*P513-174*

P513-174

B-Series Single Cylinder

Lock

Parts Included

• (2) Keys

• (1) Cylinder

• (1) M\zn” (11 mm) ring &

hardened steel insert

• (1) Z\,” (3 mm) ring &

hardened steel insert

• (1) Driver bar

• (1) Latch

• (2) Mounting screws,

cylinders

• (1) Strike

• (1) Strike dust box

• (1) Strike reinforcer

• (2) 3” (76 mm) mounting

screws, reinforcer

• (4) Mounting screws, latch

and strike

• (1) Thumbturn

Depending on size ordered, may include (2) Z\,” (3 mm) rings and

hardened steel inserts.

NOTE:

Hollow metal doors must be properly reinforced for latch

support. If door reinforcement is not furnished, contact door

manufacturer, or use Schlage reinforcer #37-001 (specify door

thickness)

1 Select rings and inserts.

Use chart to choose rings and inserts for door thickness

adjustment.

Door Thickness5 Pin Cylinder6 Pin Cylinder

1C\,” (35 mm)

B and AB and (2) A

1C\v” (44 mm)

BB and A

AB 5 Pin6 Pin

Ring InsertRing Insert1C\zn” (30 mm)1B\zn” (33 mm)

5 Pin6 Pin

1C\,” (35 mm)

door

1C\v” (44 mm)

door

1C\,” (35 mm)

door

1C\v” (44 mm)

door

2 Prepare the door.

2a Mark centerline on door face and edge.

2b Place template on door and drill a 1Z\x” (38 mm)

hole through the door face (from both sides to avoid

damaging wood).

Drill a 1” (25 mm) hole in door edge. Drill C\,” (10 mm) deeper

as illustrated.

C\,” (10 mm) deeper

1” (25 mm) Hole

1Z\x” (38 mm) Hole

3 Install latch.

3a Rotate to adjust latch so that bolt faces door jamb.

3b Insert latch into hole. Line up and trace around

faceplate.

Use chisel to remove wood until the faceplate ts ush when latch

is fully inserted.

Installation InstructionsModel B250PD
