Introduction to Sightron

Congratulations on the purchase of your new

Sightron S1 G2 Series Riflescope.

Sightron is a leader in developing new products

for the outdoor enthusiast.

This instruction sheet is designed to provide you

with the proper fundamentals for using your

S1 G2 Series Riflescope.

If you have any questions, please feel free to

contact us at [email protected],

www.sightron.com, or by phone at

+1-919-562-3000.

Before mounting your new Sightron S1 G2

Series Rifle

Scope please check to make sure it

is the correct

model and includes the following

accessories:

1-Set of Lens Covers

1-Lens Cloth

1-Instruction Sheet

1-Reticle Chart (Mil-Dot.HHR.MOA only)

CAUTION: ALWAYS ENSURE YOUR

WEAPON IS UNLOADED PRIOR TO MOUNTING

YOUR SCOPE.

USE EYE AND HEARING PROTECTION AND

FOLLOW PROPER SAFETY RULES WHEN

HANDLING OR FIRING YOUR WEAPON.

Place both rings on your mount base or receiver,

and tighten. Remove the top half of the rings

and place the riflescope in the bottom half of

the rings.

Once you have determined proper ring spacing

and eye relief, align the reticle with a vertical

line preferably a plumb line.

Tighten the top half of the rings to between 15 to

18 inch pounds or

169 to 203 Newton

Centimeters and adjust the

diopter or eye piece

focus so the reticle is crisp

and clear.

Note: The only purpose of the diopter is to focus

the reticle sharp and clear.

Sighting in Your Gun

1. Place a 2 to 3 foot target at 50 to 100 yards

away. Using a bench rest, fire two shots while

aiming at the center of the bullseye.

2.

While re-aiming at the bullseye adjust the reticle

to the bullets impact point by using the turret

adjustments and fire two more shots.

3.

Your scope should now be close to point of aim.

Fire at the bullseye and make the necessary

final adjustments.

4. Adjusting the windage and elevation turret in

the direction of the arrow on the knob, it will

move the bullet impact in the direction indicated.

5. For best optical and mechanical performance

keep the windage and elevation travel as

centered as possible to allow for maximum

adjustment range for your model of riflescope.

Note: Most sight in problems are caused by

poor ring alignment.

On

ce your scope is sighted in for the required

distance loosen the slotted screw with a coin and

remove. Realign the turret so the zero aligns with

vertical index mark on the alignment scale and

retighten.

First Shot

First Adjustment

Adjust

reticle

to this

point

OcularLens

Diopter Adjusting Ring

Elevation Adjusting Knob

Windage

Adjusting Knob

Zoom Ring

Objective Lens

S1 G2SERIES

RIFLESCOPE

INSTRUCTIONS

OcularLens

Diopter Adjusting Ring

Elevation Adjusting Knob

Windage

Adjusting Knob

Zoom Ring

Objective Lens

Adjustable focus (AO models only)



Resetting Your Turrets

Focusing Your Riflescope

Your new Riflescope has been optically centered

at the factory. After completion of the mounting

procedure simply adjust the adjustable objective

(AO Models only) to the required distance.

Your New S1 G2 Riflescope



Mounting Your Riflescope
