Seite 1/7
Digital Night Vision Viewer with
Camera, Video and Playback
PSHTCM88
www.pyleaudio.com
Instruction Manual
Digital Night Vision Viewer
Operating Manual
Model：PSHTCM88
【Contents】
Introduction················ 3
Operating Hints················ 4
Components Introduction················ 5
Operating Instructions················ 7
Battery Installation············ 7
Power On················ 8
Power Off················ 8
Scenery Observation············ 9
Brightness Adjustment········ 10
Photo Shooting················ 13
Playback················ 14
Video Shooting················ 16
Monitors Connection············ 17
PCs Connection··············· 17
Auto Power Off··············· 17
Power management··················· 18
Basic Parameters··················· 19
Configuration Standard················· 21
Operating Environment and Announcements····· 22
Contents
PSHTCM88
1
Contents
PSHTCM88
2
【Name】 Digital Night Vision Viewer
【Model】 PSHTCM88
【Features】
● It is a night vision viewer which can be used to
observe objects in the dark and low light situation.
Two lighting modes are available to use. The
viewing distance in the low light environment will
be at infinity, 700 feet, viewing distance in the dark
environment.
● Easy to exchange data with other instruments，
having USB, AV OUT and DC IN sockets.
● It can be used normally in the day or night, with
photo shooting, video shooting, playback and other
functions. 5X Optical Zoom and 8X digital Zoom.
● It is the best auxiliary tool of extending human’s
visual senses.
【Operating Hints】
● It is a night vision viewer which can be used to
observe objects in the dark and low light situation. Two
lighting modes are available to use.
● It is suitable to use in full dark environment.
● Turn the auxiliary light on to observe the objects
when it works in the dark situation. Adjusting the
brightness by the distance of the objects. CCD is utilized
in this viewer. If there is any light resource existing, the
auxiliary light cannot be turned on, please adjust the
focal distance only to get the sharp image of objects.
● Operating time: 1 hour under auxiliary light mode;
1.5 hours without using auxiliary light mode.
1 2 3
4
5
6
7
8 9 10 11
1 - Objective Cover
2 - Objective Focusing Wheel
3 - High Beam Light
4 - Socket Door
5 - DC 5V
6 - USB2.0
7 - Video/Audio Output Connector
8 - Tripod Receptacle
9 - Battery Cover
10 - Diopter Ring
11 - Eyecup
12
13
14
15
16
17
18
12 - Hand Grip Strap
13 - Up
14 - Down
15- Functions(for photos shooting, video shooting and
playback)
16 - Auxiliary Lighting/Brightness Adjustment
17 - POWER/FUNCTION
18 - Diopter Dial
Introduction
PSHTCM88
3
Operating Hints
PSHTCM88
4
Components Introduction
PSHTCM88
5
Components Introduction
PSHTCM88
6
