This designation may be in the form of a statement
pertaining to the ballast itself, or may be combinedwith
the marking for the lamps with which the ballastis intended
to be used, for example F40T 12/IS, for more information
contact the LED luminaire retrot kit manufacturer. Do not
make or alter any open holes in an enclosure of wiring
or electrical components during kit installation. Installers
should not disconnect the existing wire from lampholder
terminals to make new connections at lampholder
terminals. Instead installers should cut existing lampholder
leads away from the lampholder and make new electrical
connections to lampholder lead wires by employing
applicable connectors.
• WARNING: Luminaire wiring and electrical parts may be
damages when installing retrot kit hardware. Check for
enclosed wiring and components.
• WARNING: Check the existing wiring for damage before
installing upgrade kit. Do not install if existing wires are
damaged. This retrot kit is accepted as a component of
a luminaire where the suitability of the combination shall
be determined by authorities having jurisdiction.
Type B Lamp – this LED tube is intended to replace
uorescent tube lamps with ANSI designation.
• This lamp is dimmable in Type A (Ballast Dependent)
mode only. Dimmable ONLY with compatible dimmable
ballasts. Visit www.satco.com for compatibility list.
• Suitable for damp locations.
• Not for emergency lighting.
LED T8 DUAL MODE
U-BEND LAMPS
Models: S18410, S18411
INSTALLATION AND SAFETY INSTRUCTIONS
IMPORTANT: Read before installing xture. Retain for future reference.
Item Number-DescriptionOverall Dimensions (mm)Operating TemperatureCCTVolts
S18410-13T8U6/LED/CCT/DUAL
92 x 562.1 x 572.3–20ºC ~ 45ºC
30K, 35K,
40K, 50K
120V–277V
S18411-13T8/U1/LED/CCT/DUAL
WARNING
• DANGER: Risk of shock-disconnect power before
installation.
• WARNING: Risk of re or electric shock. The
electrical rating of these products are 120-277Vac, the
installer must determine whether they have 120-277Vac
at the luminaire before installation.
• WARNING: Risk of re or electric shock. LED Retrot
Kit installation requires knowledge of luminaire electrical
systems. If not qualied, do not attempt installation.
Contact a qualied electrician.
• WARNING: Product must be installed in accordance with
the national electrical code or your local electrical code.
If you are not familiar with these codes and requirements,
contact a qualied electrician.
• WARNING: Install this kit only in luminaries that have
the construction features and dimensions shown in the
photographs and/or drawing and where the input rating
of the retrot kit does not exceed the input rating of the
luminaire.
• WARNING: To prevent wiring damage or abrasion, do
not expose wiring to edges of sheet metal or other sharp
objects.
• WARNING: To avoid potential re or shock hazard, do
not use this retrot kit in luminaries employing shunted
bi-pin lampholders. NOTE: Shunted lamp holders are
found only in uorescent luminaries with instant-start
ballasts. Instant-start ballasts can be identied by the
words “Instant Start” or “I.S.” marked on theballast.
Satco Products, Inc.
Brentwood, NY 11717© Copyright 2023 Satco Products, Inc. 7/23 v2.0
INSTALLATION: DIRECT REPLACEMENT/ PLUG & PLAY (TYPE A)
NOTE: This product my not be compatible with all ballasts. For more information about ballast compatibility
visit www.Satco.com.
STEP 1:Turn OFF power before installation.
STEP 2: Remove xture diffuser (if present) and
existing uorescent lamps from the xture.
STEP 3: Install the LED U-bend.
STEP 4: Attach the diffuser and turn ON power.
Installation is complete.
