Features

DisplayPort (Female)

Rocstor introduces the DisplayPort 1.4 repeater, oering users a convenient means to

extend DP signals from a host PC to a monitor or projector, reaching up to 20 meters

(10 meters in and 10 meters out), supporting resolutions of up to max 8K/30Hz

Before attempting to use this unit, please check the packaging and make sure the

following items are contained in the packaging:

• Main Unit x1

• User Manual x1

• USB-A to Micro USB M/M Cable 1m x1

DisplayPort (Female)

• Support DP1.4 and downward

compatible with lower versions

• Transmission speed：1.62 Gbps / 2.7

Gbps / 5.4Gbps / 8.1 Gbps

• Support DisplayPort 1.4 HBR3 with max

video resolution 8K@30Hz.

• Extending Distance: max 20m (10m input,

10m output) with 28AWG or above cable

• Support cascading function up to 3 levels

Note: 1) To achieve 8K transmission, the

source and display should support DP1.4,

the connected cable should be 28AWG or

above DP1.4 cable

2) When using the cascading function to

achieve longer distance, the max

resolution will be decreased

3) The repeater is not bidirectional, so

make sure to connect the source to the

input port and display to the output port

Upstream:

Downstream:

Package Contents

Specication

Input

OutputDisplayPort Female

DisplayPort Female

Maximum Resolution

Supported DP VersionDP1.4/DP1.2

7680*4320@30Hz

Bandwidth1.62 / 2.7 / 5.4 / 8.1 Gbps

Operating Temperature

Storage Humidity

Storage Temperature

Operating Humidity

0°C to 45°C (32°F to 113°F)

5% to 90 % RH (no condensation)

-10°C to 70°C (14°F to 158°F)

10% to 85% RH (no condensation)

Introduction

Environmental

Signal Inputs/Output

Converter UnitFCC, CE

Regulatory Approvals

User ManualEnglish Version

Accessory Adapter

Operating Temperature

Power Requirement

Micro USBExternal Power Supply

1W（5V/200mA）Power Consumption

®

TrueReach 8K/4K DisplayPort 1.4 Extender Repeater

Max 65ft (20m)

User Manual

Y10A328-B1

Congratulations

Thank you for purchasing this premium Rocstor product. For optimum performance and

safety, please read these instructions carefully before connecting, operating or using this

product. Please keep this manual for future reference.
