DC5V Power InputConnect with DC 5V/1A power adapter

HDMI InConnect HDMI signal source

HDMI Out 1/2

Connect with HDMI display devices

Note: To ensure that all monitors can show at their

maximum resolution, please connect the monitor

with highest resolution to HDMI Output 1, which is

congured as the port that can output the

maximum resolution (via EDID management).

Firmware Upgrading

Connect the computer with Micro USB cable for

rmware upgrading

S/PDIF Out

Connect to the audio device with digital optical

audio cable

Steady on: The power is on

②

Splitter x1DC5V/1A x1User Manual x1

Grounding

Screw x1

243

①

②

③

④

⑤

⑥

Power Light

⑦

HDMI Signal Light

1/2

Corresponding to 2 HDMI outputs, the indicator

light is steady on when the signal transmission is

normal

①③④⑤

⑥

⑦

8K 60Hz Ultra HD 1 to 2

HDMI SPLITTER

TrueReach

™

®

User Manual

Y10G011-B1

Important safety notice

Introduction

Features

1- Ensure all devices are properly grounded to prevent electric shock.

Avoid placing this device near radiators, heat registers, or in direct

sunlight.

2- Protect the device from exposure to rain or water to prevent potential

failures, res, or electric shocks.

3- Place the device on a stable, even surface to prevent malfunctions due

to falls.

4- Never insert metallic objects into the open parts of this device to avoid

the risk of electric shock.

5- When using a third-party power supply, ensure it meets the product's

specied requirements for safety and compatibility.

This TrueReach HDMI Splitter is an 8K HDMI splitter designed to divide one

HDMI input signal into two HDMI output signals. Utilizing the latest HDMI 2.1

standard, it supports video signal transmission up to 8K@60Hz/4K@120Hz.

With HDR10+, Dolby Vision high dynamic range imaging, and Variable

Refresh Rate (VRR) technology, the screen display is exceptionally detailed

and smooth. This splitter is versatile and nds wide applications in TV stores,

cinemas, outdoor advertising, home entertainment, and more.

• Divides one HDMI input signal into two HDMI display device output signals.

Supports resolutions up to 8k@60Hz/4k@120Hz, with downward

compatibility.

• Features support for HDR10+, Dolby Vision high dynamic range imaging.

• Includes support for Variable Refresh Rate (VRR) technology.

• Compatible with HDMI 3D technology.

• Oers EDID passthrough and automatic downscaling for optimal signal

transmission.

• Provides S/PDIF digital audio separation output capability.

• Allows for rmware upgrading via Micro-USB port for convenient updates.

• Equipped with lightning protection, surge protection, and ESD protection

for enhanced durability.

• Supports 7x24 uninterrupted working, ensuring stable and reliable

operation.

Package Contents

Panel Description
