Seite 1/2
MX44 PRO
4-CHANNEL STEREO MIXER
Quick Start Guide
Rolls Corporation
Salt Lake City, UT
4/17
MX44 PRO
4-Channel Stereo Mixer
• Four stereo inputs to one stereo output
• Stereo RCA and 1/8" TRS Stereo high-impedance inputs
• Stereo RCA and 1/8" TRS Stereo high-impedance output
• Battery or AC operation (Rolls PS27s power supply is included)
SPECIFICATIONS
Input Impedance: 10K Ohm
Output Impedance: 100 Ohm
Gain: 30 dB
Connectors: Input: 4 ea.; RCA and 1/8" (3.5mm) unbal.
Output: 1 ea.; RCA and 1/8" (3.5mm) unbal.
Power: 9V battery, or
Rolls PS27s 15VDC adapter (included)
9-15 VDC - 100mA to 500mA
Current Draw: 15mA no load
DC Jack: 2.1X5.5 mm Tip Negative
Signal to noise ratio: 85 dB
Bandwidth: 20 Hz to 30 Khz
Size: 4.5"w x 1.5"h x 4"d
Weight: 1 lb
Four Channel Portable stereo mixer
BATTERY-9V
MX44 PRO
3.5mm
RCA
STEREO OUTPUTS
pwr
POWER
STEREO INPUTS
CH.1 CH.2 CH.3 CH.4
75889 44010
6 2
OPERATION
To connect various devices to the MX44 Pro, you'll need
the proper cables.
- Connecting most CD, Cassete, and Video units will
require a stereo RCA to stereo or 1/8" (3.5mm) cable. A
stereo plug consists of tip, ring and sleeve.
- Most stereo instruments have individual Right and Left
outputs. Therefore, you'll need an "Insert" type cable. This
cable has two 1/4" or 1/8" Tip-Sleeve jacks on one end to
connect to the stereo instrument, and a single Tip-Ring-
Sleeve stereo 1/8" jack on the other end to connect to
the MX44. For assistance on cable selection, contact your
local professional audio dealer.
- Some devices have stereo 1/4" outputs that can be con-
nected to the 1/8" inputs of the MX44. These devices will
require a 1/4" TRS stereo to RCA or 1/8" TRS stereo cable.
- While the MX44 is not a headphone amplier, the out-
puts have sucient level to drive a pair of headphones or
earphones for limited monitoring.
- NOTE: PLUGGING A TIP-SLEEVE MONO PLUG INTO THE
MX44 WILL NOT DAMAGE THE UNIT. HOWEVER, THE
SIGNAL WILL BE HEARD ON ONLY THE LEFT SIDE. DO NOT
PLUG A MONO JACK INTO THE - THIS WILL DAMOUTPUT -
AGE THE UNIT.
TO SEND A MONO SIGNAL TO THE MX44, USE A TRS JACK
WITH THE TIP AND RING CONNECTED TOGETHER.
BATTERY
LIFT TO WITHDRAW
Four Channel Portable stereo mixer
BATTERY-9V
MX44 PRO
3.5mm
RCA
STEREO OUTPUTS
pwr
POWER
STEREO INPUTS
CH.1 CH.2 CH.3 CH.4
INTRODUCTION
Thank you for your purchase of the MX44 Pro 4 Channel Stereo Mixer. This unit
is designed to mix up to four stereo line-level signals such as smart phones,
instruments, CD players, DVD players, MP3 players, laptop computers, etc. to a
single stereo output.
WARRANTY REGISTRATION
For complete warranty information, please visit our website at www.rolls.com
and click on the "Register Your Warranty Here" text, and follow the link and
instructions.
OUTPUTS: 1/4" and 1/8" (3.5 mm)Tip-Ring-Sleeve
jack for connection to a mixer input, amplier or
other input device.
ON/OFF: Latching push button switch for apply-
ing power to the MX44.
9-15 VDC: Power jack - connects to the included
Rolls PS27s 15VDC AC adapter.
BATTERY: Removable compartment for housing
a 9 volt alkaline battery.
pwr: LED - Indicates that the MX44 is connected
to a power source, and the unit is on.
1 - 4: Volume controls - adjust the level of the
signals coming from Inputs 1 - 4.
IN 1 - 4: Stereo RCA and 1/8" (3.5mm)Tip-Ring-
Sleeve stereo unbalanced jacks for connection to
line level devices.
This is a MONO jack
and should never be
plugged into the out-
put of a MX44 Pro.
This is a TRS or
stereo jack that is
compatible with the
MX44 Pro output.
