FOR YOUR SAFETY

WARNING: BE SURE THE ELECTRICITY TO THE WIRES YOU ARE WORKING

ON IS SHUT OFF; EITHER THE FUSE IS REMOVED OR THE CIRCUIT BREAKER

IS SHUT OFF.

GENERAL

You don’t need special tools to install this xture. Be sure to follow the steps

in the order given. Under no circumstances should a xture be hung on house

electrical wires, nor should a swag type xture be installed on a ceiling which

contains a radiant type heating system. Read instructions carefully. If you are

unclear as to how to proceed, consult a qualied electrician.

NOTE: Proper wiring is essential for the safe operation of this xture.

FIXTURE ASSEMBLY

Carefully remove the xture from the carton and check that all parts are included

as shown in gure. Be careful not to misplace any of the screws or parts, which

are needed to install this xture.

STEP 1: Thread rod (J) into the coupling (K). Carefully pass the wires through

each rod during assembly. Repeat step 1 with rods (G), (H) and (I) until the

desired hanging height is reached.

STEP 2: Thread the rod (G) onto swivel (F).

INSTALLATION

IMPORTANT: Do not attach xture directly to outlet box.

STEP 1: Thread mounting screw (A) into the match hole of mounting bar (B).

STEP 2: Secure the mounting bar (B) to outlet box with outlet box screws (C).

GROUNDING INSTRUCTIONS

STEP 1: Insert the green grounding screw into the hole with two raised dimples

on the mounting bar. Wrap the ground wire from the xture (if supplied) around

the green grounding screw, then connect it to ground wire from the outlet box

(if not xed on the outlet box) using a wire connector (not supplied). If ground wire

from the xture is not supplied, wrap the ground wire (if not xed on the outlet

box) from the outlet box around the green grounding screw and tighten it.

NEVER CONNECT GROUND WIRE TO BLACK OR WHITE POWER

SUPPLY WIRES.

STEP 2: Take note of the color of the wire(s) on your xture. Identify which

group your xture wire(s) falls into and connect the wires according to the

directions below:

GROUP A:

Connect to Black House Wire

GROUP B:

Connect to White House Wire

BLACKWHITE

* PARALLEL WIRE (round & smooth)* PARALLEL WIRE (square & ridged)

WHITE OR GREY WITH TRACERWHITE OR GREY WITHOUT TRACER

BROWN, GOLD OR BLACK

WITHOUT TRACER

BROWN, GOLD OR BLACK

WITH TRACER

NOTE: When parallel wire (SPT-I & SPT-2) is used, the tracer wire is square

shaped or ridged and the less tracer wire is round in shape or smooth (seen

best when viewed from wire end.)

STEP 3: Take your xture wire(s) from group A and place evenly against the

black wire from the outlet box. Do NOT twist wires together before using wire

connectors.

STEP 4: Fit a wire connector over the wires and screw the connector clockwise

until you feel rmness.

STEP 5: Try gently to pull the connector off the wires. If you can pull the

connector off, carefully re-do steps 3 and 4 as above, and check again for a

rm connection.

STEP 6: Connect the xture wire from group B to the white wire from the outlet

box in the same manner. Make sure no bare wires can be seen outside wire

connectors.

FINAL ASSEMBLY

STEP 1: After wires are connected, tuck them carefully inside outlet box.

Raise canopy (D) allowing the mounting screw (A) to protrude through the hole

in the canopy (D), and secure with nials (E).

STEP 2: Install lamp (not supplied). Do not exceed the maximum capacity

recommended on the socket.

STEP 3: Place the glass (N) into the metal frame (L) then bottom of glass into

the hooks (M).

CLEANING

To clean, wipe xture with a soft cloth. Clean glass with a mild soap. Do not use

abrasive materials such as scouring pads or powders, steel wool or abrasive paper.

ORDERING PARTS

Keep this sheet for future reference, and in case you need to order replacement

parts. Be sure to use exact wording from illustration when ordering parts.

Line art shown may not exactly match the xture enclosed. However, the installations

do apply to this xture.

La ilustración puede no concordar exactamente con la pieza enviada. Sin embargo,

las instalaciones sí aplican para esta pieza.

Les images peuvent ne pas correspondre exactement au luminaire de la boîte.

Par contre, les directives d’installation s’appliquent au luminaire.

INSTALLATION AND SAFETY INSTRUCTIONS

ITEM NO: 60-7140, 60-7150, 60-7160

ARTÍCULO Nº: 60-7140, 60-7150, 60-7160

ARTICLE N°: 60-7140, 60-7150, 60-7160

FIGURE
