Part no. 209-1426 || 09-MAY-2023
Inline™ Tunable Light
1
© 2022 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376 www.robern.com
SWAY CONTROL / MODEL NUMBERS - 2
TOOLS NEEDED / PARTS - 3
NOTES - 4
REPLACING ENDCAPS - 5
ASSEMBLING THE BRACKETS - 5
MOUNTING THE BRACKETS TO THE CABINET - 6
MOUNTING THE BRACKETS BETWEEN CABINETS FOR GANGING - 7
ELECTRICAL ENCLOSURE AC POWER CONNECTIONS - 9
ELECTRICAL ENCLOSURE CONTROL WIRE CONNECTIONS - 10
SWAY WALL CONTROL- 11
RECESSED INSTALLATION AND ELECTRICAL WIRING- 11
SURFACE INSTALLATION AND ELECTRICAL WIRING- 12-14
FINAL ASSEMBLY - 14
PRODUCT ALIGNMENT - 15-17
USE & MAINTENANCE / WARRANTY - 17
This instruction sheet contains information on how to install the Tenor Tunable Light(s). This series comes in many variations. Please refer to the box or
product label for the specic model number. A key is provided on page 2.
Save these instructions for future use and reference. An improper installation voids the warranty. Carefully inspect the light(s) for damage. Installed
products cannot be returned.
If you experience any problems with your light(s), contact your dealer or Robern directly.
Limited Warranty — One Year Term
INLINE™ TUNABLE LIGHT
Installation Instructions
Important safety instructions - Save these instructions
Suitable for damp locations
CONTENTS
GENERAL INFORMATION
This product re-
quires Robern Sway
Wall Control to
function
(sold separately).
See Page 2 for more
info
Scan the QR code
to see the entire
Inline Series
of lights.
Use the camera app on your
mobile device to look at this and
other QR codes. This will allow
you to quickly access web pages
and other relevant documents.
Part no. 209-1426 || 09-MAY-2023
Inline™ Tunable Light
2
© 2022 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376 www.robern.com
This model requires the use of the Sway™ Wall Control (CB-SWAY sold separately).
In addition to the Sway™ Wall Control, a standard wall switch may also be used for on/off (non-dimming) operation.
More information provided on Page 10 and 11.
NOTE: The Sway™ Wall Control runs on low voltage (5VDC) sourced from the electrical enclosure using the CAT5 cable provided with
the lights.
It is not directly compatible with 120VAC.
Low voltage and dual voltage wiring switch enclosures are available.
Check with local code authority for compliance.
NOTE: Sway™ Wall Control and Electrical Enclosures are not compatible with any other product.
Do not connect Sway™ Wall Control or Sway™ Electrical Enclosures to any other products via CAT5 cable.
NOTE: Only one Sway™ Wall Control can be used per lighting array.
No more than 6 lights are recommended per array.
SWAY™ WALL CONTROL
Use the chart below to learn how to read your light model number. Consult the Robern Price Book for a complete list of model numbers.
MODEL NUMBERS
K S SLM
Example Model: M L C30 I K 3DS S
Product Line M = Inline
Category L = Lighting
Dimensions C30 = 3-1/2"W × 30"H
C36 = 3-1/2"W × 36"H
C40 = 3-1/2"W × 40"H
Lighting Style I = Inline
Light Type K = Title 24 Certified LED
Quantity of Lights S = Single
Body Finish S = Silver
Lighting Option 3D = Dimmable: Dimming to 5%, Warm White (3000K)
VC = Tunable: Dimming to 5%, Color Temperature Tuning
(2700K - 5600K)
C48 = 3-1/2"W × 48"H
I
