SPEAKMAN COMPANY

S-3014 Installation, Operation & Maintenance Instructions

ANYSTREAM

®

SHOWERHEAD

DESCRIPTION

Polished chrome plated ANYSTREAM

®

S-3014 Showerhead with a 3-3/4” outer spray adjustment ring. 5 self-

cleaning plunger nozzles resist scale build-up and provide 45 spray streams for a full body coverage pattern. The

center core nozzle delivers twelve massaging jets and a combination spray is included. Water conserving pressure

compensating AUTOFLO® device reduces flow to 2.5 GPM/9.46LPM maximum, to meet existing ANSI A112.18.1

Standard. ½” NPT inlet.

OPTIONS

SPECIFICATIONS

◊BN –Brushed Nickel

◊S-3014-E2 – Low Flow Showerhead

(2.0 GPM/ 7.6 LPM)

◊S-3014-BN-E2 – Low Flow Brushed

Nickel Showerhead

(2.0 GPM/ 7.6 LPM)

SUPPLY INLET: ½” NPT

FLOW RATE: 2.5 GPM/9.46LPM MAXIMUM

SHIPPING WEIGHT: 1.0 LBS.

INSTALLATION

Remove the old shower head from the shower arm. Clean of the shower arm. Wrap o any debris on the threads

Teflon tape around the shower arm threads in a clockwise direction. Turning in a clockwise direction, screw the

new Speakman shower head onto the shower arm. Tighten with a wrench. Turn the water supply on and check for

leaks.

OPERATION

To adjust the spray pattern of the shower head, simply rotate the outer ring to the desired spray (Full-Body, Dual

action or Massage). The outer ring can rotate 360°.

MAINTENANCE

1/11

92-3200

Rev. 1

The gleaming finish of your SPEAKMAN ANYSTREAM

®

shower head can be cleaned by using mild soap and warm

water. Dry immediately with a soft, clean cloth for best results. The flow control device limits water flow to 2.5 gallons

per minute. The small orifices may become clogged with scale and other minerals found in potable water. To clean the

flow regulator, simply remove the shower head from the bent arm, dislodge the flow regulator which is located in the

inlet and clean as necessary.

ROUGH-IN MEASUREMENTS

Product improvements may cause

specification and dimensional

changes without notice.

SPEAKMAN

SPEAKMAN

SPEAKMAN

SPEAKMANSPEAKMAN

®

PO Box 191 Wilmington, DE 19899 Phone: 800-537-2107 Fax: 800-977-2747

Visit us on the web at www.speakmancompany.com
