INSTRODUCTION

INSTRUCTIONMANUAL

600TVL Camera

SK-600116

SkyRC 600TVL Camera employs 1/3" SONY SUPER HAD II CCD image sensor to ensure

fantastic light handing and high definition. The lightweight plastic casing and bracket are

tailored for easy mounting. The lens of the camera is changeable. Besides, it allows users

to set the parameters and fine tune personalpreferenceswith a control stick included in

the package.

SPECIFICATIONS

Item

Image Sensor

DSP

Effective Pixel Array

FOV

Signal System

OSD Menu

Horizontal Resolution

Min. Illumination

S/N Ratio

Auto Gain Control

White Balance

Back Light Compensation

Electronic Shutter Speed

Working Voltage

DNR

WDR

Day/ Night Shift

Size

Weight

SK-600116-01

1/3” SONY SUPER HAD II CCD

Nextchip 2090

752 (H) x 582 (V)

115°(Default)

PAL

8 Languages

600TVL

0.01Lux

≥60dB

OFF/LOW/MID/HIGH

MANUAL/ AUTO/ AUTO TRACK

OFF/ BACK LIGHT

COMPENSATION/ STRONG

LIGHT SUPPRESSION

1/50-1/100000S

DC5V-12V

2D-DNR

D-WDR

Auto/ Color/ B&W

26.6x26.6x29.8mm

11.3g

SK-600116-02

1/3” SONY SUPER HAD II CCD

Nextchip 2090

768 (H) x 494 (V)

115°(Default)

NTSC

8 Languages

600TVL

0.01Lux

≥60dB

OFF/LOW/MID/HIGH

MANUAL/ AUTO/ AUTO TRACK

OFF/ BACK LIGHT

COMPENSATION/ STRONG

LIGHT SUPPRESSION

1/60-1/10000S

DC5V-12V

2D-DNR

D-WDR

Auto/ Color/ B&W

26.6x26.6x29.8mm

11.3g

Upper Indicator

Lens

Transmitter

Connector

Control Stick

Connector

Mounting

Bracket

HOW TO FIX

CONNECTION

Transmitter

Control Stick

Video GND

5-13V DC

* Unplug the control stick connector after setting.

Hanging

Camera Mounting Board

Base

Side Plate

Note: Camera Mounting Board is not included.Note: Side Plate is not included.
