Dimensions

*988-12705-002*

NAC™ -D

INSTALLATION GUIDE

86.5 mm (3.4”)

20.0 mm

(0.8”)

11.5 mm

(0.45”)

17.1 mm

(0.67”)

9.6 mm

(0.38”)

Optimus® (SEASTAR®) and Yanmar®

Volvo® and Yamaha®

Compass

TT

Autopilot

Co

ntrol unit

Volvo® / Yamaha®

Autopilot Gateway

12V DC

T

T

12V DC

Volvo® / Yamaha®

CAN BUS / NMEA 2000® c

ompatible

steering system

NAC™ -D

STEERINGTOPILAUOT

Compass

NAC™ -D

TT

Autopilot

Control unit

12V DC

Optimus® 360 (SEAST

AR®) / Yanmar®

CAN BUS / NMEA 2000® compatible

steering system

T

NMEA 2000®

BACKBONE

NMEA 2000®

DROP CABLES

CAN BUS / NMEA 2000®

TERMINATOR

STEERING SYSTEM

CAN BUS

STEERINGTOPILAUOT

*Yanmar® autopilot t(kionly for Yanmar®)

*

55 cm (2.17”)55 cm (2.17”)

Compliance statements

Declarations

The relevant Declaration of Conformity is available on the following websites:

www.simrad-yachting.com

Europe

Navico declares under our sole responsibility that the product conforms with the requirements of:

• CE under EMC Directive 2014/30/EU

United States of America

¼Note: The user is cautioned that any changes or modications not expressly approved by the

party responsible for compliance could void the user’s authority to operate the equipment.

Australia and New Zealand

Navico declares under our sole responsibility that the product conforms with the requirements of:

• level 2 devices of the Radiocommunications (Electromagnetic Compatibility) standard 2017

Trademarks

®Reg. U.S. Pat. & Tm. O, and ™ common law marks. Visit www.navico.com/intellectual-property to

review the global trademark rights and accreditations for Navico Holding AS and other entities.

¼Note: for some systems, it is only possible to turn the rudder when the engine is

in gear.
