Simple User Guide
Thank you for purchasing this Samsung product.
To receive more complete service, please register your product at www.samsung.com
Model Serial No.
The figures and illustrations in this Simple User Guide are provided for reference only and may differ from the actual product
appearance.
The product design and specifications may change without notice.
© 2025 Samsung Electronics Co., Ltd. All rights reserved.
ENG
Before Reading This
Simple User Guide
This TV comes with this Simple User Guide and an embedded
User guide.
(F6***F/H5***F:
> left directional button > > Settings
Support Open User guide > )
(Other models:
> left directional button > > Settings
Support Tips and User Guides Open User guide > > )
On the website (www.samsung.com), you can download the
manuals and see its contents on your PC or mobile device.
Warning! Important
Safety Instructions
Please read the Safety Instructions before using your TV.
Refer to the table below for an explanation of symbols which
may be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). THERE ARE
NO USER SERVICEABLE PARTS INSIDE. REFER ALL
SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is
present inside. It is dangerous to make any
kind of contact with any internal part of
this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product: This symbol indicates
that a safety connection to electrical earth
(ground) is not required. If this symbol
is not present on a product with a mains
lead, the product MUST have a reliable
connection to protective earth (ground).
AC voltage: Rated voltage marked with this
symbol is AC voltage.
DC v oltage: Rated voltage marked with -
this symbol is DC voltage.
Using the One Connect cable holder
(S95F, The Frame (LS03FA) only)
You can use the One Connect cable holder to tidy up the
cables while installing the wall mount.
•The image may differ depending on the model.
03 Initial Setup
When you turn on your TV for the first time, it immediately
starts the Initial Setup. Follow the instructions displayed on
the screen and configure the TV's basic settings to suit your
viewing environment.
•You will need a Samsung Account to access our network-
based smart services. If you choose not to log in, you
will only get a connection to terrestrial TV (applicable to
devices with tuners only) and external devices, e.g. via
HDMI.
•43LS03F model as a wall mount, it When installing the
can be installed vertically and used.
–Some features may not support portrait mode or full
screen.
–The initial setup is optimised for landscape mode.
Using the TV Controller
You can turn on the TV with the TV Controller button at
the bottom of the TV, and then use the Control menu. The
Control menu TV Controller appears when the button is
pressed while the TV is On.
•The position and shape of the buttons at the bottom of
the TV may differ depending on the model.
•The screen may dim if the protective film on the Samsung
logo or the bottom of the TV is not detached. If protective
film is attached, remove the film.
Caring for the TV
•To clean this apparatus, unplug the power cord from the
wall outlet and wipe the product with a soft, dry cloth.
Do not use any chemicals such as wax, benzene, alcohol,
thinners, insecticide, aerial fresheners, lubricants, or
detergents. These chemicals can damage the appearance
of the TV or erase the printing on the product.
•The exterior and screen of the TV can get scratched
during cleaning. Be sure to wipe the exterior and screen
carefully using a soft cloth to prevent scratches.
•Do not spray water or any liquid directly onto the TV. Any
liquid that goes into the product may cause a failure, fire,
or electric shock.
01 What's in the Box?
Make sure the following items are included with your TV. If
any items are missing, contact your dealer.
•Simple User Guide
•Warranty Card / Regulatory Guide (Not available in some
locations)
•*Samsung Smart Remote
•*Remote Control & Batteries
•*Standard Remote Control & Batteries
•*TV Power Cord
•*Wall Mount Adapter x 2
•*Slim Power Cord
•**Power Box
•**Power Box Cable x 2
•**C-type Power Adapter
•**C to C Cable
•**Wireless One Connect Box
•**One Connect Box
•**One Connect Box Power Cord
•**One Connect Cable x 2
•**One Connect cable holder (for wall mount)
*: Some of the items specified above may not be included in
the package, depending on the model or geographical area.
**: Some components may not be provided, depending
on the One Connect connection method (wired or wireless
connection).
**: The number of One Connect cables provided may differ
depending on the model.
•The type of battery may vary depending on the model.
•The items’ colours and shapes may vary depending on the
models.
Installation
•Do not place this apparatus near or over a radiator or heat
register, or where it is exposed to direct sunlight.
•Do not place vessels (vases etc.) containing water on this
apparatus, as this can result in a fire or electric shock.
•Do not expose this apparatus to rain or moisture.
•Be sure to contact an authorised Samsung service
centre for information if you intend to install your TV in a
location with heavy dust, high or low temperatures, high
humidity, chemical substances, or where it will operate
24 hours a day such as in an airport, a train station, etc.
Failure to do so may lead to serious damage to your TV.
•Do not expose this apparatus to dripping or splashing.
Mounting the TV on a wall
If you mount this TV on a wall, follow
the instructions exactly as set out by the
manufacturer. If it is not correctly mounted, the
TV may slide or fall and cause serious injury to
a child or adult and serious damage to the TV.
•To order the Samsung wall mount kit, contact Samsung
service centre.
•Samsung Electronics is not responsible for any damage to
the product or injury to yourself or others if you choose to
install the wall mount on your own.
•Samsung is not liable for product damage or personal
injury when a non-VESA or non-specified wall mount is
used or when the consumer fails to follow the product
installation instructions.
•You can install your wall mount on a solid wall
perpendicular to the floor. Before attaching the wall
mount to surfaces other than plaster board, contact your
nearest dealer for additional information. If you install
the TV on a ceiling or slanted wall, it may fall and result in
severe personal injury.
•When installing a wall mount kit, we recommend you
fasten all four VESA screws.
•If you want to install a wall mount kit that attaches to the
wall using two top screws only, be sure to use a Samsung
wall mount kit that supports this type of installation.
(You may not be able to purchase this type of wall mount
kit, depending on the geographical area.)
•Do not mount the TV at more than a 15 degree tilt.
•Standard dimensions for wall mount kits are shown in the
table on the Unpacking and Installation Guide.
Do not install your wall mount kit while your TV
is turned on. This may result in personal injury
from electric shock.
04 Troubleshooting and
Maintenance
Troubleshooting
For more information, refer to "Troubleshooting" in the User
guide.
(F6***F/H5***F:
> left directional button > > Settings
Support Open User guide Troubleshooting > > )
(Other models:
> left directional button > Settings
> > Support Tips and User Guides Open User guide > >
Troubleshooting)
If none of the troubleshooting tips apply, please visit
"www.samsung.com" and click Support or contact the
Samsung service centre.
•This panel is made up of sub pixels which require
sophisticated technology to produce. There may be,
however, a few bright or dark pixels on the screen. These
pixels will have no impact on the performance of the
product.
•To keep your TV in optimum condition, upgrade to the
latest software. Use the Update Now or Auto update
functions on the TV's menu (
> left directional button >
Settings > > Support Software Update Update Now > or
Auto update).
The TV won’t turn on.
•Make sure that the power cord is securely plugged into
the product and the wall outlet.
•Make sure that the wall outlet is working and the remote
control sensor at the bottom of the TV is lit and glowing
a solid red.
•Try pressing the TV Controller button at the bottom of the
TV to make sure that the problem is not with the remote
control. If the TV turns on, refer to "The remote control
does not work".
The remote control does not work.
•Check if the remote control sensor at the bottom of the
TV blinks when you press the
button on the remote
control.
–H5***F/HE50EF/F6***F/FE60EF/U7***F/U8***F/
UE8**F/QEF1/QE1F: If it does not blink, replace
the remote control's batteries. Make sure that the
batteries are installed with their poles (+/–) in the
correct direction. Alkaline batteries are recommended
for longer battery life.
•Always educate about the dangers of climbing on
furniture to reach the television set or its controls.
•Always route cords and cables connected to your
television so they cannot be tripped over, pulled or
grabbed.
•Never place a television set in an unstable location.
•Never place the television set on tall furniture (for
example, cupboards or bookcases) without anchoring both
the furniture and the television set to a suitable support.
•Never place the television set on cloth or other materials
that may be located between the television set and
supporting furniture.
•Never place items that might tempt to climb, such as
toys and remote controls, on the top of the television or
furniture on which the television is placed.
If the existing television set is going to be retained and
relocated, the same considerations as above should be
applied.
•When you have to relocate or lift the TV for replacement
or cleaning, be sure not to pull out the stand.
Preventing the TV from falling
: Wall-anchor (not supplied)
1. Using the appropriate screws, firmly fasten a set of
brackets to the wall. Confirm that the screws are firmly
attached to the wall.
–You may need additional material such as wall anchors
depending on the type of wall.
2. Using the appropriately sized screws, firmly fasten a set of
brackets to the TV.
–For the screw specifications, refer to the standard screw
part in the table on the Unpacking and Installation
Guide.
3. Connect the brackets fixed to the TV and the brackets
fixed to the wall with a durable, heavy-duty string, and
then tie the string tightly.
–Install the TV near the wall so that it does not fall
backwards.
–Connect the string so that the brackets fixed to the wall
are at the same height as or lower than the brackets
fixed to the TV.
QA65QN85FA QA75QN85FA QA85QN85FA QA43QN90FA
QA50QN90FA QA55QN90FA QA65QN90FA QA75QN90FA
QA85QN90FA QA98QN90FA QA115QN90F QA65QN900F
QA75QN900F QA85QN900F QA65QN990F QA75QN990F
QA85QN990F QA98QN990F QA55S85FA QA65S85FA
QA77S85FA QA83S85FA QA48S90FA QA55S90FA
QA65S90FA QA77S90FA QA83S90FA QA55S95FA
QA65S95FA QA77S95FA QA83S95FA QA65LS03FW
QA75LS03FW QA85LS03FW QA43LS03FA QA50LS03FA
QA55LS03FA QA65LS03FA QA75LS03FA QA85LS03FA
(Saudi Arabia only: UA32H5000FU UA43F6000FU
UA43U8000FU UA50U8000FU
UA55U8000FU UA58U8000FU UA65U8000FU UA70U8000FU
UA75U8000FU UA85U8000FU QA43Q7FAAU QA50Q7FAAU
QA55Q7FAAU QA65Q7FAAU QA75Q7FAAU QA85Q7FAAU
QA50Q7F4AU QA55Q7F4AU QA65Q7F4AU QA75Q7F4AU
QA55Q7F5AU QA65Q7F5AU QA75Q7F5AU QA50Q8FAAU
QA55Q8FAAU QA65Q8FAAU QA75Q8FAAU QA85Q8FAAU
QA50Q80FAU QA55Q80FAU QA65Q80FAU QA75Q80FAU
QA85Q80FAU QA55QN1EFAU QA65QN1EFAU QA75QN1EFAU
QA85QN1EFAU QA55QN70FAU QA65QN70FAU QA75QN70FAU
QA85QN70FAU QA55QN80FAU QA65QN80FAU QA75QN80FAU
QA100QN80FU QA55QN85FAU QA65QN85FAU QA75QN85FAU
QA85QN85FAU QA43QN90FAU QA50QN90FAU QA55QN90FAU
QA65QN90FAU QA75QN90FAU QA85QN90FAU QA98QN90FAU
QA115QN90FU QA65QN900FU QA75QN900FU QA85QN900FU
QA65QN990FU QA75QN990FU QA85QN990FU QA98QN990FU
QA55S85FAE QA65S85FAE QA77S85FAE QA83S85FAE
QA48S90FAE QA55S90FAU QA65S90FAE QA77S90FAE
QA83S90FAE QA55S95FAU QA65S95FAU QA77S95FAU
QA83S95FAE QA65LS03FWU QA75LS03FWU QA85LS03FWU
QA43LS03FAU QA50LS03FAU QA55LS03FAU QA65LS03FAU
QA75LS03FAU QA85LS03FAU)
Sound (Output)
HE50EF/H5***F: 10 W
F6***F (32"): 10 W, FE60EF/F6***F (43"): 20 W
U8***F/UE8**F/QEF1/Q6F/Q7F/Q8F/Q80F/QN70F/
QN1EF/S85F/S90F (42"): 20 W
QN80F/QN82F/QN83F: 30 W
QN85F/S90F (48"-83"): 40 W
QN90F (43"): 20 W, QN90F (50"): 40 W
QN3EF/QN90F (55"-115"): 60 W
S95F/QN900F: 70 W
QN950F: 90 W
QN990F (65"-85"): 90 W, QN990F (98"): 120 W
LS03FW: 40 W
LS03FA (43"-50"): 20 W, LS03FA (55"-85"): 40 W
Caution. Consult instructions for use:
This symbol instructs the user to consult
the Simple User Guide for further safety
related information.
Power
•Do not overload wall outlets, extension cords, or adapters
beyond their voltage and capacity. It may cause fire or
electric shock.
Refer to the power specifications section of the manual
or the power supply label on the product for voltage and
amperage information.
•Power-supply cords should be placed so that they are not
likely to be walked on or pinched by items placed upon
or against them. Pay particular attention to cords at the
plug end, at wall outlets, and at the point where they exit
from the appliance.
•Never insert anything metallic into the open parts of this
apparatus. This may cause electric shock.
•To avoid electric shock, never touch the inside of this
apparatus. Only a qualified technician should open this
apparatus.
•Be sure to plug in the power cord until it is firmly seated.
When unplugging the power cord from a wall outlet,
always pull on the power cord's plug. Never unplug it by
pulling on the power cord. Do not touch the power cord
with wet hands.
•If this apparatus does not operate normally - in particular,
if there are any unusual sounds or smells coming from it
- unplug it immediately and contact an authorised dealer
or Samsung service centre.
•To protect this apparatus from a lightning storm, or to
leave it unattended and unused for a long time, be sure to
unplug it from the wall outlet and disconnect the antenna
or cable system.
–Accumulated dust can cause an electric shock, an
electric leakage, or a fire by causing the power cord to
generate sparks and heat or by causing the insulation
to deteriorate.
•Use only a properly grounded plug and wall outlet.
–An improper ground may cause electric shock or
equipment damage. (Class l Equipment only.)
•To turn off this apparatus completely, disconnect it from
the wall outlet. To ensure you can unplug this apparatus
quickly if necessary, make sure that the wall outlet and
power plug are readily accessible.
•On model LS03FW, the TV Control button / Remote
Control Sensor may not be fixed in place and may move.
This is not a defect, but part of the design to ensure
smooth remote control sensing when a Customizable
Frame is installed, which is sold separately.
Control menu
TV Controller Remote control sensor button / /
Microphone switch Motion Sensor / *
TV Controller Remote control sensor button /
Microphone switch
*: The Frame only
How to turn on and off the Microphone
Type A Type B
Type C Type D
: On/Off Switch
You can turn on or off the microphone by using the switch at
the bottom or rear bottom of the TV. If microphone is turned
off, All voice and sound features using microphone are not
available.
•This function is supported only in Q8F (except for 32Q8F)/
QN7*F/QN*EF/QN8*F/QN9*F/QN9**F/S8*F/S9*F/The
Frame.
•The position and shape of the microphone switch may
differ depending on the model.
•During analysis using data from the microphone, the data
is not saved.
•Cables not included can be purchased separately.
•Check for any accessories hidden behind or in the packing
materials when opening the box.
Warning: Screens can be damaged from
direct pressure when handled incorrectly. We
recommend lifting the TV at the edges, as
shown. For more information about handling,
refer to the Unpacking and Installation Guide
came with this product.
Do Not Touch
This Screen!
02 Connecting the TV to
the One Connect Box
(One Connect Box Supported Model only)
For more information about how to connect via the One
Connect Box, refer to Unpacking and Installation Guide.
•Do not use the One Connect Box in the
upside-down or upright position.
•Take care not to subject the cable to any of
the actions below. The One Connect Cable
contains a power circuit.
Bending Twisting Pulling
Pressing
on
Electric
shock
CLASS 1 LASER PRODUCT (The Frame (LS03FA) only)
•Caution - Invisible laser radiation when open. Do not
stare into beam.
–Do not bend the One Connect Cable excessively. Do
not cut the cable.
–Do not place heavy objects on the cable.
–Do not disassemble either of the cable connectors.
•Caution - Use of controls, adjustments, or the
performance of procedures other than those specified
herein may result in hazardous radiation exposure.
•Do not use screws that are longer than the standard
dimension or do not comply with the VESA standard
screw specifications. Screws that are too long may cause
damage to the inside of the TV set.
•For wall mounts that do not comply with the VESA
standard screw specifications, the length of the screws
may differ depending on the wall mount specifications.
•Do not fasten the screws too firmly. This may damage the
product or cause the product to fall, leading to personal
injury. Samsung is not liable for these kinds of accidents.
•Always have two people mount the TV onto a wall.
–For 82 inch or larger models, have four people mount
the TV onto a wall.
Providing proper ventilation for your TV
When you install your TV *and One Connect Box, maintain a
distance of at least 10 cm between the TV *and One Connect
Box with other objects (walls, cabinet sides, etc.) to ensure
proper ventilation. Failing to maintain proper ventilation
may result in a fire or a problem with the product caused by
an increase in its internal temperature.
*: One Connect Box Supported Model Only
•When you install your TV with a stand or a wall mount, we
strongly recommend you use parts provided by Samsung
Electronics only. Using parts provided by another
manufacturer may cause difficulties with the product or
result in injury caused by the product falling.
Safety Precaution
Caution: Pulling, pushing, or climbing
on the TV may cause the TV to fall. In
particular, do not hang on or destabilise the
TV. This action may cause the TV to tip over,
causing serious injuries or death. Follow all
safety precautions provided in the Safety
Flyer included with your TV. For added
stability and safety, you can purchase and
install the anti-fall device, referring to
"Preventing the TV from falling".
WARNING: Never place a television set in
an unstable location. The television set may
fall, causing serious personal injury or death.
Many injuries can be avoided by taking simple
precautions such as:
•Always use cabinets or stands or mounting methods
recommended by Samsung.
•Always use furniture that can safely support the
television set.
•Always ensure the television set is not overhanging the
edge of the supporting furniture.
–Other models: When the remote's battery is
discharged, charge the battery using the USB charging
port (C-type), or turn over the remote to expose the
solar cell to light.
•Try pointing the remote directly at the TV from 1.5-1.8 m
away.
•If your TV came with a Samsung Smart Remote (Bluetooth
Remote), make sure to pair the remote to the TV. To pair
a Samsung Smart Remote, press the
and buttons
together for 3 seconds.
Eco Sensor and screen
brightness
(except for H5***F, F6***F)
Eco Sensor adjusts the brightness of the TV automatically.
This feature measures the light in your room and optimises
the brightness of the TV automatically to reduce power
consumption. If you want to turn this off, go to
> left
directional button > Settings All Settings General > >
& Privacy Power and Energy Saving Brightness > >
Optimisation.
•The eco sensor is located at the bottom of the TV. Do
not block the sensor with any object. This can decrease
picture brightness.
05 Specifications and
Other Information
Specifications
Display Resolution
QN9**F: 7680 x 4320
F6***F: 1920 x 1080
H5***F: 1366 x 768
Other models: 3840 x 2160
Model Name
UA32H5000F UA43F6000F UA43U8000F UA50U8000F
UA55U8000F UA58U8000F UA65U8000F UA70U8000F
UA75U8000F UA85U8000F QA75Q6FAA QA85Q6FAA
QA43Q7FAA QA50Q7FAA QA55Q7FAA QA65Q7FAA
QA75Q7FAA QA85Q7FAA QA50Q7F4A QA55Q7F4A
QA65Q7F4A QA75Q7F4A QA55Q7F5A QA65Q7F5A
QA75Q7F5A QA50Q8FAA QA55Q8FAA QA65Q8FAA
QA75Q8FAA QA85Q8FAA QA50Q80FA QA55Q80FA
QA65Q80FA QA75Q80FA QA85Q80FA QA55QN1EFA
QA65QN1EFA QA75QN1EFA QA85QN1EFA QA55QN70FA
QA65QN70FA QA75QN70FA QA85QN70FA QA55QN80FA
QA65QN80FA QA75QN80FA QA100QN80F QA55QN85FA
Precautions when installing the TV with a
stand
(The Frame only)
When you install the TV with a stand, avoid placing the stand
on the back part of the table surface. Failure to do so may
cause the motion sensor at the bottom of the TV not to work
properly.
Operation
•This apparatus uses batteries. In your community, there
might be environmental regulations that require you to
dispose of these batteries properly. Please contact your
local authorities for disposal or recycling information.
•Store the accessories (remote control, batteries, or etc.) in
a location safely out of the reach.
•Do not drop or strike the product. If the product is
damaged, disconnect the power cord and contact a
Samsung service centre.
•Do not dispose of remote control or batteries in a fire.
•Do not short-circuit, disassemble, or overheat the
batteries.
•After removing the screen protective film, never remove
the Polarising film.
–If the protective film removal label is not found, the
protective film has already been removed.
•: There is danger of an explosion if you replace CAUTION
the batteries used in the remote with the wrong type of
battery. Replace only with the same or equivalent type.
•WARNING - Do not use liquid fumigators containing
chemicals, such as mosquito repellent or air freshener,
around the product.
–If steam comes in contact with the product surface or
enters the product, it may cause stains or malfunction.
•WARNING - TO PREVENT THE SPREAD OF
FIRE, KEEP CANDLES AND OTHER ITEMS
WITH OPEN FLAMES AWAY FROM THIS
PRODUCT AT ALL TIMES.
Operating Temperature
50 °F to 104 °F (10 °C to 40 °C)
Operating Humidity
10 % to 80 %, non-condensing
Storage Temperature
-4 °F to 113 °F (-20 °C to 45 °C)
Storage Humidity
5 % to 95 %, non-condensing
Notes
•This device is a Class B digital apparatus.
•For information about the power supply, and more
information about power consumption, refer to the
information on the label attached to the product.
–On most models, the label is attached to the back of
the TV. (On some models, the label is inside the cover
terminal.)
–On One Connect Box models, the label is attached to
the bottom of the One Connect Box.
•To connect a LAN cable, use a CAT 7 (*STP type) cable for
the connection. (100/10 Mbps)
* Shielded Twisted Pair
•The images and specifications of the Unpacking and
Installation Guide may differ from the actual product.
•Operation of this product shall be limited to indoor use
only.
(QN900F, QN950F, QN990F, The Frame (LS03FW) only)
Decreasing power consumption
When you shut the TV off, it enters Standby mode. In
Standby mode, it continues to draw a small amount of
power. To decrease power consumption, unplug the power
cord when you don't intend to use the TV for a long time.
Recommendation - Jordan Only
Hereby, Samsung Electronics, declares that this TV is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
The official Declaration of Conformity may be found at
http://www.samsung.com, go to Support > Search Product
Support and enter the model name.
This equipment may only be used indoors.
This equipment may be operated in Jordan.
Contact Samsung world wide
If you have any questions or comments relating to Samsung products, please contact the Samsung service centre.
Country/Region
Samsung Service Centre
Website
SAUDI ARABIA
8002474357 (08:00 ~ 20:00 HELP) From Inside Saudi Arabia
+966112614718 From outside Saudi Arabia (Call charges
may be applied)
Digital services (24/7 HELP)
www.samsung.com/sa_en/support (English)
www.samsung.com/sa/support (Arabic)
PAKISTAN 0800-Samsung (7267864) www.samsung.com/pk/support
TUNISIA www.samsung.com/n_africa/support80 100 012
U.A.E 800-SAMSUNG (800 - 726 7864)
www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
OMAN 800-SAM CS (800-72627)
KUWAIT 183-CALL (183-2255)
BAHRAIN 8000-GSAM (8000-4726)
QATAR 800-CALL (800-2255)
TÜRKİYE 444 77 11 www.samsung.com/tr/support
JORDAN
0800-22273
06-577-7444
WhatsApp +962-79-777-7421
www.samsung.com/levant/support
LEBANON
1598
WhatsApp +962-79-777-7421
IRAQ
80010080
WhatsApp +962-79-777-7421
-00
.Samsung
www.samsung.com
Samsung Electronics Co., Ltd 2025
ARA
> >
:H5***F /F6***F (
)
> >
) >
www.samsung.com
Samsung
)LS03FA( The Frame ,S95F(
One Connect
•
03
• Samsung
Samsung
.HDMI
•
43LS03F
–
–
•
•
Samsung
•
•
•
01
•
•
• Samsung Smart
*
•
•
*
•
• 2 x
•
•
• 2
• C
• C C
• Wireless One Connect**
• One Connect
• One Connect
• 2 x One Connect **
• One Connect
One Connect
One C
onnect
•
•
•
•
•
•
Samsung
24
•
• Samsung
.Samsung
• Samsung Electronics
• Samsung
VESA
•
• VESA
•
Samsung
• 15
•
.Unpacking and Installation Guide
04
.
> >
:H5***F /F6***F (
) >
> >
) > >
www.samsung.com
.Samsung
•
•
> > >
.)
•
•
•
•
– / U8***F/ U7***F/ FE60EF/ F6***F/ HE50EF/ H5***F
QE1F
/ QEF1/ UE8**F
•
•
•
•
•
•
•
1
–
2
–
.Unpacking and Installation Guide
3
–
–
QA65QN85FA QA75QN85FA QA85QN85FA QA43QN90FA
QA50QN90FA QA55QN90FA QA65QN90FA QA75QN90FA
QA85QN90FA QA98QN90FA QA115QN90F QA65QN900F
QA75QN900F QA85QN900F QA65QN990F QA75QN990F
QA85QN990F QA98QN990F QA55S85FA QA65S85FA
QA77S85FA QA83S85FA QA48S90FA QA55S90FA
QA65S90FA QA77S90FA QA83S90FA QA55S95FA
QA65S95FA QA77S95FA QA83S95FA QA65LS03FW
QA75LS03FW QA85LS03FW QA43LS03FA QA50LS03FA
QA55LS03FA QA65LS03FA QA75LS03FA QA85LS03FA
UA32H5000FU UA43F6000FU (
UA43U8000FU UA50U8000FU
UA55U8000FU UA58U8000FU UA65U8000FU UA70U8000FU
UA75U8000FU UA85U8000FU QA43Q7FAAU QA50Q7FAAU
QA55Q7FAAU QA65Q7FAAU QA75Q7FAAU QA85Q7FAAU
QA50Q7F4AU QA55Q7F4AU QA65Q7F4AU QA75Q7F4AU
QA55Q7F5AU QA65Q7F5AU QA75Q7F5AU QA50Q8FAAU
QA55Q8FAAU QA65Q8FAAU QA75Q8FAAU QA85Q8FAAU
QA50Q80FAU QA55Q80FAU QA65Q80FAU QA75Q80FAU
QA85Q80FAU QA55QN1EFAU QA65QN1EFAU QA75QN1EFAU
QA85QN1EFAU QA55QN70FAU QA65QN70FAU QA75QN70FAU
QA85QN70FAU QA55QN80FAU QA65QN80FAU QA75QN80FAU
QA100QN80FU QA55QN85FAU QA65QN85FAU QA75QN85FAU
QA85QN85FAU QA43QN90FAU QA50QN90FAU QA55QN90FAU
QA65QN90FAU QA75QN90FAU QA85QN90FAU QA98QN90FAU
QA115QN90FU QA65QN900FU QA75QN900FU QA85QN900FU
QA65QN990FU QA75QN990FU QA85QN990FU QA98QN990FU
QA55S85FAE QA65S85FAE QA77S85FAE QA83S85FAE
QA48S90FAE QA55S90FAU QA65S90FAE QA77S90FAE
QA83S90FAE QA55S95FAU QA65S95FAU QA77S95FAU
QA83S95FAE QA65LS03FWU QA75LS03FWU QA85LS03FWU
QA43LS03FAU QA50LS03FAU QA55LS03FAU QA65LS03FAU
)QA75LS03FAU QA85LS03FAU
10 HE50EF/H5***F :
20
:)43F6***F/ FE60EF , :) 10 32F6***F
/ QN70F/ Q80F/ Q8F/ Q7F/Q6F/ QEF1/ UE8**F/ U8***F
20
:)42S90F/ S85F/ QN1EF
30
:QN83F/ QN82F/ QN80F
40
:)83S90F/ QN85F
40
:)50QN90F , 20 43 :) QN90F
60
:)115QN90F/ QN3EF
70
:QN900F/ S95F
90
:QN950F
120
:)98QN990F , 90 85 :) 65QN990F
40
:LS03FW
40
:)85LS03FA , 20 :)50 43 LS03FA
•
•
•
•
•
•
.
Samsung
•
–
•
–
•
• LS03FW
Cust
omizable Frame
/
/
* /
/
The Frame :*
AB
D
• / QN7*F/ )32Q8F Q8F
.The Frame/
S9*F/ S8*F/ QN9**F/ QN9*F/ QN8*F/ QN*EF
•
•
•
•
02
One Connect
,One Connect
.Unpacking and Installation Guide
• One Connect
•
One Connect
)LS03FA(
The Frame 1
•
– One Connect
–
–
•
•
.VESA
•
VESA
•
Samsung
•
– 82
One Connect
One Connect 10
One Connect
•
Samsung Electronics
•
.Samsung
•
•
–
C USB
•
1.8 1.5
• Samsung
Smart
Samsung Smart
3
)F6***F ,H5***F
Eco
> > >
. >
• Eco
05
7680 x 4320 : QN9**F
1920 x 1080 : F6***F
1366 x 768 : H5***F
3840 x 2160
UA32H5000F UA43F6000F UA43U8000F UA50U8000F
UA55U8000F UA58U8000F UA65U8000F UA70U8000F
UA75U8000F UA85U8000F QA75Q6FAA QA85Q6FAA
QA43Q7FAA QA50Q7FAA QA55Q7FAA QA65Q7FAA
QA75Q7FAA QA85Q7FAA QA50Q7F4A QA55Q7F4A
QA65Q7F4A QA75Q7F4A QA55Q7F5A QA65Q7F5A
QA75Q7F5A QA50Q8FAA QA55Q8FAA QA65Q8FAA
QA75Q8FAA QA85Q8FAA QA50Q80FA QA55Q80FA
QA65Q80FA QA75Q80FA QA85Q80FA QA55QN1EFA
QA65QN1EFA QA75QN1EFA QA85QN1EFA QA55QN70FA
QA65QN70FA QA75QN70FA QA85QN70FA QA55QN80FA
QA65QN80FA QA75QN80FA QA100QN80F QA55QN85FA
The Frame(
•
•
•
.Samsung
•
•
•
–
•
•
–
•
40 10 104 50
80 10
45 113
95 5
• .B
•
–
– One Connect
.One Connect
• *STP LANCAT 7
100/10(
* Shielded Twisted Pair
• Unpacking and Installation Guide
•
)LS03FW(
The Frame ,QN990F ,QN950F ,QN900F (
Samsung Electronics
.EC/1999/5
http://www.samsung.com
.Samsung
Samsung
Samsung
www.samsung.com/sa_en/support )English(
www.samsung.com/sa/support )Arabic(
)Call charges may be applied(
Digital services )24/7 HELP(
SAUDI ARABIA
www.samsung.com/pk/support
PAKISTAN
www.samsung.com/n_africa/support TUNISIA80 100 012
www.samsung.com/ae/support )English(
www.samsung.com/ae_ar/support )Arabic(
U.A.E
OMAN
KUWAIT
BAHRAIN
QATAR
www.samsung.com/tr/support 444 77 11
www.samsung.com/levant/support
JORDAN
1598
LEBANON
80010080
IRAQ
Produktspezifikationen
| Marke: | Samsung |
| Kategorie: | Fernseher |
| Modell: | QA55LS03FAU |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Samsung QA55LS03FAU benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Fernseher Samsung
22 August 2025
22 August 2025
22 August 2025
22 August 2025
22 August 2025
22 August 2025
22 August 2025
22 August 2025
22 August 2025
22 August 2025
Bedienungsanleitung Fernseher
- Hannspree
- Clatronic
- Insignia
- Sceptre
- Furrion
- Kunft
- Orava
- Astar
- AOC
- Sony
- LG
- ECG
- Westinghouse
- Inovia
- SereneLife
Neueste Bedienungsanleitung für -Kategorien-
21 August 2025
21 August 2025
21 August 2025
21 August 2025
21 August 2025
21 August 2025
21 August 2025
21 August 2025
21 August 2025
21 August 2025
