Seite 1/160
QUANTUM AIS GX6000
25 Watt VHF/FM Marine Transceiver
Owner’s Manual
z Capable of connecting two optional wired RAM4 or one wired RAM4 and up to four Wireless
RAM4W remote access microphones using SCU-30 wireless access point
z Integrated NMEA 2000 interface supporting all PGNs for Navigation, GPS, AIS and DSC functions
z Integrated Dual Channel AIS (Automatic Identication System) receiver
z GPS Compass, Waypoint and GPS status pages
z Dual Zone 25W PA / Loud Hailer with preprogrammed horn, siren, fog signals and listen back
z Submersible IPX8 (5 feet or 1.5 meters for 30 minutes)
z Integrated 32 Code Voice Scrambler and 4 Code Voice Scrambler
z AIS / AIS SART target display: MMSI, Call Sign, Ship Name, BRG, DST, SOG and COG
z Front panel microphone can be connected to rear panel and extended 20 feet using MEK-4
mic extension kit
z Programmable CPA or TCPA collision avoidance alarms
z Advanced 80 dB commercial Grade Receiver with Local / Distance Attenuator
z Intercom feature allows you to communicate between the radio, RAM4 and Wireless RAM4W
microphones
z Integrated Voice Recorder to play back up to two minutes of RX receive audio
TABLE OF CONTENTS
Quick Reference Guide ...................................... 2
1 GENERAL INFORMATION ............................ 3
2 PACKING LIST ............................................... 4
3 OPTIONAL ACCESSORIES .......................... 4
4 ONLINE WARRANTY REGISTRATION
(in USA or Canada only) ............................... 4
5 GETTING STARTED ...................................... 5
5.1 PROHIBITED COMMUNICATIONS ............................. 5
5.2 ABOUT VHF RADIO .................................................... 5
5.3 SELECTING AN ANTENNA ......................................... 5
5.4 COAXIAL CABLE ......................................................... 6
5.5 DISTRESS AND HAILING (CHANNEL 16) .................. 6
5.6 CALLING ANOTHER VESSEL (CHANNEL 16 OR 9) ... 7
5.7 MAKING TELEPHONE CALLS .................................... 8
5.8 BRIDGE CHANNELS 13 AND 67 ................................ 8
5.9 AUTOMATED RADIO CHECK SERVICE .................... 8
5.10 WHAT IS THE RANGE FOR AIS RECEIVERS? .......... 9
5.11 ACCURACY OF COG* ................................................. 9
6 CONTROLS AND INDICATORS .................. 10
6.1 FRONT PANEL .......................................................... 10
6.2 MICROPHONE .......................................................... 12
6.3 REAR PANEL ............................................................. 14
7 INSTALLATION ............................................ 16
7.1 SAFETY / WARNING INFORMATION ....................... 16
7.2 LOCATION ................................................................. 16
7.3 MOUNTING THE RADIO ........................................... 16
7.4 ELECTRICAL CONNECTIONS .................................. 18
7.5 CONNECTION OF EXTERNAL DEVICES
TO THE RADIO ... 20
7.6 INITIAL SETUP REQUIRED WHEN TURNING
ON THE POWER FOR THE FIRST TIME ... 26
7.7
CHECKING GPS SIGNAL (GPS STATUS DISPLAY)
... 28
7.8 GPS CONFIGURATION ............................................. 29
8 BASIC OPERATION ..................................... 32
8.1 TURNING ON AND OFF THE TRANSCEIVER ......... 32
8.2 RECEPTION .............................................................. 32
8.3 TRANSMISSION ........................................................ 32
8.4 BASIC OPERATION OF THE MENU MODE ............. 33
8.5 TRANSMIT TIME-OUT TIMER (TOT) ........................ 34
8.6 SIMPLEX/DUPLEX CHANNEL USE .......................... 34
8.7 USA, INTERNATIONAL, AND CANADA MODE ........ 35
8.8 NOAA WEATHER CHANNELS .................................. 35
8.9 MULTI WATCH (TO PRIORITY CHANNEL) .............. 37
8.10 SCANNING ................................................................ 38
8.11 PRESET CHANNELS: INSTANT ACCESS ................ 40
8.12 MOB OPERATION ..................................................... 41
8.13 PA/FOG OPERATION ................................................ 42
8.14 INTERCOM OPERATION .......................................... 45
8.15 VOICE SCRAMBLER ................................................. 45
8.16 DEMO MODE ............................................................. 46
9 GPS OPERATION ........................................ 47
9.1 DISPLAYING POSITION INFORMATION .................. 47
9.2 CHECKING GPS STATUS ......................................... 47
9.3 GPS LOGGER OPERATION ..................................... 48
10 DIGITAL SELECTIVE CALLING (DSC) ....... 49
10.1 GENERAL .................................................................. 49
10.2 DSC DISTRESS ALERT ............................................ 50
10.3 ALL SHIPS CALL ....................................................... 54
10.4 INDIVIDUAL CALL ..................................................... 56
10.5 GROUP CALL ............................................................ 62
10.6 POSITION REQUEST ................................................ 67
10.7 POSITION REPORT .................................................. 71
10.8 POLLING CALL .......................................................... 75
10.9 AUTO POSITION POLLING ...................................... 77
10.10 DSC TEST .................................................................. 79
10.11 DSC LOG OPERATION ............................................. 81
10.12 DSC LOOP BACK OPERATION ................................ 83
11 NAVIGATION ................................................ 84
11.1 WAYPOINT OPERATION ........................................... 84
11.2 ROUTING OPERATION ............................................. 88
12 GM OPERATION .......................................... 92
12.1 SETTING UP GM OPERATION ................................. 92
12.2 STARTING GM OPERATION ..................................... 94
13
AUTOMATIC IDENTIFICATION SYSTEM (AIS)
... 96
13.1 GENERAL .................................................................. 96
13.2 AIS OPERATION ....................................................... 96
13.3 AIS SETUP .............................................................. 100
14 NMEA 2000 SETUP ................................... 103
14.1 SELECT DEVICE ..................................................... 103
14.2 DEVICE NUMBER ................................................... 103
14.3 SYSTEM NUMBER .................................................. 104
14.4 SUMMARY OF THE NMEA 2000 SETUP ................ 104
14.5 COMPATIBLE NMEA 2000 PGN LIST ..................... 104
15 CONFIGURATION SETUP ......................... 106
15.1 DISPLAY MODE ....................................................... 106
15.2 DIMMER ADJUSTMENT .......................................... 106
15.3 DISPLAY CONTRAST .............................................. 106
15.4 KEY BEEP ................................................................ 107
15.5 FOG ALERT TONE FREQUENCY ........................... 107
15.6 LISTEN BACK .......................................................... 107
15.7 STATION NAME ....................................................... 108
15.8 SOFT KEYS ............................................................. 109
15.9 MODE/STATUS LED DIMMER ................................ 111
15.10 RESET ..................................................................... 111
15.11 SUMMARY OF THE CONFIGURATION SETUP ..... 112
16 CHANNEL FUNCTION SETUP .................. 112
16.1 CHANNEL GROUP .................................................. 112
16.2 WEATHER ALERT ................................................... 112
16.3 SCAN MEMORY ...................................................... 112
16.4 SCAN TYPE ............................................................. 113
