Installation Instruction for Shadow SH 950

Double Side Upright Bass Pickup

Fig. 1Fig. 1

Fig. 2Fig. 2

Content:Content:

2 Upright Bass Transducer with 6.5 mm (1/4”)

output socket and mounting adhesive,

Copper Foil Tape,

Cable Holder

2 Upright Bass Transducer with 6.5 mm (1/4”)

output socket and mounting adhesive,

Copper Foil Tape,

Cable Holder

Note:

Piezo pickups and transducers have a very high output impedance. In order to get the optimum sound output we recommend

an amplier with low impedance input.

Note:

Piezo pickups and transducers have a very high output impedance. In order to get the optimum sound output we recommend

an amplier with low impedance input.

3. Install the sensors into the bridge slots.

4. Locate the output socket in a convenient location on the instrument and attach with applied double sided adhesive.

5. Connect to appropriate amplier with instrument cable.

3. Install the sensors into the bridge slots.

4. Locate the output socket in a convenient location on the instrument and attach with applied double sided adhesive.

5. Connect to appropriate amplier with instrument cable.

1. Test t sensors into the slot between the wing and foot.

Pickup should t tightly for best output (see g 1).

1. Test t sensors into the slot between the wing and foot.

Pickup should t tightly for best output (see g 1).

2. If pickup is too loose, shim with included shim material (see fig 2 ). If pickup is too high, file the bridge slot slightly.2. If pickup is too loose, shim with included shim material (see fig 2 ). If pickup is too high, file the bridge slot slightly.
