Seite 1/2
NA30N7755TS
30" Gas Cooktop
Features
• Bluetooth
®
Connected to Hood
• Blue LED Lights
• Wi-Fi Connectivity
• Powerful Cooktop
– Right Front: 13K BTU
– Left Front: 9.5K BTU
– Right Rear: 5K BTU
– Left Rear: 9.5K BTU
– Center: True Dual, 22K BTU (Brass)
Signature Features
22K True Dual-Power Burner
• Two independent heating burners offer intense
heat and precise control to quickly boil water
or temper chocolate.
Analog Controls with Digital Wi-Fi
and Bluetooth
®
Technology
• The ultimate combination of analog comfort
and digital technology delivers exceptional
cooking performance.
Cast Iron Griddle
• Cook breakfast, grill sandwiches, or sauté vegetables
on the removable griddle.
Cast Iron Griddle22K True Dual-Power Burner
Available Colors
Stainless Steel (shown)
Fingerprint Resistant
Black Stainless Steel
Convenience
• Wok Grate
• LP Conversion Kit
• Cast Iron 3-Piece Grates
• Sealed Burners
• Burner On/Off Monitoring
• ADA Compliant
ADA Compliant
ADA
Compliant
Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.
©2018 Samsung Electronics America, Inc., 85 Challenger Road, Ridgeeld Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com. Samsung is a registered trademark of Samsung Electronics Co., Ltd.
NA30N7755TS
30" Gas Cooktop
Total Power (BTU)
59K
Power Source
120V / 60 Hz / 1A
Gas Cooktop (BTU)
• Right Front: 13K
• Left Front: 9.5K
• Right Rear: 5K Simmer
• Left Rear: 9.5K
• Center: 22K (True Dual)
Warranty
One (1) Year All Parts and Labor
Product Dimensions & Weight (WxHxD)
Outside (Max) Cooktop Dimensions:
30" x 5
41
/
72
" x 22
1
/
3
"
Cooktop Cut-Out Dimensions:
28
1
/
2
" x 3
1
/
8
" x 19
5
/
8
"
Weight: 75.8 lbs. (76.3 lbs. Fingerprint Resistant
Black Stainless Steel)
Shipping Dimensions & Weight (WxHxD)
Dimensions: 34
11
/
16
" x 10
5
/
8
" x 25
5
/
8
"
Weight: 84.0 lbs. (84.9 lbs. Fingerprint Resistant
Black Stainless Steel)
Color Model # UPC Code
Stainless Steel NA30N7755TS 887276281704
Fingerprint Resistant
Black Stainless Steel NA30N7755TG 887276281698
30"
2
4
/
9
"
Counter otop t
grate surface
3
1
/8"
Chassis height
21"
28
1
/
7
"
19
3
/
8
"
22
1
/
3
"
13" Max.
18" Min.
30" Min.
12" Min.
12" Min.
28¹/
"
Min.
2 /⁷
"
Min.
19 /⁵
"
Min.
Minimum distance to combustible
side wall above countertop (both sides)
Rear wall
Vertical
combustible
surface
All horizontal clearances must
be maintained for a minimum
of 18" above the cooking surface.
Allow
7
/
16
" minimum vertical
clearance from the cooktop
bottom (or 3⁹/
16
") minimum depth
from the countertop) to any
combustible surfaces, including
the upper edge of a drawer
installed below the cooktop.
El leectrical out t 12"
minimum
be wlo count toper
3
9
/
16
"
7
/
16
"
DR WEA R
90° ow Elb
5" t teo Cen r of " . 2 Dia
Hol m e fro co r punte to
2" a Di . Hole
20
7
/
8
"
ont fr from
of r counte top to
h e ol center
View F p from ront of Cookto
C ine sab t Side
Installation Requirements
Countertop cut-out and minimum clearance dimensions:
Cooktop Dimensions
1" -
1
1
/
4
"
3
3
/
4
"
24"
4"
22"
9
1
/
2
"
***
27
1
/
4
"-
27
1
/
3
"
28
1
/
2
" - 28
5
/
8
"
Min.
Max.
Min.
Installing Over a Single Oven
* This cooktop can be installed
above any Samsung single
built-in oven. Refer to
installation manual of oven.
** Gas and electrical connections
for gas cooktop must be located
in an adjacent accessible location
to the right.
