Digital Cinema
Dual System
Operating Instructions
Before operating the unit, please read this manual and supplied Safety Regulations
thoroughly and retain it for future reference.
SRX-R515P
SRX-R515
LKRA-010
LKRA-011
LKRA-PCAB1
4-573-779-13(1)
© 2015 Sony Corporation
2
Table of Contents
Please Read This First .............................................. 3
Notations Used in This Guide ................................ 3
Manual Structure ................................................... 3
About License ........................................................ 3
USB HDD and USB Memory Devices That can be
Used on INGEST PORT 1/2 of This Unit ........... 3
Recognized Folder Names ..................................... 3
On Security ............................................................ 3
Overview
System Configuration Example ............................... 4
Part Names and Functions ....................................... 5
SRX-R515 Digital Cinema Projector .................... 5
XCT-S10 Digital Cinema Server ........................... 8
LKRA-007 Touch Panel Monitor ........................ 10
LKRA-011 3D filter and holder .......................... 11
LKRA-PCAB1 Projector Auto Calibration
Box ..................................................................... 12
Main Screen ......................................................... 13
Items to Check
Startup ..................................................................... 15
Turning on the Main Power on the Projectors ..... 15
Starting up the Server .......................................... 15
Logging Into the System ...................................... 15
Starting the Projectors .......................................... 16
Rebooting the System ............................................. 17
Shutting Down the System ..................................... 17
Operations
Sequence of Operations .......................................... 18
Selecting the Projector to be Controlled ............... 18
Ingesting DCP .......................................................... 19
Ingesting from HDD via USB Connector ............ 19
Ingesting from HDD via CRU DATAPORT ........ 20
Ingesting via Network .......................................... 21
Ingesting KDM ........................................................ 21
Ingesting from a USB Flash Drive ....................... 21
Ingesting from a Network Folder ......................... 22
Playing Back CPL ................................................... 23
Calling up Screen Adjustment Data .................... 23
Selecting a CPL ................................................... 24
Playing Back CPL ................................................ 25
Creating an SPL ...................................................... 26
Creating an SPL ................................................... 26
Setting an Intermission in the SPL ...................... 28
Triggering SPL Playback Using GPI Signals ...... 29
Playing Back an SPL .............................................. 30
Selecting an SPL .................................................. 30
Playing Back an SPL ........................................... 30
Creating a Schedule ................................................ 30
Creating a Schedule ............................................. 30
Importing/Exporting Schedules ........................... 31
Projecting Images Using an External Playback
Device ....................................................................... 32
Manually Controlling Theater Facilities ............... 33
Others
Opening/Closing the 3D Filter ............................... 34
Opening the 3D Filter .......................................... 34
Closing the 3D Filter ........................................... 34
Calibrating the Screen ............................................ 35
Installing the Calibration Camera ........................ 35
LCD Panel Displays ............................................. 37
Preparation ........................................................... 37
Performing Calibration ........................................ 38
Periodic Calibration Using SPLs ......................... 40
Attaching and Removing the Lens ........................ 42
Removing the Lens .............................................. 42
Attaching the Lens ............................................... 43
How to Read the Indicators ................................... 44
Troubleshooting ....................................................... 46
Error Code List (LKRA-PCAB1) .......................... 48
Specifications ........................................................... 50
SRX-R515 Digital Cinema Projector .................. 50
XCT-S10 Digital Cinema Server ......................... 50
LKRA-007 Touch Panel Monitor ........................ 51
LKRA-010 Dual System Accessory Kit .............. 51
LKRA-011 3D filter and holder ........................... 51
LKRA-PCAB1 Projector Auto Calibration
Box ..................................................................... 51
Trademarks
• The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.
• Other products or system names appearing in this
document are trademarks or registered trademarks of
their respective owners.
Further, the ® or ™ symbols are not used in the text.
• Reproduction or duplication, in whole or part, of the
operation manual supplied with the system without the
authorization of the right holder is prohibited under
copyright law.
• Sony assumes no responsibility for damages, loss of
income, or any claims from a third party arising out of
use of the system.
• Note that the specifications of the system are subject to
change for improvement without prior notice.
