INSTRUCTIONS FOR MODELS

92-S-3019-01

For additional assistance or service please contact:

SPEAKMAN

®

Company

400 Anchor Mill Road

New Castle, DE 19720

800-537-2107

customerser[email protected]

www.speakman.com

S-3019

S-3019-E2

S-3019-E175

TOOLS AND SUPPLIES

IMPORTANT

SAFETY TIPS

Cover your drain to prevent loss of parts.

MAINTENANCE

WARRANTY

Additional warranty information can be found at:

www.speakman.com

Thread Seal

Tape

(included)

Adjustable

Wrench

Be sure to read instructions thoroughly before

beginning installation. Do not overtighten any

connections or damage may occur. This showerhead

has an operating range of 20-80 psi.

Periodic cleaning using a mild soap and warm water

will help keep your Showerhead's appearance in its

original condition.

For best results, dry immediately with a soft, clean

cloth. DO NOT USE harsh and/or abrasive cleaners.

To help restore the finish, occasionally apply a

non-abrasive wax to your showerhead body (follow

manufacturers’ instructions).

On CHROME PLATED SHOWER HEADS, a two (2)

part white vinegar, one (1) part water solution can be

used to break down excessive mineral deposits on the

sprays. Let the showerhead soak in the solution for

about ½ hour then rinse thoroughly. Brush off any

remaining mineral deposits if necessary.

DO NOT USE the vinegar/water treatment on any

finish other than Chrome.

To reduce mineral build-up, turn the handle to FLOOD

position to let the water drain out after every use.

ROUGH-IN

Specifications:

Inlet: 1/2” NPT FEMALE

Model:S-3019

Max. Flow Rate:2.5 gpm (9.5L/min)

Min. Flow Rate:2.0 gpm (7.6 L/min) @ 45psi

FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED

AT 7.6 L/MIN (2.0 GPM) OR LESS.

Model:S-3019-E2

Max. Flow Rate:2.0 gpm (7.6 L/min)

Min. Flow Rate:1.5 gpm (5.7 L/min) @ 45psi

FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED

AT 6.6 L/MIN (1.75 GPM) OR LESS.

Model:S-3019-E175

Max. Flow Rate:1.75 gpm (6.6 L/min)

Min. Flow Rate:1.3 gpm (4.9 L/min) @ 45psi

FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED

AT 5.7 L/MIN (1.5 GPM) OR LESS.

4

1

8

1

5

8

"

41mm

2"

51mm

3

15

16

"

99mm

5

15

16

"

150mm

4

1

8

"

105mm

1

Apply Thread Seal Tape to the outlet side of

shower arm in a clockwise direction.

2

Thread Shower head onto shower arm by turning

it in a clockwise direction. Tighten with adjustable

wrench. Turn water supply on and check for leaks.

3

Adjust spray pattern by rotating side handle to

preferred Anystream

®

position.
