Seite 1/12
Description: Robinhood Ceramic Cooktop 60cm
Model Numbers: HED604FKG
Issue 2
Warning and safety information
Installing the built in cooktop
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
Do not leave this cooktop unattended or unsupervised whilst children or inrmed are present.
WARNING: Accessible parts will become hot when in use and directly after use, care should be taken to avoid
touching the burners. To avoid burns and scalds keep children away.
The installation of this cooktop is to be carried out by using only a qualied electrician.
This cooktop is to be installed in accordance with the local, national building, electrical and plumbing codes.
If the power supply cable is damaged, it must be replaced by the manufacturer or its service agent or similarly
qualied person to avoid a hazard
The cooktop is not intended to be operated by means of an external timer or separate remote-control system.
WARNING: If the glass surface is cracked, switch o the appliance to avoid the possibility of electric shock, as
the ceramic glass protects live parts.
Do not clean the oven with a steam cleaner
The appliance must be installed by an qualied person in accordance with local and national building regulations.
Panels and furniture lining of the kitchen cabinet receiving the cooktop must be treated with temperature resistant
adhesives 100 C (otherwise they may become discoloured or deformed due to inadequate temperature resistance). °
The cooktop is intended for installation into a benchtop above a kitchen cabinet of min 600mm width or more.
After the installation of built-in cooktop make sure that there is free access to the two xing elements in front.
The distance between the top of the cooktop and any cabinets or rangehoods above must be no less than 600mm such
as indicated in the instructions for installation of the rangehood.
The use of hard wood decorative borders around the worktop behind the appliance is allowed, in case the minimum
distance remains as indicated on the installation illustrations.
Minimum distance between the built-in cooktop and rear wall is indicated at the illustration for the installation of the built-
in cooktop.
Induction cooktop may be installed into benchtop between 25mm to 40mm thick.
Kitchen cabinet must not have a drawer directly below cooktop. It must be tted with a horizontal board 20mm away
from the cooktop bottom surface. Space between the plate and the cooktop must be empty and no objects may be
stored or kept there.
Rear side of the kitchen element must also have a 50mm high opening along the entire width of the element, and the
front part must have an opening of no less than 5mm .
Incorporation of the oven under the induction cooktop is permissible for ovens equipped with a cooling fan.
Installation - continued
Built in induction cooktop cutout dimensions.
HED604FKG
A (mm) 580
B (mm) 510
C (mm) 560
D (mm) 490
E (mm) 50
F (mm) 10
G (mm) 50
Installing the foam gasket
Before inserting the appliance into the opening in the kitchen benchtop, the supplied foam
gasket must be attached to the lower side of the glass ceramic (glass) cooktop between
the benchtop and cooktop.
Do not install the appliance without the foam gasket!
The gasket should be attached to the appliance in the following way:
•Remove the protective lm from the gasket.
•Then, attach the gasket to the lower side of the glass, approximately 2-3mm from the edge.
•The gasket must be attached along the entire length of the glass edge and should not overlap at the corners.
•When installing the gasket, make sure that the glass does not come into contact the with any sharp objects.
