1of2

ForStyleLUL5022C

PackageContents

WarningsandCautions

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly

recommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.

Crossbar

Assembly

x1

CeilingCanopy

x1

FixtureChain

x1

QuickLink

x2

Pleasegotoforproductcleaningtips.Gototheselection.

(5)B10CandelabraBasebulbs60WMaximum,bulbnotincluded.

MinimumHangingHeightis29.5”,MaximumHangingHeightis77.5”.

30-45minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare

present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.MissingParts?Contactyouroriginalplaceof

purchase.

www.quoizel.comCare+Maintenance

LightSource:

FixtureHangingHeight:

EstimatedAssemblyTime:

Preparation:

ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.

A

B

C

D

STEP2-InstalltheCrossbarAssemblytoOutletBoxandAdjust

thelengthoftheNipple

A.AttachtheCrossbarAssembly(A)totheOutletBoxwiththeheadof

theGreenGroundScrewfacingyou.SecureitwithOutletBox

Screws(notincluded),tightenuntilsnug

B.Adjustthehexnutandlockwasherundersideofthecrossbartothe

middleofthenipple.

C.Removethecanopylockringfromthecanopychainloop.Placethe

CeilingCanopy(D)overthecanopychainloopagainsttheceilingto

determinethecorrectpositionofthenipple.Threadthecanopylock

ringontothecanopychainloop.AdjustthenippletoallowtheCeiling

Canopy(D)torestagainsttheceilingwhenheldinplacebythe

canopylockring.

D.RemovethecanopylockringandtheCeilingCanopy(D).Tighten

thelockwasherandthehexnutagainstthecrossbartosecurein

place.

.

OutletBoxScrew

(notincluded)

HexNutand

LockWasher

OutletBox

GreenGroundScrew

CanopyChainLoop

CanopyLockRing

Nipple

STEP3-InstalltheFixtureChainandCeilingCanopy

A.AdjusttheFixtureChain(B)toyourdesiredlengthbyremoving

linksifneeded.PutaclothovertheFixtureChain(B)toprotectthe

finish.

B.PullthesupplywiresthroughtheFixtureChain(B)alternatinglinks.

AfterthewiresarethroughtheFixtureChain(B),pulltheSupply

WiresandtheGroundWirethroughthecanopylockringandthe

CeilingCanopy(D)inorder.

C.AttachoneendoftheFixtureChain(B)tothefixtureloopwithone

QuickLink(C).LiftthefixtureandFixtureChain(B)upandattach

theotherendoftheFixtureChain(B)ontothecanopychainloop

withanotherQuickLink(C).Thefixturewillnowhangsafely.

D.FeedtheSupplyWiresandGroundWirethroughthecanopychain

loopandnippleintotheoutletbox.Cutthewiresleaving

approximately8”ofwireextendingfromtheOutletBox.

E.GotoStep5forwireconnectionsandfollowthedirections.Return

toStepFinthisstepwhencompletewithStep4.

F.RaisetheCeilingCanopy(D)andcanopylockringuptheFixture

Chain(B)andoverthecanopychainloop.Tightenthecanopylock

ringontothecanopychainloopuntiltight.

InstallationGuide#IS-LUL5022C

2018QuoizelInc.

ReleasedDate:2019-03-04

visituson-lineatwww.quoizel.com

A

D

Figure2

SocketAssembly

x1

F

CenterStem

x1

H

STEP1AssembleCageand

SocketAssemblies

-

a.UnfoldsupportarmsoftheFixture

LoopAssembly(E)toproper

locations.(RefertoSocket

Orientation)

b.Removethelockballfromthe

FixtureLoopAssembly(E).

c.PlaceCage(H)overthefixtureloop

assembly(E),Securewiththe

previouslyremovedlockball.

Hand-tightenuntilsnug.

FixtureLoopAssembly

(E)

D.Threadthe

,theCenterStem(F)andthe

SocketAssembly(H)togetheras

shown.Handtightenuntilsnug.

Figure1

FixtureLoop

Assembly

x1

E

G

Cage

x1

I

GlassAccentA

x25

(1pcreplacementpart)

J

GlassAccentB

x49

(1pcreplacementpart)

K

GlassAccentC

x1

E

F

G

H

lockball
