200 New Highway, Amityville, NY 11701

800-645-5516 / www.specotech.com

DIMENSIONS

FEATURES

Intensifier T® Series HD-TVI 1080p 2MP Bullet Camera

Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage

HTi70TM –2.8~12mm motorized

motorized

motorized

motorized motorized zoom focus lens,

zoom focus lens,

zoom focus lens,

zoom focus lens, zoom focus lens, dark gray housing

dark gray housing

dark gray housing

dark gray housingdark gray housing

HTi702TM –5~50mm motorized

motorized

motorized

motorized motorized zoom focus lens,

zoom focus lens,

zoom focus lens,

zoom focus lens, zoom focus lens, dark gray housing

dark gray housing

dark gray housing

dark gray housingdark gray housing

SPECIFICATIONS

Image Sensor.................. 1/2.9” Progressive Scan CMOS, 2MP

Minimum Illumination....... 0.001 lux (Sens-up X32)

Effective Pixels................ 1984 (H) x 1105 (V)

Total Pixels...................... 2000 (H) x 1121 (V)

Scanning System............ Progressive

S/N Ratio......................... More than 50dB

Output Resolution............ 1920x1080 @ 30fps

Video Output.................... 1.0Vp-p / 75 Ohms

Electronic Shutter............ Auto / Manual (1/30 –1/30,000 sec.)

Day / Night....................... Color (default) / BW / Ext / Auto

Test Monitor Output......... CVBS (BNC out in Yellow)

Communication............... UTC (up the coax)

Power............................. 12VDC / 24VAC

Power Consumption........ 600mA max. (DC), 450mA max. (AC)

Operating Temperature.... -40F –140F °°

Unit Dimensions.............. 9.64” (L) x 3.72” (Dia.)

Unit Weight...................... 2 lbs(camera), 0.9lbs (junction box)

Certifications.................... FCC, RoHS

Signal Distance............... Up to 1600 feet

(depending on coax quality)*

• Full HD resolution over coax (HD-TVI)

• Supports up to Full HD 1080p @ 30fps

• True WDR operation

• Superior low-light performance

• Amplify existing light with no distance limitation

• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor

• Built-in heater and anti-fog glass reduces condensation

• 3-axis for wall and ceiling mounting

• Full OSD operation through on-board control and UTC (up the coax)

• Additional 960H analog output

• Signal distance up to 1600 feet*

• IP67 compliant, weather resistant

• 12VDC & 24VAC dual voltage operation

• 5 year warranty

OSD MENU TREE

PRESET MODE

•OUTDOOR

•INDOOR•LOW LIGHT

•LOBBY

•HALLWAY

•ELEVATOR

MAIN SETUP

EXPOSURE

•B/W

•EXTERN

•••LOWMIDDLEHIGH

•••SHARPNESSGAMMAMIRROR

•FLIP

DAY / NIGHT

COLOR

SPECO DNR


EXIT

•BRIGHTNESS

•SHUTTER

BACKLIGHT

•HLC•BLC

•WDR

•AUTO

••AWBCOLOR GAIN

••ACEDEFOG

SYSTEM

•OUTPUT

•FREQ.

•IMAGE RANGE

•INTENSIFY

•AGC

•COLOR

•SHADING

IRIS

MOTION

•FRAME RATE

•LANGUAGE

•COLOR BAR

•RESET

•CAM TITLE

•D-ZOOM

•PRIVACY

2-MOTOR

•COLOR SPACE

•COM.

INTCM1

(Pole/Corner Mount)

DIMENSIONS

Camera

Optional Accessories

Unit : inch

Junction Box

included

OSD Joystick

Video Test (CVBS)

Right (Near)

Up (Zoom-In)

Down (Zoom-Out)

Left (Far)

OSD CONTROL
