Made in U.S.A. www.SmartAVI.com 1-800-AVI-2131
MXWall-Pro
User Manual
All-in-one HD Switch / Converter / Scaler for
Video Walls and Signage Displays
Route Up to 32 sources to as many as 32 HD displays
2
TABLE OF CONTENTS
WHAT'S IN THE BOX? 2
INTRODUCTION 3
FEATURES 3
APPLICATIONS 3
TECHNICAL SPECIFICATIONS 4
HARDWARE INSTALLATION 5
AVAILABLE CONFIGURATIONS 6
FRONT PANEL CONTROLS 7
SOFTWARE INSTALLATION AND USE 8-11
LIMITED WARRANTY STATEMENT
WHAT'S IN THE BOX?
PART NO. QTY DESCRIPTION
MXWALLPRO-32x32-S 1 32 Port HDMI, Real-Time Switch with Integrated Video wall
CCPWR06 Power supply cord 1
1 Quick Start Guide
Figure 2-1
3
INTRODUCTION
The MXWall-Pro is an enhanced and fully scalable video wall controller combining switching capabilities with
the versatile high definition capabilities of a converter. Specifically designed and optimized for the most de-
manding environments and applications, the MXWall-Pro lets users manage and route up to 32 HDMI video
sources to as many as 32 HD displays. Capable of expanding any one HD signal to as many as 4 to 32 large-
scale screens at 1080p (1920x1080 @ 60Hz). Completely compatible with HDCP and HDMI 1.4 connectors,
the MXWall-Pro reliably transmits HD content across scalable display configurations in real-time for 24/7 un-
interrupted use via DVI outputs.
FEATURES
· Complete hardware solution
· Plug-and-play ready
· Expandable 32 HDMI inputs and 32 DVI outputs
· Output Resolution up to 1080p @ 30Hz
· Supports Video Wall and Digital Signage Layouts
· Reliable 24/7 Uninterrupted Use
· Easy control and access
· HDCP and HDMI 1.4 compliant
· User-Friendly MXWall Manager Software
APPLICATIONS
· Corporate or Educational Presentations
· Airport Installations
· Wall Displays
· Digital Signage
· Dealer Rooms
· Control Rooms
· Shopping Centers
· Security
· Point-of-Sale
· Entertainment Venues
· Corporate Lobbies
· Restaurants
