User's Guide
ADI-648
Multichannel Audio Digital Interface
SyncAlign
TM
SyncCheck
TM
Intelligent Clock Control
TM
SteadyClock
TM
Hi-Precision 24 Bit / 192 kHz
64 Channel MADI / ADAT Converter
16 x 16 Matrix Router
MIDI embedded in MADI
Firmware 2.5
MADI
24 Bit Interface
2
User's Guide ADI-648 © RME
Important Safety Instructions ........................................................................... 3
1 Introduction ........................................................................................................ 5
2 Package Contents .............................................................................................. 5
3 Brief Description and Characteristics .............................................................. 5
4 Technical Specifications
4.1 Inputs ............................................................................................................... 6
4.2 Outputs ............................................................................................................ 7
5 First Usage
5.1 Quick Start ...................................................................................................... 8
5.2 Firmware ......................................................................................................... 8
5.3 Operating the ADI-648 .................................................................................... 9
6 The MADI to ADAT Converter
6.1 General .......................................................................................................... 10
6.2 Inputs ............................................................................................................. 10
6.3 Input State Display ........................................................................................ 10
6.4 Outputs ADAT Optical ................................................................................... 11
7 The ADAT to MADI Converter
7.1 General .......................................................................................................... 12
7.2 Inputs ............................................................................................................. 12
7.3 Input State Display ........................................................................................ 12
7.4 Outputs MADI ................................................................................................ 13
8 Clock Section
8.1 Clock Configuration ....................................................................................... 13
8.2 Lock and SyncCheck .................................................................................... 14
8.3 Word Clock Input and Output ........................................................................ 15
9 Word Clock
9.1 Operation and Technical Background ........................................................... 16
9.2 Cabling and Termination ............................................................................... 17
10 MIDI
10.1 Transmission of MIDI .................................................................................. 18
10.2 Remote Controlling the ADI-648 ................................................................. 18
10.3 Remote Control Software ........................................................................... 19
11 Special Modes
11.1 MADI to MADI Converter ............................................................................ 21
11.2 ADAT Patchbay and Splitter ....................................................................... 21
11.3 MADI Coaxial/Optical Converter ................................................................. 21
11.4 MADI Merger .............................................................................................. 22
11.5 MADInet ...................................................................................................... 22
12 Technical Background
12.1 DS – Double Speed .................................................................................... 23
12.2 QS – Quad Speed ...................................................................................... 23
12.3 MADI Basics ............................................................................................... 24
12.4 SteadyClock ................................................................................................ 25
13 Controls and Connectors ................................................................................ 26
14 Block Diagram .................................................................................................. 27
15 MIDI Implementation Chart
15.1 Basic SysEx Format ................................................................................... 28
15.2 Message Types .......................................................................................... 28
15.3 MADI Input State – Redundancy Mode ...................................................... 28
16 Warranty ............................................................................................................ 31
17 Appendix ........................................................................................................... 31
