WARNING!
Read this Operator Man-’s
ual carefully before using
this tool. Failure under-to
stand and follow the con-
tents of this manual may
result in electrical shock,
fire, and/or serious per-
sonal injur y.
SR-20 online support:
support.seesnake.com/sr-20
Operator’s Manual
SR-20
SR™ Locators
SR-24LE online support:
support.seesnake.com/sr-24le

2 – English – SR-24LE/SR-20 *Original Instructions – English
Table of Contents
Introduction
Regulatory Statements ��������������������������������������������������������������������������������������������� 3
Safety Symbols ��������������������������������������������������������������������������������������������������������� 3
General Safety Rules
Work Area Safety ����������������������������������������������������������������������������������������������������� 4
Electrical Safety �������������������������������������������������������������������������������������������������������� 4
Personal Safety �������������������������������������������������������������������������������������������������������� 4
Equipment Use and Care ����������������������������������������������������������������������������������������� 5
Pre-Operation Inspection������������������������������������������������������������������������������������������ 5
Specific Safety Information
SR-24LE/SR-20 Safety ��������������������������������������������������������������������������������������������� 6
System Overview
Description���������������������������������������������������������������������������������������������������������������� 7
SR-24LE and SR-20 Specifications ������������������������������������������������������������������������� 8
Standard Equipment ������������������������������������������������������������������������������������������������� 9
Components ������������������������������������������������������������������������������������������������������������� 9
Operating Instructions
Powering the System ���������������������������������������������������������������������������������������������� 10
Receiver Operation Modes ������������������������������������������������������������������������������������� 10
Display Elements ���������������������������������������������������������������������������������������������������� 12
Active Line Tracing
Tracing the Target Line ������������������������������������������������������������������������������������������� 16
Induction and Air-Coupling ������������������������������������������������������������������������������������� 16
Passive Line Tracing
Passive Power ������������������������������������������������������������������������������������������������������� 16
Passive Radio Frequency Broadband ������������������������������������������������������������������� 17
OmniSeek 17 ��������������������������������������������������������������������������������������������������������������
Sonde Locating
Steps 17 ����������������������������������������������������������������������������������������������������������������������
Depth
Depth Verification Test �������������������������������������������������������������������������������������������� 17
Depth Average �������������������������������������������������������������������������������������������������������� 18
Signal Accuracy
Checking for Accuracy �������������������������������������������������������������������������������������������� 18
Maintenance and Support
Cleaning 19 �����������������������������������������������������������������������������������������������������������������
Transportation and Storage ������������������������������������������������������������������������������������ 19
Service and Repair ������������������������������������������������������������������������������������������������� 19
Disposal 19 ������������������������������������������������������������������������������������������������������������������

SR-24LE/SR-20 – English – 3
Introduction
The warnings, cautions, and
instructions discussed in this
manual cannot cover all possi-
ble conditions and situations
that may occur. It must be un-
derstood by the operator that
common sense and caution are
factors that cannot be built into
this product, but must be sup-
plied by the operator.
Regulatory Statements
The EC Declaration of Conformity
(999-995-232�10) will accompany
this manual as a separate booklet
when required�
This device complies with Part 15
of FCC rules� Operation is subject
to the following two conditions:
(1) This device may not cause
harmful interference, and (2) this
device must accept any interfer-
ence received, including interfer-
ence that may cause undesired op-
eration�
Contains Transmitter Module FCC ID:
X8WBT840XEE IC: 4100A-BT840XEE�
UK Importer
Ridge Tool UK (RIDGID)
44 Baker Street
London W1U 7AL, UK
Safety Symbols
In this manual and on the product, safety
symbols and signal words are used to com-
municate important safety information� This
section is provided to improve understand-
ing of these signal words and symbols�
This is the safety alert symbol� It is
used to alert you to potential per-
sonal injury hazards� Obey all
safety messages that follow this
symbol to avoid possible injury or
death�
DANGER
DANGER indicates a hazardous situation
which, if not avoided, will result in death or
serious injury�
WARNING
WARNING indicates a hazardous situation
which, if not avoided, could result in death
or serious injury�
CAUTION
CAUTION indicates a hazardous situation
which, if not avoided, could result in minor
or moderate injury�
NOTICE
NOTICE indicates informa-
tion that relates to the pro-
tection of property�
This symbol means read the op-
erator’s manual carefully before
using the equipment� The manual
contains important information on
the safe and proper operation of
the equipment�
This symbol means always wear
safety glasses with side shields or
goggles when handling or using
this equipment to reduce the risk
of eye injury�
This symbol indicates the risk of
electrical shock�
This symbol indicates the risk of
fire�
