022 PRYME Radio Products, Brea CA. All Rights Reserved
Model No. BTH-550-MAX
Made in Taiwan
Optional Cradle Charger
Part No. P-CHA-550
Optional Cradle Charger
Part No. P-CHA-550
Controls and Connection
Multifunction Button
This button is used to answer or hang up
phone calls. Is also used to place the
microphone into pairing mode so it can
be connected to a handset via BT.
Front Firing Speaker
Received calls are heard over
this speaker. The volume level
can be controlled using either
the Volume/Power Knob on the
speaker microphone, or by using
the volume controls on the phone.
Status LEDs
The red and blue LEDs flash
messages that let the user know
the current status of the speaker
microphone.
Replaceable Clothing Clip
The alligator-type clip secures
the speaker microphone to the
user’s clothing during use.
The clip can be rotated to
allow the microphone to
be better positioned.
Microphone
This microphone picks up
the user’s voice audio when
sending a call.
PTT Button
This button is used to
activate the push-to-talk
feature of the PoC app or
two-way radio.
Volume Control/Power Knob
This knob allows you to turn the
BTH-550-MAX microphone on and
off and to adjust the volume of
received calls.
Accessory Jack
This jack is used to connect an
optional, wired listen-only earphone
or audio accessory to the speaker
microphone for enhanced privacy.
Any standard 3.5mm mono or
stereo listen-only earphone
can be plugged into this jack.
Received calls will be heard
over the earphone.
This jack can also be used with a
3.5 mm 4-conductor (Apple iPhone
compatible) audio accessory that
contains both an earphone and a
microphone such as Apple part
numbers ME186LL/A, or MD827LL/A.
(Not included.) When used with such
an accessory, received calls can be
heard over the accessory earphones
and transmit audio will be taken
from the accessory microphone.
Charge Jack
This micro-USB jack is used to recharge
the removable battery of the speaker
microphone by connecting the
BTH-550-MAX to a USB charger
or any powered USB source.
Keep the rubber cover in place
when the jack is not being used.
