Specifications subject to change without notice.

PS300-12

Installation

Reference

Sheet

12” 300 Watt Powered Subwoofer

Features

Specifications

General Features

•Flexible mounting options (hardware included)

•Quick disconnect Power and Input connections for

easy removal

Woofer Features

•12" High output woofer

(application specific/optimized)

•Heavy-duty molded ABS slot-port enclosure

(internally damped)

•Bass reinforcing protective "Loading Plate"

(no grill needed)

Amplifier Features

•True 300 Watt RMS proprietary power amplifier

(closed loop optimized)

•Proprietary EQ/Compensation and fixed high order

low-pass filter

•Intelligent auto turn on/off function

•Optional remote bass level control (0dB to +20dB)

•Separate line level and speaker level inputs

(harness included)

•Custom extruded aluminum amplifer heat sink

•Thermal overload protection circuitry for maximum

safe run time

System Specifications

Frequency Response:................................................28 - 90Hz

P

o

w

er Rating (RMS/Max):...............................300W / 600W

Enclosure Type:..............................................6th order vented

Enclosure Displacement:................26.231 Liters / 0.9 cu.ft.

Net Weight:............................................35.1 Lbs./ 15.921 Kg.

Dimensions (HxWxD):......................11.23”x21.18”x15.27”

Woofer Specifications

Fs (Hz):..............................................................................36.3Hz

Re (Ohms):........................................................................1.60Ω

SPL (db - 1W/1M):.............................................................89dB

BL(T*M):...................................................................................8.1

Xmax (mm):

......................................................................

8.5mm

Sd (cm2):

..................................................................................

530

Magnet (oz):.........................................................................56oz.

Voice Coil (in):.......................................................................2.0”

Amplifier Specifications

Input Sensitivity:..................................................150mV - 3.9V

Input Impedance:

...............................................................

20kΩ

Lo

w-Pass Filter

:

.....................................24dB/octave @ 90Hz

EQ:...............................................multi-pole cascadin circuitry

THD@ Rated Power:...................................................<0.10%

S/N Ratio:..........................................................................95.8dB

Fuse Rating:............................................................................40A

P

o

w

er

Wir

e Input:...............................................up to 8AWG

LED

Indicators:...............................................Power / Thermal

Replacement Parts

Power Connector:........................(AP pack) 1130-55119-01

Hi-Le

v

el Input Harness:

...............

(APpack) 1130-55119-01

Mounting Har

dwar

e:

........................................1130-55768-01

Subwoofer:.........................................................1465-55501-01
